TP-Link TL-FC111PB-20 - 10/100 Mbps WDM SFP to RJ45 Fiber to Ethernet Media Converter with 1-Port PoE
TP-Link TL-FC111PB-20 - 10/100 Mbps WDM SFP to RJ45 Fiber to Ethernet Media Converter with 1-Port PoE - 10/100 Mbps RJ45 Port to 100Base-FX Single-Mode Fiber - Extend Fiber Distance Up to 20 km
| $26.27 |
- Designed to convert 100BASE-FX SC fiber to 100Base-Tx copper media or vice versa.
- Auto-negotiation of Half-Duplex/Full-Duplex transfer mode. Supports auto MDI/MDIX for TX port.
- The 802.3af PoE output makes remote camera deployment easier and more convenient.
- TL-FC111PB-20 adopts WDM (wavelength division multiplexing) technology, helping send and receive data at a distance up to 20 km with only one single-mode fiber, which saves half of the cable deployment cost for customers compares to dual-fiber deployment.
- Wavelength: Tx 1310 nm, Rx 1550nm; Compatible TP-Link model: TL-FC111A-20.
By:
TP-Link
Manufacturer:
TP-LINK Technologies Co., Ltd
Product ID:
100452
Item:
TL-FC111PB-20
UPC Code:
840030703065
Our Part #
43201553
Condition
New
$26.27EA
Availability
Only 120 Left In Stock
Product description
TP-Link TL-FC111PB-20 - 10/100 Mbps WDM SFP to RJ45 Fiber to Ethernet Media Converter with 1-Port PoE - 10/100 Mbps RJ45 Port to 100Base-FX Single-Mode Fiber - Extend Fiber Distance Up to 20 km
10/100 Mbps RJ45 Port to 100Base-FX Single-Mode Fiber - Extend Fiber Distance Up to 20 km
Specifications
Fiber Mode Supported
Single-mode
Fiber Optic Cable Standard
9/125 µm
Fiber Optic Wavelength
1310 nm
Fiber Optic Wavelength
1550 nm
Maximum Distance Supported
12.43 Mile
Network (RJ-45)
Yes
Number of PoE (RJ-45) Ports
1
PoE Port Type
PSE
SC Port Type
Duplex
UPC Alternates
840030703065
Brand Name
TP-Link
Country of origin
China
Depth
2.9"
Ethernet Technology
Fast Ethernet
Form factor
Rack-mountable
Form factor
Standalone
Height
1.1"
Limited Warranty
2 Year
Manufacturer
TP-LINK Technologies Co. Ltd
Manufacturer Part Number
TL-FC111PB-20
Manufacturer Website Address
http://www.tp-link.com/us
Marketing Information
What This Product Does
TL-FC111PB-20 is a 10/100 Mbps media converter with 802.3af PoE output providing 1� 10/100 Mbps PoE RJ45 port and 1� 100 Mbps SC fiber port which can convert between electrical and optical signals. With up to 20 km fiber transmission distance and 802.3af PoE output the media converter is designed to address the needs of flexible long-range surveillance deployment with optical fibers. It provides an economical path towards extending the distance of an existing network.
How This Product Works
TL-FC111PB-20 adopts WDM (wavelength division multiplexing) technology helping send and receive data at a distance of up to 20 km with only a single mode fiber which saves half of the cable deployment cost for customers. TL-FC111PB-20 transmits data at 1310 nm wavelength and receives data at 1550 nm wavelength on optical fiber. Therefore the terminal device used in conjunction with the TL-FC111PB-20 should send data at a wavelength of 1550 nm and receive data at a wavelength of 1310 nm. TP-Link another media converter TL-FC111A-20 is one of the products that can cooperate with TL-FC111PB-20.
Other Features
Besides this media converter can be used as a standalone device (no rack required) or used with TP-Link's TL-FC1420 rack for auto MDI/MDI-X in TX port in which duplex mode is automatically negotiated.
Media Type Supported
Optical Fiber
Media Type Supported
Twisted Pair
Network Technology
10/100Base-T
Package Contents
- Media Converter TL-FC111PB-20
- Power Adapter
- Installation Guide
Power source
Power Adapter
Product Name
10/100Mbps WDM Media Converter with 1-Port PoE
Product Type
Transceiver/Media Converter
Total Number of Ports
2
Width
3.7"
