APC by Schneider Electric ACF201BLK Rack Side Air Distribution System
APC by Schneider Electric ACF201BLK Rack Side Air Distribution System - 260 CFM - Rack-mountable - Black - IT - Black - 2U - 120 V DC - 150 W
| $849.25 | Retail $974.00 |
- Air turning vane - Directs air up or down the side of the rack, supplying cool air to the inlet of side-to-side airflow equipment.
- |Dual fans - Provides fault tolerance in the event of a fan failure.
- |Fan control switches - Users can turn one or both fans on and off depending on the heat load.
- |Fan guards - A safety measure that provides protection from the fan opening by covering the inlet.
- |Mounting rails - Adjustable depth allows the unit to fit APC NetShelter enclosures or other 19"" EIA-310-D enclosures.
- |Resettable circuit breakers - Enables a quick recovery from overload events.
By:
APC by Schneider Electric
Manufacturer:
Schneider Electric Sa
Product ID:
61796
Item:
ACF201BLK
UPC Code:
731304227007
Our Part #
F94355
Condition
New
$849.25EA
$974.00
$974.00
Availability
Only 17 Left In Stock
Product description
APC by Schneider Electric ACF201BLK Rack Side Air Distribution System - 260 CFM - Rack-mountable - Black - IT - Black - 2U - 120 V DC - 150 W
260 CFM - Rack-mountable - Black - IT - Black - 2U - 120 V DC - 150 W
Specifications
Compatible Rack Height
2U
Indicators & Controls
Power On/Off
UPC Alternates
731304227007
Application/Usage
IT
Brand Name
APC by Schneider Electric
Certifications & Standards
UL
Depth
26.3"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Rack-mountable
Height
3.4"
Input voltage
120 V DC
Limited Warranty
2 Year
Manufacturer
Schneider Electric SA
Manufacturer Part Number
ACF201BLK
Manufacturer Website Address
http://www.schneider-electric.com
Marketing Information
Housing equipment with side to side airflow creates many challenges for IT and facility managers particularly in regards to cooling. Because most enclosures are designed for a front to back airflow pattern it is difficult to maintain ideal operating temperatures on side to side airflow equipment. The Rack Side Air Distribution Unit is a 2U rack mountable air distribution product for networking equipment or servers with side to side airflow. It pulls in conditioned air from the front of the rack and distributes it to the side air intake of the networking equipment.
Maximum Air Flow
260 CFM
Package Contents
- ACF201BLK Rack Side Air Distribution System
- Installation Guide
- Rack Mounting Brackets
- User Manual
Plug Type
NEMA 5-15P
Power consumption
150 W
Product color
Black
Product Name
ACF201BLK Rack Side Air Distribution System
Product Type
Airflow Cooling System
Weight (Approximate)
32.10 lb
Width
17"
