Tripp Lite PDU Monitored 5/5.8kW 208/240V, 20 C13 4 C19, LX Platform Interface, 0URM Rackmount Vertical TAA
Tripp Lite PDU Monitored 5/5.8kW 208/240V, 20 C13 4 C19, LX Platform Interface, 0URM Rackmount Vertical TAA - Monitored - NEMA L6-30P - 20 x IEC 60320 C13, 4 x IEC 60320 C19 - 230 V AC - 5800 VA - 0U - Vertical - Rack Mount - TAA Compliant
| $428.13 | Retail $947.24 |
- 5/5.8kW 208/240V 30A monitored PDU
- 24 outlets-20 C13, 4 C19-with cord retention brackets
- NEMA L6-30P input with 10 ft. AC power cord
- Digital ammeter for on-site load monitoring in real time
- Built-in LX Platform interface for remote access
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
78940
Item:
PDUMNV30HVLX
UPC Code:
037332204479
Our Part #
2DA021
Condition
New
$428.13EA
$947.24
$947.24
Availability
Only 10109 Left In Stock
Product description
Tripp Lite PDU Monitored 5/5.8kW 208/240V, 20 C13 4 C19, LX Platform Interface, 0URM Rackmount Vertical TAA - Monitored - NEMA L6-30P - 20 x IEC 60320 C13, 4 x IEC 60320 C19 - 230 V AC - 5800 VA - 0U - Vertical - Rack Mount - TAA Compliant
Monitored - NEMA L6-30P - 20 x IEC 60320 C13, 4 x IEC 60320 C19 - 230 V AC - 5800 VA - 0U - Vertical - Rack Mount - TAA Compliant
Specifications
Mounting Orientation
Vertical
PDU Type
Monitored
Phase
Single Phase
Power Rating (Watt)
5800 W
Receptacle Detail
4 x IEC 60320 C19
Receptacle Detail
20 x IEC 60320 C13
UPC Alternates
037332204479 818216968621
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
2.7"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
70"
Input current
30 A
Input voltage
230 V AC
Input Voltage Range
200 V AC - 240 V AC
Limited Warranty
2 Year
Management
- HTTP
- HTTPS
- SNMPv1
- SNMPv2
- SNMPv3
- telnet
- SSH
- FTP
- DHCP
- NTP
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUMNV30HVLX
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
The PDUMNV30HVLX 5.8kW Single-Phase Monitored PDU provides real-time remote monitoring of voltage frequency and load levels via built-in network connection. Recommended for any IT or industrial application it features 24 outlets (20 C13 and 4 C19) with included cord retention brackets to prevent cables from becoming accidentally disconnected. A 10-foot cord with NEMA L6-30P plug connects the PDU to a compatible AC power source generator or protected UPS.
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities. Protocols supported include HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP.
A digital ammeter allows you to monitor each bank's load in real time to ensure it remains well below maximum capacity with no danger of overload. The PDU mounts in 0U of space in EIA-standard 19-inch racks using the included toolless mounting buttons or the included rack-mounting brackets. Use the included PDUMVROTATEBRKT kit to install the unit with outlets facing the rear for better airflow or equipment access.
Mount Type
Rack-mountable
Output voltage
208 V AC
Output voltage
240 V AC
Output voltage
200 V AC
Package Contents
- PDUMNV30HVLX 5/5.8kW Single-Phase Monitored PDU
- Configuration cable
- 24 x Cable ties
- 2 x Cord retention brackets
- Rack-mounting hardware
- PDUMVROTATEBRKT mounting bracket accessory
- Owner's manual
Plug/Connector Type
NEMA L6-30P
Product Name
PDUMNV30HVLX 5/5.8kW Single-Phase Monitored PDU
Product Type
PDU
Rack Height
0U
Receptacle Type
IEC 60320 C19
Receptacle Type
IEC 60320 C13
Weight (Approximate)
11.50 lb
Width
2.2"
