Cisco Catalyst C9200CX-8P-2X2G Ethernet Switch

Cisco Catalyst C9200CX-8P-2X2G Ethernet Switch - 8 Ports - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 1000Base-T, 10GBase-X - 3 Layer Supported - Modular - 240 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Rack-mountable, DIN Rail Mountable, Wall Mountable, Compact, Under Table
$7,396.00
  • Effectively increases available bandwidth on your network
  • Cascade to other network devices through the uplink port to expand your local area network
  • Expand your network capacity with the help of 8 networking ports and transfer your data quickly and easily
  • Power Supply power source for dependable power supply
  • Supports layer 3 switching for enhanced performance and usability
  • Under-table mounting allows you to keep your table tidy and organized
  • Management capability provides control over setup and configuration of your network
  • Gigabit Ethernet port for ultra-fast network speeds
  • Twisted Pair media support for efficient and reliable connectivity
  • Comes in gray color for better adaption to the space
By:
Cisco
Manufacturer:
Cisco Systems, Inc
Product ID:
59817
Item:
C9200CX-8P-2X2G-A
Our Part #
06ZH15
Condition
New
$7,396.00EA
Availability Only 9999 Left In Stock
Great Deals Everyday

You may be also interested

Product description

Cisco Catalyst C9200CX-8P-2X2G Ethernet Switch - 8 Ports - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 1000Base-T, 10GBase-X - 3 Layer Supported - Modular - 240 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Rack-mountable, DIN Rail Mountable, Wall Mountable, Compact, Under Table
8 Ports - Manageable - Gigabit Ethernet, 10 Gigabit Ethernet - 1000Base-T, 10GBase-X - 3 Layer Supported - Modular - 240 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Rack-mountable, DIN Rail Mountable, Wall Mountable, Compact, Under Table

Specifications

Number of Total Expansion Slots
2
PoE Budget
240 W
Total Number of Network Ports
8
UPC Alternates
889728447157
Application/Usage
Business
Brand Name
Cisco
Depth
9.6"
Ethernet Technology
Gigabit Ethernet
Ethernet Technology
10 Gigabit Ethernet
Expansion Slot Type
SFP+
Features
Fanless
Form factor
Under Table
Form factor
Wall Mountable
Form factor
Compact
Form factor
Rack-mountable
Form factor
DIN Rail Mountable
Frequency
60 Hz
Frequency
50 Hz
Height
1.7"
Input voltage
120 V AC
Input voltage
230 V AC
Layer Supported
3
Manageable
Yes
Manufacturer
Cisco Systems Inc
Manufacturer Part Number
C9200CX-8P-2X2G-A
Manufacturer Website Address
http://www.cisco.com
Marketing Information

Introduction

Extend intent-based networking everywhere

Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree Catalyst 9200 Series switches offer simplicity without compromise - it is secure always on and IT simplified.

As foundational building blocks for the Cisco Digital Network Architecture Catalyst 9200 Series switches help customers simplify complexity optimize IT and reduce operational costs by leveraging intelligence automation and human expertise that no other vendor can deliver regardless of where you are in the intent-based networking journey.

Catalyst 9200 Series switches provide security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. Combine that with open APIs of Cisco IOS XE and programmability of the UADP ASIC technology Catalyst 9200 Series switches give you what you need now with investment protection on future innovations.

With full PoE+ capability power and fan redundancy stacking bandwidth up to 160 Gbps modular uplinks Layer 3 feature support and cold patching Catalyst 9200 Series switches are the industry's unparalleled solution with differentiated resiliency and progressive architecture for cost-effective branch-office access. Catalyst 9200 Series switches also provide operational choice of Cisco DNA Center or Meraki cloud monitoring.

Product overview

Product highlights

  • Full Power over Ethernet Plus (PoE+) capability for up to 48 ports for C9200 and Power over Ethernet Plus (PoE+) capability for up to 12 ports for C9200CX. Available in fan less variants for C9200CX.
  • Resiliency with Field-Replaceable Units (FRU) and redundant power supply fans and modular uplinks for C9200. C9200CX are powered by internal fixed power supply or optional power adapters when not powered by upstream 802.3bt type4 90W PSE.
  • Flexible downlink options with data PoE+ or mGig
  • Operational efficiency with optional backplane stacking supporting stacking bandwidth up to 160 Gbps
  • UADP 2.0 Mini with integrated CPU offers customers optimized scale with better cost structure
  • Enhanced security with AES-128 MACsec encryption on C9200 and AES-256 MACsec encryption for C9200CX variants policy-based segmentation and trustworthy solutions for the whole C9200 family
  • Layer 3 capabilities including OSPF EIGRP ISIS RIP and routed access
  • Advanced network monitoring using Full Flexible NetFlow
Media Type Supported
Optical Fiber
Media Type Supported
Twisted Pair
Network Technology
1000Base-T
Network Technology
10GBase-X
Networking standards
IEEE 802.3
Networking standards
IEEE 802.3u
Networking standards
IEEE 802.3z
Networking standards
IEEE 802.1p
Networking standards
IEEE 802.3at
Networking standards
IEEE 802.1D
Networking standards
IEEE 802.3ab
Networking standards
IEEE 802.1s
Networking standards
IEEE 802.3af
Networking standards
IEEE 802.1x
Networking standards
IEEE 802.3ad
Networking standards
IEEE 802.1w
Port/Expansion Slot Details
8 x Gigabit Ethernet PoE+
Port/Expansion Slot Details
2 x Gigabit Ethernet Network
Port/Expansion Slot Details
2 x 10 Gigabit Ethernet Expansion Slot
Power source
Power Supply
Product color
Gray
Product Family
Catalyst 9200
Product Line
Catalyst
Product Model
C9200CX-8P-2X2G
Product Name
Catalyst C9200CX-8P-2X2G Ethernet Switch
Product Series
9200
Product Type
Ethernet Switch
Weight (Approximate)
6.60 lb
Width
10.6"
