Broadcom NetXtreme BCM5720-2P Dual-Port Ethernet Server Adapter
Broadcom NetXtreme BCM5720-2P Dual-Port Ethernet Server Adapter - PCI Express 2.0 x1 - 2 Port(s) - 2 - Twisted Pair - 10/100/1000Base-T - Plug-in Card
| $89.27 |
- Enjoy the super fast Gigabit Ethernet connection by inserting this Gigabit Ethernet card into your computer
- This 500MB/s bandwidth adapter is ideal for PCs with PCI Express 2.0 x1 slots, ensuring top level network connectivity for your desktops
- For high bandwidth connectivity, add this efficient dual port gigabit ethernet card to your server or workstation
- Supports cost-efficient twisted pair cables for speedy data transfer up to 100 meters
- With the 10/100/1000Base-T technology get up to 1000Mbps data transfer rate over the twisted pair cable
By:
Broadcom
Manufacturer:
Broadcom Corporation
Product ID:
173849
Item:
BCM95720A2003AC
Our Part #
43201404
Condition
New
$89.27EA
Availability
Only 193 Left In Stock
Product description
Broadcom NetXtreme BCM5720-2P Dual-Port Ethernet Server Adapter - PCI Express 2.0 x1 - 2 Port(s) - 2 - Twisted Pair - 10/100/1000Base-T - Plug-in Card
PCI Express 2.0 x1 - 2 Port(s) - 2 - Twisted Pair - 10/100/1000Base-T - Plug-in Card
Specifications
Brand Name
Broadcom
Depth
4.3"
Device Supported
Server
Form factor
Plug-in Card
Height
2.7"
Host interface
PCI Express 2.0 x1
Manufacturer
Broadcom Corporation
Manufacturer Part Number
BCM95720A2003AC
Manufacturer Website Address
http://www.broadcom.com
Marketing Information
Leveraging long-standing industry leadership in Ethernet Broadcom now offers the NetXtreme BCM5720-2P Ethernet Server Adapter providing the highest levels of performance efficiency and scalability for the enterprise data center.
Designed for today's enterprise and data center environments the Broadcom BCM5720-2P Ethernet Server adapter is the ideal solution for multicore servers delivering full line-rate throughput across all ports. The adapter utilizes Broadcom's field-proven dual-port BCM5720-2P integrated controller device to deliver lower power consumption and Energy Efficient Ethernet (EEE) reducing IT operation costs. The BCM5720-2P is compatible with x86 and x64 servers utilizing the PCIe v1.x and v2.x interfaces.
Increasing application workloads are placing greater demands on enterprise networks and the BCM5720-2P-based dual-port 1GbE Server Adapter is the solution of choice for such environments providing a reliable highperformance energy-efficient 1GbE connectivity solution.
FEATURES
Designed for today's enterprise and data center environments the Broadcom BCM5720-2P Ethernet Server adapter is the ideal solution for multicore servers delivering full line-rate throughput across all ports. The adapter utilizes Broadcom's field-proven dual-port BCM5720-2P integrated controller device to deliver lower power consumption and Energy Efficient Ethernet (EEE) reducing IT operation costs. The BCM5720-2P is compatible with x86 and x64 servers utilizing the PCIe v1.x and v2.x interfaces.
Increasing application workloads are placing greater demands on enterprise networks and the BCM5720-2P-based dual-port 1GbE Server Adapter is the solution of choice for such environments providing a reliable highperformance energy-efficient 1GbE connectivity solution.
FEATURES
- Dual-port 1GbE adapter for rack and tower servers
- x1 PCI Express (PCIe) v2.0 (5 GT/s) support
- Energy Efficient Ethernet (EEE)
- I/O Virtualization supported with 17 receive queues and 16 transmit queues per port
- Full line-rate performance across all ports
- Broad OS and hypervisor support
- Preboot eXecution Environment (PXE) support
- Support for VMware NetQueue and Microsoft VMQ
- Link aggregation and automatic load-balancing
- Wake-on-LAN support
- MSI and MSI-X support
- IPv4 and IPv6 offloads
- TCP UDP and IP checksum offloads
- Large Send Offload (LSO)
- TCP Segmentation Offload (TSO)
- Receive Side Scaling (RSS)
- Transmit Side Scaling (TSS)
- VLAN support with VLAN tagging
- Jumbo frame support for frames larger than 1500 Bytes
- Broadcom Advanced Control Suite (BACS) management application
- iSCSI remote boot support
- Accelerates Server Performance:
- Boosts network performance with full line-rate performance across all ports.
- Maximizes server processing performance by reducing CPU overhead and lowering interrupt latency through the use of the MSI-X standard.
- Boosts performance in Windows and Linux environments by directing interrupts to the server's CPU cores leveraging Transmit/Receive Side Scaling (TSS/RSS).
- Delivers Advanced Ethernet Capabilities:
- Energy Efficient Ethernet-Reduces adapter power consumption by up to 42% through intelligent adaptive power management adjusting power based on data traffic load.
- Robust Virtualization Capabilities:
- Superior network performance with support for VMware NetQueue and Microsoft VMQ technologies.
- Enhances network management and efficiency with support for VLAN tagging.
- Streamlines Deployment and Management:
- Simplifies deployment and management complexity-Broadcom Ethernet solutions available across a wide range of server platforms.
- Unifies the Server Adapter and storage management using Broadcom Advanced Management Suite (BACS).
Media Type Supported
Twisted Pair
Network Technology
10/100/1000Base-T
Number of Network (RJ-45) Ports
2
Product Line
NetXtreme
Product Model
BCM5720-2P
Product Name
NetXtreme BCM5720-2P Dual-Port Ethernet Server Adapter
Product Type
Gigabit Ethernet Card
