NVIDIA MCX653106A-HDAT-SP ConnectX-6 VPI Adapter Card HDR/200GbE
NVIDIA MCX653106A-HDAT-SP ConnectX-6 VPI Adapter Card HDR/200GbE - PCI Express 4.0 x16 - 2 Port(s) - Optical Fiber - QSFP56
| $2,026.86 |
- Up to 200Gb/s connectivity per port
- Max bandwidth of 200Gb/s
- Up to 215 million messages/sec
- Sub 0.6usec latency
- Block-level XTS-AES mode hardware encryption
- FIPS capable
- Advanced storage capabilities including block-level encryption and checksum offloads
- Supports both 50G SerDes (PAM4) and 25G SerDes (NRZ) based ports
- Best-in-class packet pacing with sub-nanosecond accuracy
- PCIe Gen 3.0 and Gen 4.0 support
- RoHS compliant
- ODCC compatible
By:
NVIDIA
Manufacturer:
Mellanox Technologies Ltd
Product ID:
69206
Item:
MCX653106A-HDAT-SP
Our Part #
7AD901
Condition
New
$2,026.86EA
Availability
Only 330 Left In Stock
You may be also interested
Product description
NVIDIA MCX653106A-HDAT-SP ConnectX-6 VPI Adapter Card HDR/200GbE - PCI Express 4.0 x16 - 2 Port(s) - Optical Fiber - QSFP56
PCI Express 4.0 x16 - 2 Port(s) - Optical Fiber - QSFP56
Specifications
Brand Name
NVIDIA
Environmental Certification
RoHS
Environmentally Friendly
Yes
Expansion Slot Type
QSFP56
Host interface
PCI Express 4.0 x16
Limited Warranty
1 Year
Manufacturer
Mellanox Technologies Ltd
Manufacturer Part Number
MCX653106A-HDAT-SP
Manufacturer Website Address
http://www.mellanox.com
Marketing Information
NVIDIA MCX653106A-HDAT-SP ConnectX-6 VPI Adapter Card HDR InfiniBand and 200GbE Dual-Port QSFP56 PCIe 4.0 x16 Tall Bracket (-SP indicates Single Pack)
ConnectX-6 VPI Card 200Gb/s InfiniBand & Ethernet Adapter Card
ConnectX-6 Virtual Protocol Interconnect (VPI) cards are a groundbreaking addition to the ConnectX series of industry-leading network adapter cards. Providing two ports of 200Gb/s for InfiniBand and Ethernet connectivity sub-600ns latency and 215 million messages per second ConnectX-6 VPI cards enable the highest performance and most flexible solution aimed at meeting the continually growing demands of data center applications. In addition to all the existing innovative features of past versions ConnectX-6 cards offer a number of enhancements to further improve performance and scalability.
ConnectX-6 VPI supports HDR HDR100 EDR FDR QDR DDR and SDR InfiniBand speeds as well as 200 100 50 40 25 and 10Gb/s Ethernet speeds.
Media Type Supported
Optical Fiber
Packaged Quantity
1
Product Line
ConnectX-6 VPI
Product Name
MCX653106A-HDAT-SP ConnectX-6 VPI Adapter Card HDR/200GbE
Product Type
200Gigabit Ethernet Card
Total Number of Ports
2
