Microchip 1-Port 30W 802.3at PoE Injector
Microchip 1-Port 30W 802.3at PoE Injector - 120 V AC, 230 V AC Input - 55 V DC Output - 1 x 10/100/1000Base-T Input Port(s) - 1 x 10/100/1000Base-T Output Port(s) - 30 W
| $53.10 | Retail $86.91 |
By:
Microchip
Manufacturer:
Microchip Technology Inc.
Product ID:
177932
Item:
PD-9001GR/AT/AC-US
UPC Code:
818245045201
Our Part #
3U7100
Condition
New
$53.10EA
$86.91
$86.91
Availability
Only 5 Left In Stock
Product description
Microchip 1-Port 30W 802.3at PoE Injector - 120 V AC, 230 V AC Input - 55 V DC Output - 1 x 10/100/1000Base-T Input Port(s) - 1 x 10/100/1000Base-T Output Port(s) - 30 W
120 V AC, 230 V AC Input - 55 V DC Output - 1 x 10/100/1000Base-T Input Port(s) - 1 x 10/100/1000Base-T Output Port(s) - 30 W
Specifications
Input Ports
1 x 10/100/1000Base-T
Maximum Output Voltage
55 V DC
UPC Alternates
818245045201 844117002058
UPC Alternates
818245045201
Brand Name
Microchip
Certifications & Standards
- CE
- FCC Part 15 Class B
- EN 55022 Class B (Emissions)
- EN 55024 (Immunity)
- VCCI
- UL/cUL Per IEC 60950-1
- IEEE802.3af
- IEEE802.3at
Certifications & Standards
- CE
- FCC Part 15 Class B
- EN 55022 Class B (Emissions)
- EN 55024 (Immunity)
- VCCI
- UL/cUL Per IEC 60950-1
- IEEE802.3af
- IEEE802.3at
Compatibility
- Access Points
- Pan-Tiltzoom (PTZ) Cameras
- Video-Phones
- Network Devices
Country of origin
China
Environmental Certification
RoHS
Environmental Certification
GS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Height
1.3"
Input voltage
230 V AC
Input voltage
120 V AC
Length
5.5"
Limited Warranty
1 Year
Manufacturer
Microchip Technology Inc.
Manufacturer Part Number
PD-9001GR/AT/AC-US
Manufacturer Website Address
http://www.microchip.com
Marketing Information
Microsemi's PD-9001GR is a single port high-power solution for remote powering of current and emerging high power applications. Generating up to 30W the PD-9001GR enables remote power for a new range of applications including 802.11ac Access Points pan-tiltzoom (PTZ) cameras and video-phones. It complies with the IEEE 802.3at PoE+ standard and is backward compatible with IEEE802.3af. It can power both existing 10/100Base-T network devices and emerging wireless 1000Base-T devices such as wireless IEEE 802.11ac access points and IP Cameras.
Features
- Single-port Gigabit PoE Midspan 802.3at Compliant with 2-event classification
- Backwards compatible with IEEE802.3af
- 30W output power from -20�C to +40�C 25W output at +55�C
- 1000Base-T compatible
- Safe & reliable power over existing Ethernet infrastructure only PoE devices receive power
- Automatic detection and protection of non-standard devices
- Plug-and-play installation
- Guaranteed up-time
Maximum Frequency
60 Hz
Maximum Input Current
800 mA
Maximum Output Power
30 W
Minimum Frequency
50 Hz
Product Model
PD-9001GR
Product Name
1-Port 30W 802.3at PoE Injector
Product Type
PoE Injector
Weight (Approximate)
7.04 oz
Width
2.2"
