Black Box ServSwitch Wizard SRX DVI-D/USB Extender, Dual-Head
Black Box ServSwitch Wizard SRX DVI-D/USB Extender, Dual-Head - 1 Computer(s) - 1 Local User(s) - 196 ft Range - 3840 x 2400 Maximum Video Resolution - 4 x Network (RJ-45) - 6 x USB - 4 x DVI - Rack-mountable
| $1,911.34 | Retail $2,166.66 |
- Dual Head DVI-D Video Resolution 1920x1200 @60Hz
- Transparent USB 2.0 supports up to 60 meters
- Extended profile DDC EDID ensures optimal video with high-performance display devices
- Delivers bi-directional USB signals
- (2x) CATx connections
- Plug-and-play setup and supports Audio
By:
Black Box
Manufacturer:
Black Box Corporation
Product ID:
102490
Item:
ACU5502A-R3
UPC Code:
766796411955
Our Part #
UT2264
Condition
New
$1,911.34EA
$2,166.66
$2,166.66
Availability
Only 31 Left In Stock
Product description
Black Box ServSwitch Wizard SRX DVI-D/USB Extender, Dual-Head - 1 Computer(s) - 1 Local User(s) - 196 ft Range - 3840 x 2400 Maximum Video Resolution - 4 x Network (RJ-45) - 6 x USB - 4 x DVI - Rack-mountable
1 Computer(s) - 1 Local User(s) - 196 ft Range - 3840 x 2400 Maximum Video Resolution - 4 x Network (RJ-45) - 6 x USB - 4 x DVI - Rack-mountable
Specifications
Transmitter Depth
5"
Transmitter Height
2"
Transmitter Weight (Approximate)
4 lb
Transmitter Width
3.10"
UPC Alternates
766796411955 822088068341
Brand Name
Black Box
Certifications & Standards
CE
Connectivity technology
Wired
Country of origin
United Kingdom
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
Rack-mountable
Input voltage
110 V AC
Input voltage
220 V AC
Limited Warranty
2 Year
Manufacturer
Black Box Corporation
Manufacturer Part Number
ACU5502A-R3
Manufacturer Website Address
http://www.blackbox.com
Marketing Information
Purely digital for pure video
Because the extender delivers full DVI digital video without compression or conversion you get pure video displays with no loss of quality. The extender uses CAT6a cable to extend keyboard mouse and uncompressed single-link DVI-D video up to 196 feet (59.7 m) at full 1920 x 1200 at 60 Hz or 3840 x 2400 at 17 Hz resolution! It's ideal where you want to reduce environmental concerns such as heat and noise and ensure optimal temperature control.
Go the distance
You'll get different distances depending on what cable you use and if you make direct connections or patch panel connections.
Direct cable connections:
CAT6a: 196 feet (59.7 m)
CAT6: 180 feet (54.8 m)
CAT5e: 147 feet (44.8 m)
Patch Panel Connections
CAT6a: 164 feet (50 m)
CAT6: 147 feet (44.8 m)
CAT5e: 114 feet (34.7 m)
USB keyboard and mouse support
The extender also delivers bi-directional USB data enabling USB device extension over 196 feet (59.7 m) on the same CAT6a cable. This makes the extender ideal for distributed workstations where you want to reduce environmental concerns such as heat and noise such as in post-production suites. The extender supports a variety of USB keyboards and mice and other human interface devices (HIDs) such as touchscreens.
Extended profile DDC EDID
The Wizard DVI/USB carries extended profile DDC EDID data from your display device to the display adapter to ensure that your system is configured to deliver optimal video performance. The extended profile DDC EDID is particularly important when extending the video to high-performance display devices. This is essential for professional graphics users such as post-production broadcast architecture graphic design medical imaging CAD or any other applications where display performance is critical.
19" mounting
You can mount up to 16 local or remote units in the Rackmount Chassis for ServSwitch Wizard Extender (ACU5000A).
Interface-powered local unit
The local unit of the Wizard SRX can be interface powered if your attached PC outputs do not exceed 500 mA. Otherwise use the spare 5-VDC Power Supply (PS649-R3).
Maximum Operating Distance
196 ft
Maximum Video Resolution
3840 x 2400
Number of Computers Supported
1
Number of Network (RJ-45) Ports
4
Number of USB Ports
6
Package Contents
- 1 x Transmitter
- 1 x Receiver
- 2 x USB TYPE A/B M/M cable
- 2 x DVI-D M/M single link cable
- 1 x 3.5mm Audio Cable(
- 8 x Rubber Feet
- 1 x 5 VDC 2.5A 12.5W Power Supply
- 1 x Faceplate for mounting w/ (4) screws per plate
Product Line
ServSwitch
Product Name
ServSwitch Wizard SRX DVI-D/USB Extender Dual-Head
Product Type
KVM Console/Extender
