Black Box GigaTrue Cat. 6 Channel UTP Patch Cable
Black Box GigaTrue Cat. 6 Channel UTP Patch Cable - RJ-45 Male - RJ-45 Male - 5ft - Red
| $8.16 | Retail $9.71 |
- High quality stranded 24 AWG unshielded copper wire
- Tested to 550 MHz and meets or exceeds CAT6 specifications
- Cable construction: stranded, 24-AWG copper wire, RJ-45 connectors, 4-pair, T568B, PVC jacket, straight-pinned
- For 1000BASE-T, 100BASE-TX, 100BASE-VG, 155-Mbps ATM, 100-Mbps FDDI/CDDI, and other high-speed applications
- Guaranteed for life!
By:
Black Box
Manufacturer:
Black Box Corporation
Product ID:
118238
Item:
EVNSL623-0005
UPC Code:
641676281562
Our Part #
BBNEVNSL6230005
Condition
New
$8.16EA
$9.71
$9.71
Availability
Only 6 Left In Stock
You may be also interested
Product description
Black Box GigaTrue Cat. 6 Channel UTP Patch Cable - RJ-45 Male - RJ-45 Male - 5ft - Red
RJ-45 Male - RJ-45 Male - 5ft - Red
Specifications
Jacket Material
Polyvinyl Chloride (PVC)
UPC Alternates
641676281562 822088034285
Additional Information
- Full Power Sum Performance
- Impedance: 100 ± 15 Ohms at 100 MHz 100 ± 22 Ohms at 100-550 Mhz
- Meets balance requirements (LCL/LCTL)
- Attenuation:23.6 dB at 100 MHz 39.1 dB at 250 MHz
- Delay Skew (Maximum): 25 ns/100 m
- Mutual Capacitance (Maximum): 56 pF/m
- NEXT: 45.0 dB at 100 MHz 39.0 dB at 250 MHz
- PS-ACR: 32 dB (Typical) at 100 MHz
- PS-NEXT: 43.0 dB at 100 MHz 37.0 dB at 250 MHz
- Resistance (Maximum): 9.09 ohms/100 m (328 ft.)
- Return Loss: 22.5 dB at 100 MHz; 20.5 dB at 250 MHz
- Structured Return Loss: 22.5 dB at 100 MHz 20.5 dB at 250 Mhz
Applications:
- 1000BASE-T
- 100BASE-TX
- 100BASE-VG
- 155-Mbps ATM
- 100-Mbps FDDI/CDDI
American Wire Gauge
24 AWG
Brand Name
Black Box
Cable Characteristic
Patch Cable
Cable length
5 ft
Cable type
Category 6
Certifications & Standards
EIA/TIA-568-B.2-1
Color
Red
Conductor
Copper
Connector on First End
RJ-45 Male Network
Connector on First End
1 x RJ-45 Male Network
Country of origin
China
Data transfer rate
1 Gbit/s
Device Supported
Wallplate
Device Supported
Patch Panel
Device Supported
Network Device
Features
Near End Cross Talk (NEXT)
Features
Rugged
Features
Non-booted
Features
Stranded
Jacket Type
CM
Limited Warranty
Lifetime
Manufacturer
Black Box Corporation
Manufacturer Part Number
EVNSL623-0005
Manufacturer Website Address
http://www.blackbox.com
Marketing Information
Get high-level CAT6 performance in an end-to-end BLACK BOX® GigaTrue® channel with our 550MHz Stranded Ethernet Patch Cable. It provides full-duplex operation for next-generation applications and meets balance requirements (LCL/LCTL) resulting in better transmission.
The improved attenuation provides cleaner data and video transmissions. Our rugged PVC jacket stands up to long-term use and is perfect for full broadband and baseband video.
Product Line
GigaTrue
Product Name
GigaTrue Cat.6 UTP Patch Network Cable
Product Type
Network Cable
Shielding
No
