C2G 1m LC-LC 50/125 Duplex Multimode OM2 Fiber Cable - Orange - 3ft
C2G 1m LC-LC 50/125 Duplex Multimode OM2 Fiber Cable - Orange - 3ft - 1m LC-LC 50/125 Duplex Multimode OM2 Fiber Cable - Orange - 3ft
| $15.38 | Retail $30.99 |
- This Network Cable provides splendid performance and clear connectivity
- Features Fiber Optic cable type
- Features Molded
- 2 x LC Male Network offers a secure and reliable connection with a compatible network device
Manufacturer:
C2G
Product ID:
100671
Item:
33027
UPC Code:
132017654249
Our Part #
26121607
Condition
New
$15.38EA
$30.99
$30.99
Availability
Only 4 Left In Stock
Product description
C2G 1m LC-LC 50/125 Duplex Multimode OM2 Fiber Cable - Orange - 3ft - 1m LC-LC 50/125 Duplex Multimode OM2 Fiber Cable - Orange - 3ft
1m LC-LC 50/125 Duplex Multimode OM2 Fiber Cable - Orange - 3ft
Specifications
UPC Alternates
132017654249 757120330271 818216095679 993251426104
Additional Information
- Buffer material: PVC
- Buffer OD: 900 µm
- Jacket OD: 3.0 mm
- Jacket color: Orange
- Min. bandwidth @850 nm: 160 kHz/km
- Min. bandwidth @1310 nm: 500 kHz/km
- Attenuation @850 nm: 3.75 dB/km
- Attenuation @1310 nm: 1.5 dB/km
- Maximum tensile load: 100 N/cm
- Loaded min. bend radius: 5 cm
- Unloaded min. bend radius: 3 cm
- Crush resistance: 750 N/cm
- Impact resistance: 1000 cycles
- Flex resistance: 5000 cycles
Cable length
3.28 ft
Cable type
Fiber Optic
Color
Orange
Connector on First End
2 x LC Male Network
Connector on First End
LC Male Network
Core/Cladding Diameter
50/125 µm
Device Supported
Network Device
Environmental Certification
RoHS
Environmentally Friendly
Yes
Features
Impact Resistant
Features
Pull Resistant Connector
Features
Molded
Features
Crush Resistant
Features
Flex Resistant
Features
Strain Resistant
Fiber Optic Mode
Multi-mode
Jacket Type
Plenum
Limited Warranty
Lifetime
Manufacturer
C2G
Manufacturer Part Number
33027
Manufacturer Website Address
http://www.cablestogo.com
Marketing Information
Cost-effective solution that provides higher bandwidth and transmission rates and supports longer distances with lower loss than 62.5/125 fiber. Specifically designed for use with today's narrower aperture components this cable is fully compatible with multimode applications. The patented injection molding process provides each connection greater durability in resisting pulls strains and impacts from cabling installs.
Each cable is 100% optically inspected and tested for insertion loss before you receive it. A pull-proof jacket design surrounds the popular 50/125 multimode fiber immune to electrical interference.
Product Name
1m LC-LC 50/125 OM2 Duplex Multimode PVC Fiber Optic Cable - Orange
Product Type
Network Cable
