Tripp Lite 1M Duplex Multimode 50/125 Fiber Optic Patch Cable LC/SC 3' 3ft 1 Meter
Tripp Lite 1M Duplex Multimode 50/125 Fiber Optic Patch Cable LC/SC 3' 3ft 1 Meter - LC Male - SC Male - 3.28ft
| $10.45 | Retail $15.52 |
- Premium PVC 50/125 multimode patch cables
- Attenuation loss meets or exceeds the latest industry standards
- Higher bandwidth optimized for Gigabit and 10Gbps networks
- Backward compatible with 62.5 micron fiber
- Built-in headroom for future applications
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
75073
Item:
N516-01M
UPC Code:
011411563169
Our Part #
C18292
Condition
New
$10.45EA
$15.52
$15.52
Availability
Only 373 Left In Stock
Product description
Tripp Lite 1M Duplex Multimode 50/125 Fiber Optic Patch Cable LC/SC 3' 3ft 1 Meter - LC Male - SC Male - 3.28ft
LC Male - SC Male - 3.28ft
Specifications
UPC Alternates
011411563169 037332119605
Additional Information
- Fiber type: all glass graded index
- Core diameter: two 50+/-3 microns
- CLAD diameter: 125+/-2 microns
- Primary coating diameter: 245+/-15 microns
- Primary coating material: acrylate
- Secondary coating diameter: 900+/-50 microns
- Attenuation @850NM: 3.5DB/KM maximum @1300NM: 1.0DB/KM maximum
- Bandwidth @850NM: 220 MHz-KM minimum @1300NM: 600 MHz-KM minimum
- Numeric apeture: .275 nominal
- Proof test level: 100000 PSI
- Insertion loss testing performed on every connector (0.2db typical) and provided with cable
Brand Name
Tripp Lite
Cable Characteristic
Patch Cable
Cable length
3.30 ft
Cable type
Fiber Optic
Certifications & Standards
- FDDI
Connector on First End
2 x LC Male
Connector on First End
LC Male
Connector on Second End
2 x SC Male
Connector on Second End
SC Male
Country of origin
China
Jacket Type
Plenum
Limited Warranty
Lifetime
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
N516-01M
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite's 1-meter multimode duplex Fibre Channel SC/LC patch cable is manufactured from 50/125 zipcord fiber. The cable has SC connectors on one end and LC at the other a PVC jacket and is FDDI and OFNR rated. 50/125 Duplex multimode fiber is most commonly used in Fibre Channel applications. It is backward compatible with 62.5 micron fiber and built-in headroom for future applications. The cable provides higher bandwidth optimized for Gigabit and 10Gbps networks as well. Also available in 2 3 5 10 15 20 30 and 50 meter lengths. Search "N516-" to bring up all lengths. Also search "N506-" for SC-SC cables and "N520-" for LC-LC cables. Tripp Lite warrants this product to be free from defects in materials and workmanship for life.
Package Contents
- Duplex Fiber Optic Patch Cable
- 1M duplex MMF cable LC/SC 50/125 fiber
Product Name
Duplex Fiber Optic Patch Cable
Product Type
Network Cable
