Elo 1790L 17" Open-frame LCD Touchscreen Monitor - 5:4 - 5 ms

Elo 1790L 17" Open-frame LCD Touchscreen Monitor - 5:4 - 5 ms - 17" Class - 5-wire Resistive - 1280 x 1024 - SXGA - 16.7 Million Colors - 800:1 - 250 Nit - LED Backlight - HDMI - USB - VGA - DisplayPort - Black - T�V, RoHS, China RoHS, WEEE - 3 Year
$752.66
  • Explore a world loaded with potentially vivid entertainment outcomes with the Elo Open-frame LCD Touchscreen Monitor
  • LED backlight technology provides for industry-leading low power consumption and less hazardous materials
  • The 800:1 contrast ratio produces enhanced sharpness and shading accuracy in each picture
  • Furnishes captivating visuals with about 250 Nit brightness levels
  • HDMI interface allows connectivity to a variety of HD devices including gaming consoles, laptop PCs, Blu-ray players, digital cameras and many others for the ultimate high-definition display
By:
Elo
Manufacturer:
Elo Touch Solutions, Inc
Product ID:
95924
Item:
E326347
UPC Code:
060678814026
Our Part #
3GU942
Condition
New
$752.66EA
Availability Only 10 Left In Stock
Great Deals Everyday

You may be also interested

Product description

Elo 1790L 17" Open-frame LCD Touchscreen Monitor - 5:4 - 5 ms - 17" Class - 5-wire Resistive - 1280 x 1024 - SXGA - 16.7 Million Colors - 800:1 - 250 Nit - LED Backlight - HDMI - USB - VGA - DisplayPort - Black - T�V, RoHS, China RoHS, WEEE - 3 Year
17" Class - 5-wire Resistive - 1280 x 1024 - SXGA - 16.7 Million Colors - 800:1 - 250 Nit - LED Backlight - HDMI - USB - VGA - DisplayPort - Black - T�V, RoHS, China RoHS, WEEE - 3 Year

Specifications

Touchscreen Type
5-wire Resistive
UPC Alternates
060678814026 657379367212 815335025792 818213927034 818214097477 818214448477 818239806900
UPC Alternates
060678814026 657379367212 815335025792 818213927034
Aspect ratio
5:4
Backlight Technology
LED
Brand Name
Elo
Brightness
250 Nit
Certifications & Standards
  • T�V
  • Color Supported
    16.7 Million Colors
    Contrast Ratio
    800:1
    Depth
    1.9"
    Environmental Certification
    China RoHS
    Environmental Certification
    WEEE
    Environmental Certification
    T�V
    Environmental Certification
    RoHS
    Environmentally Friendly
    Yes
    Height
    12.1"
    Limited Warranty
    3 Year
    Manufacturer
    Elo Touch Solutions Inc
    Manufacturer Part Number
    E326347
    Manufacturer Website Address
    http://www.elotouch.com
    Marketing Information

    The Elo 1790L 17-inch open-frame LCD touch display features a slim design and narrow outside dimensions thanks to the state-of-the-art energy-saving LED backlight using less electricity to operate and generating less heat. This compact touch display is designed for touch with proven Elo expertise and reliability built in. The 1790L provides stable drift-free operation with outstanding image clarity and light transmission-for accurate touch responses and vivid images. Instantly grabbing and holding users' attention the 17-inch open frame is perfect for kiosks casino and amusement retail self-service and industrial automation environments.

    Easily integrated.

    The touchscreen is sealed against dirt dust and liquids which simplifies integration into the final enclosure. Projected capacitive (PCAP) units can be sealed into a solution and obtain an IP65 rating on the front side of the unit. With the design and tooling being controlled by Elo long-lasting product availability can be expected.

    Touch ready.

    The 1790L is available with a choice of industry-leading touch technologies in both single touch and multi touch versions. The seamless zero-bezel 17-inch multi-touch display is available with our latest multi-touch TouchPro™ PCAP two-glass solution (2GS) technology has a zero-bezel that delivers both a 10-touch tablet-like experience along with two-touch thru-glass functionality-both modes support single or dual latex gloves as well as cloth gloves. Standard bezel single-touch display options include AccuTouch® five-wire resistive IntelliTouch® SAW or SecureTouch® anti-vandal SAW.

    Commercial-grade.

    The Elo open frame touchscreen display delivers the quality and reliability Elo is known for and is backed by our three-year standard warranty. We design build and are responsible for the complete solution with touch integrated from the start. Using our own touchscreens combined with our software and drivers everything is designed to work together and is tested as part of our life testing processes. All of our products go through rigorous reliability testing (over 20 tests) to deliver 50000 MTBF.

    Other features.
    • Projected capacitive (PCAP) two glass solution (2GS) offers pristine optical clarity and touch durability that passes UL-60950 & IK-07 impact testing
    • High quality energy-saving LED panel
    • 10-touch TouchPro projected capacitive (PCAP) with two-touch thru-glass capabilities
    • Display Port and VGA video interfaces
    Maximum resolution
    1280 x 1024
    Mount Type
    Front Mount
    Mount Type
    Rack-mountable
    Operating Power Consumption
    17.80 W
    Package Contents
    • 1790L 17" Open Frame Touchscreen (Rev B)
    • HDMI cable
    • VGA Cable
    • RJ45 OSD Remote
    • Touch USB Cable
    • User Manual CD
    • Quick Install Guide
    • "L" (Side Mount) Brackets and w/Screws
    • Japan Class-B info sheet
    Product color
    Black
    Product Model
    1790L
    Product Name
    1790L 17" Open Frame Touchscreen (Rev B)
    Product Type
    Open-frame LCD Touchscreen Monitor
    Response time
    5 ms
    Screen Mode
    SXGA
    Viewable Screen Size
    17"
    Weight (Approximate)
    7.94 lb
    Width
    14.5"
