TP-Link TL-SG1008MP - 8-Port Gigabit PoE Switch - Limited Lifetime Protection
TP-Link TL-SG1008MP - 8-Port Gigabit PoE Switch - Limited Lifetime Protection - 8 PoE+ Ports @153W - Rackmount - Plug & Play - Sturdy Metal - Shielded Ports - Overload Protection w/ Port Priority
| $123.38 |
- Flexible Full Gigabit 8-Port PoE Configuration - 8x PoE+ (802.3at/af) 10/100/1000 Mbps RJ45 ports providing up to 30W per port and total PoE power budget of153W.
- Plug and Play - Easy setup with no software installation or configuration needed.
- Overload Protection with Port Priority - When connected devices' total power consumption is greater than or equal to 153W, lower priority ports are disabled to prevent overloading.
- Sturdy Metal Case - Durable metal casing and desktop/rackmount design are well-suited for different environments.
- Reliable Data Transfer - IEEE 802.3X flow control provides reliable data transfer.
By:
TP-Link
Manufacturer:
TP-LINK Technologies Co., Ltd
Product ID:
72619
Item:
TL-SG1008MP
UPC Code:
840030700057
Our Part #
6TC200
Condition
New
$123.38EA
Availability
Only 91 Left In Stock
Product description
TP-Link TL-SG1008MP - 8-Port Gigabit PoE Switch - Limited Lifetime Protection - 8 PoE+ Ports @153W - Rackmount - Plug & Play - Sturdy Metal - Shielded Ports - Overload Protection w/ Port Priority
8 PoE+ Ports @153W - Rackmount - Plug & Play - Sturdy Metal - Shielded Ports - Overload Protection w/ Port Priority
Specifications
PoE Budget
126 W
Total Number of Network Ports
8
UPC Alternates
840030700057
Brand Name
TP-Link
Country of origin
China
Depth
7.1"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
Gigabit Ethernet
Form factor
Desktop
Form factor
Rack-mountable
Frequency
50 Hz
Frequency
60 Hz
Height
1.7"
Input voltage
230 V AC
Input voltage
120 V AC
Layer Supported
2
Limited Warranty
2 Year
Manageable
No
Manufacturer
TP-LINK Technologies Co. Ltd
Manufacturer Part Number
TL-SG1008MP
Manufacturer Website Address
http://www.tp-link.com/us
Marketing Information
What This Product Does
The TL-SG1008MP is an 8-Port Gigabit Desktop/Rack mountable Switch with all 8 ports supporting the PoE+ standard. It provides a simple way to expand a wired network by transferring power and data over a single Ethernet Cable. With a total power budget of 126W up to 30W per port TL-SG1008MP can power more high-powered devices such as wireless Access Points (APs) IP Cameras or IP Phones. Moreover with innovative energy-efficient technology the TL-SG1008MP can save up to 75% of the power consumption making it an eco-friendly solution for your business network.
How This Product Works
All 8 ports of TL-SG1008MP support Power over Ethernet Plus (PoE+) standard which can automatically detect and supply power to any IEEE 802.3af/at compliant device(s). In this situation the electrical power is transmitted along with data in a single cable allowing you to expand your network where there are no electrical cables or outlets where you wish to fix devices such as APs IP Cameras or IP Phones.
Overload Arrangement
TL-SG1008MP has a priority function which helps protect the system when its power is overloaded. If all PoE+ devices' power consumption is greater than or equal to 126W a priority will be arranged among the 8 PoE+ ports at which point the system will cut off the power of the lowest-priority port.
Port Priority Function
Priority (port 1 > port 2 > port 3 > port 4 > port 5 > port 6 > port 7 > port 8): This function helps protect the system if the power becomes overloaded. For example if port 1 2 4 and 7 are using 30W (maximum power per port is 30W the system power is 126W in total) and there is an additional device inserted into Port 3 at 25W the system will cut off the power of Port 7 in response to the power exceeding the 126W limit. This means Port 1 2 and 4 will use 30W and Port 3 will use 25W with no power will be supplied to Port 7 as it has the lowest designated priority among the ports in use.
Easy To Use
TL-SG1008MP is easy to install and use. It requires no configuration or installation. With its Desktop/Rack mountable design outstanding performance and quality the TP-Link TL-SG1008MP 8-Port Gigabit Desktop/Rack mountable Switch with 8-Port PoE is a great choice for expanding your home or office network.
Media Type Supported
Twisted Pair
Network Technology
1000Base-T
Networking standards
IEEE 802.3at
Networking standards
IEEE 802.3x
Networking standards
IEEE 802.3af
Package Contents
- 8-Port Gigabit Desktop/Rackmount Switch with 8-Port PoE+
- Power Cord
- Installation Guide
- Rackmount Kit
- Rubber Feet
Port/Expansion Slot Details
8 x Gigabit Ethernet PoE+
Power consumption
9.89 W
Power source
Power Supply
Product Name
8-Port Gigabit Desktop/Rackmount Switch with 8-Port PoE+
Product Type
Ethernet Switch
Width
11.6"
