Tripp Lite N845X-03M-8L-MG Fiber Optic Duplex Trunk Network Cable
Tripp Lite N845X-03M-8L-MG Fiber Optic Duplex Trunk Network Cable - 9.84 ft Fiber Optic Network Cable for Network Device, Patch Panel, Switch - First End: 1 x MTP/MPO Female Network - Second End: 8 x LC Male Network - 100 Gbit/s - Trunk Cable - LSZH, OFNR - 50/125 µm - Magenta, Magenta, Black, Aqua - 1 Piece
| $159.30 | Retail $216.00 |
- OM4-rated cable recommended for 100 Gb speeds up to 100 meters (@ 850 nm)
- Switchable LC connectors allow polarity conversion without tools or re-termination
- Backward compatible with 10/25/40 Gb networks to facilitate future-proofing
- Magenta LSZH jacket allows easy ID in a crowded switch or patch panel
- This product is covered by a Lifetime Limited Warranty
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
100430
Item:
N845X-03M-8L-MG
UPC Code:
037332272331
Our Part #
01FX40
Condition
New
$159.30EA
$216.00
$216.00
Availability
Only 24 Left In Stock
You may be also interested
Product description
Tripp Lite N845X-03M-8L-MG Fiber Optic Duplex Trunk Network Cable - 9.84 ft Fiber Optic Network Cable for Network Device, Patch Panel, Switch - First End: 1 x MTP/MPO Female Network - Second End: 8 x LC Male Network - 100 Gbit/s - Trunk Cable - LSZH, OFNR - 50/125 µm - Magenta, Magenta, Black, Aqua - 1 Piece
9.84 ft Fiber Optic Network Cable for Network Device, Patch Panel, Switch - First End: 1 x MTP/MPO Female Network - Second End: 8 x LC Male Network - 100 Gbit/s - Trunk Cable - LSZH, OFNR - 50/125 µm - Magenta, Magenta, Black, Aqua - 1 Piece
Specifications
Boot Type
Slim
Connector Color
Black
Connector Color
Aqua
Connector on First End Details
1 x MTP/MPO Network - Female
Connector on Second End Details
8 x LC Network - Male
Connector Type on First End
MTP/MPO Network - Female
Connector Type on Second End
LC Network - Male
UPC Alternates
037332272331
Brand Name
Tripp Lite
Cable Characteristic
Trunk Cable
Cable length
9.84 ft
Cable type
Fiber Optic
Color
Black Connector
Color
Aqua Connector
Color
Black
Color
Magenta Jacket
Color
Aqua
Color
Magenta Connector
Color
Magenta
Connector on First End
MTP/MPO Female Network
Connector on First End
1 x MTP/MPO Female Network
Connector on Second End
LC Male Network
Connector on Second End
8 x LC Male Network
Core/Cladding Diameter
50/125 µm
Country of origin
China
Data transfer rate
100 Gbit/s
Device Supported
Network Device
Device Supported
Switch
Device Supported
Patch Panel
Environmental Certification
EcoLogo
Environmental Certification
REACH
Environmental Certification
RoHS
Environmentally Friendly
Yes
Features
Slim Boot
Features
Bendable
Features
Stranded
Features
Polished Connector (PC)
Features
Push-Pull Tab
Fiber Optic Mode
Multi-mode
Jacket Color
Magenta
Jacket Type
LSZH
Jacket Type
OFNR
Limited Warranty
Lifetime
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
N845X-03M-8L-MG
Manufacturer Part Number
N845X03M8LMG
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
40/100 GbE Cable Supports Higher Bandwidths Needed for High-Density Data Networking
As the amount of traffic in data networks grows so does the need for devices and fiber cables to support higher bandwidths for high-density patching between data center MDFs and IDFs in enterprise installations. This multimode 50/125 OM4 fan-out cable is an ideal choice for 100 Gb Ethernet applications up to 100 meters (328 feet) at 850 nm. It is also backward compatible with 10 Gb and 25 Gb networks so you can future-proof your current application for an eventual upgrade to 400 Gb.
Switchable LC Connectors Allow Easy Polarity Conversions
The switchable LC/PC duplex ends let you easily switch the fiber polarity without tools or the need to re-terminate the connectors. Use the detachable clip to keep the connectors in place while in use.
Magenta Jacket Helps Avoid Misidentification That Can Cause Costly Downtime
The OM4-rated cable has a magenta jacket to identify it as multimode in a crowded patch panel or switch and prevent it from becoming accidentally disconnected. The round low-smoke zero-halogen (LSZH) jacket limits the amount of toxic smoke emitted in case of combustion making it suitable for poorly ventilated areas. The connectors' slim boots allow easy one-handed installation and removal of the cable.
Packaged Quantity
1 Piece
Product Model
N845X-03M-8L-MG
Product Name
N845X-03M-8L-MG Fiber Optic Duplex Trunk Network Cable
Product Type
Network Cable
