Tripp Lite PDU 3-Phase Metered 208/120V 5.7 Kw 36 C13; 6 C19; 6 5-15/20R 0U
Tripp Lite PDU 3-Phase Metered 208/120V 5.7 Kw 36 C13; 6 C19; 6 5-15/20R 0U - 36 x IEC 60320 C13, 6 x IEC 60320 C19, 6 x NEMA 5-15/20R - 5.70 kVA - Vertical Rackmount, Toolless-mount"
| $537.97 | Retail $791.86 |
- Metered 5.7kW 3 Phase 208/120V PDU; 70 in. / 178cm 0U vertical rackmount
- Reports input current per-phase via built in current meters
- NEMA L21-20P (3P+N+E) 208V 3 phase input; 6 ft. / 1.8m line cord
- 48 outlets total; 36 C13 (208V), 6 C19 (208V) & 6 NEMA 5-15/20R (120V)
- Toolless button-mount installation; cord retention brackets included
- TAA Compliant
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
60887
Item:
PDU3MV6L2120
UPC Code:
037332163929
Our Part #
PK7845
Condition
New
$537.97EA
$791.86
$791.86
Availability
Only 74 Left In Stock
Product description
Tripp Lite PDU 3-Phase Metered 208/120V 5.7 Kw 36 C13; 6 C19; 6 5-15/20R 0U - 36 x IEC 60320 C13, 6 x IEC 60320 C19, 6 x NEMA 5-15/20R - 5.70 kVA - Vertical Rackmount, Toolless-mount"
36 x IEC 60320 C13, 6 x IEC 60320 C19, 6 x NEMA 5-15/20R - 5.70 kVA - Vertical Rackmount, Toolless-mount"
Specifications
Mounting Orientation
Vertical
Power Rating (Watt)
5700 W
Receptacle Detail
6 x NEMA 5-15/20R
Receptacle Detail
6 x IEC 60320 C19
Receptacle Detail
36 x IEC 60320 C13
UPC Alternates
037332163929 742712005286
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
2.2"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
70"
Input voltage
230 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDU3MV6L2120
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite 3 phase Metered PDU / Power Distribution Units offer real-time local reporting of current levels in amps via set of 3 built-in digital meters. Enables visual monitoring of PDU current levels to preserve proper loading balance and prevent circuit overloads as additional equipment is added. Offers reliable rackmount multi-outlet power distribution from any protected UPS generator or mains input power source. High quality design includes rugged all-metal housing and secure rackmount installation with included mounting accessories.
Mount Type
Rack-mountable
Output voltage
208 V AC
Output voltage
120 V AC
Package Contents
- Metered Rackmount PDU
- Cord Retention Brackets
- Rack Mounting Brackets
- User Manual
Plug/Connector Type
NEMA L21-20P
Product Name
3-Phase Metered PDU
Product Series
Metered
Product Type
PDU
Receptacle Type
IEC 60320 C13
Receptacle Type
NEMA 5-15/20R
Receptacle Type
IEC 60320 C19
Weight (Approximate)
12.60 lb
Width
1.9"
