Tripp Lite 5M Duplex Multimode 50/125 Fiber Optic Patch Cable LC/SC 16' 16ft 5 Meter
Tripp Lite 5M Duplex Multimode 50/125 Fiber Optic Patch Cable LC/SC 16' 16ft 5 Meter - LC Male - SC Male - 16.4ft
| $14.36 | Retail $20.80 |
- Premium PVC 50/125 multimode patch cables
- Attenuation loss meets or exceeds the latest industry standards
- Higher bandwidth optimized for gigabit and 10Gbps networks
- Backward compatible with 62.5 micron fiber
- Built-in headroom for future applications
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
75075
Item:
N516-05M
UPC Code:
037332119568
Our Part #
C18294
Condition
New
$14.36EA
$20.80
$20.80
Availability
Only 159 Left In Stock
You may be also interested
Product description
Tripp Lite 5M Duplex Multimode 50/125 Fiber Optic Patch Cable LC/SC 16' 16ft 5 Meter - LC Male - SC Male - 16.4ft
LC Male - SC Male - 16.4ft
Specifications
Connector on First End Details
2 x LC - Male
Connector on Second End Details
2 x SC Network - Male
Connector Type on First End
LC - Male
Connector Type on Second End
SC Network - Male
UPC Alternates
037332119568
Additional Information
- Fiber type: all glass graded index
- Core diameter: two 50+/-3 microns
- CLAD diameter: 125+/-2 microns
- Primary coating diameter: 245+/-15 microns
- Primary coating material: acrylate
- Secondary coating diameter: 900+/-50 microns
- Attenuation @850NM: 3.5DB/KM maximum @1300NM: 1.0DB/KM maximum
- Bandwidth @850NM: 220 MHz-KM minimum @1300NM: 600 MHz-KM minimum
- Numeric apeture: .275 nominal
- Proof test level: 100000 PSI
- Insertion loss testing performed on every connector (0.2db typical) and provided with cable
- Beveled edge on ends of glass makes insertion of plug a breeze
Brand Name
Tripp Lite
Cable Characteristic
Patch Cable
Cable length
16.40 ft
Cable type
Fiber Optic
Certifications & Standards
- OFNR(riser rated)
- FDDI
Connector on First End
LC Male
Connector on First End
2 x LC Male
Connector on Second End
2 x SC Male
Connector on Second End
SC Male
Country of origin
China
Jacket Type
Plenum
Limited Warranty
Lifetime
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
N516-05M
Manufacturer Part Number
N51605M
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite's 5-meter multimode duplex Fibre Channel SC/LC patch cable is manufactured from 50/125 zipcord fiber. The cable has SC connectors on one end and LC at the other a PVC jacket and is FDDI and OFNR rated. 50/125 Duplex multimode fiber is most commonly used in Fibre Channel applications. It is backward compatible with 62.5 micron fiber and built-in headroom for future applications. The cable provides higher bandwidth optimized for Gigabit and 10Gbps networks as well. Also available in 1 2 3 10 15 20 30 and 50 meter lengths. Search "N516-" to bring up all lengths. Also search "N506-" for SC-SC cables and "N520-" for LC-LC cables. Tripp Lite warrants this product to be free from defects in materials and workmanship for life.
Package Contents
- Duplex Fibre Channel Patch Cable
- 5M duplex MMF cable LC/SC 50/125 fiber
Product Model
N516-05M
Product Name
Duplex Fibre Channel Patch Cable
Product Type
Network Cable
