Black Box DB9 Mini Converter (USB to Serial), USB/RS-485 (4-wire, Terminal Block)
Black Box DB9 Mini Converter (USB to Serial), USB/RS-485 (4-wire, Terminal Block) - 1 x Type B USB 2.0 USB Female - 1 x 9-pin DB-9 RS-485 Serial - TAA Compliant
| $120.10 | Retail $129.95 |
- Use legacy serial devices with PC and laptop USB ports.
- Add a COM port to your PC or laptop.
- Supports USB 1.0, 1.1, and 2.0 (12 Mbps).
- Powered from the USB interface
- RS485 baud rates up to 921 Kbps.
By:
Black Box
Manufacturer:
Black Box Corporation
Product ID:
102512
Item:
IC833A
UPC Code:
700604198294
Our Part #
UP7693
Condition
New
$120.10EA
$129.95
$129.95
Availability
Only 12 Left In Stock
Product description
Black Box DB9 Mini Converter (USB to Serial), USB/RS-485 (4-wire, Terminal Block) - 1 x Type B USB 2.0 USB Female - 1 x 9-pin DB-9 RS-485 Serial - TAA Compliant
1 x Type B USB 2.0 USB Female - 1 x 9-pin DB-9 RS-485 Serial - TAA Compliant
Specifications
Connector on First End Details
1 x Type B USB 2.0 USB Female
Connector on Second End Details
1 x 9-pin DB-9 RS-485 Serial
Connector Type on First End
USB 2.0 Type B - Female
Connector Type on Second End
DB-9 RS-485 Serial
UPC Alternates
700604198294 783555097779 822088100379 999560702014
Adapter Type
Serial/USB
Brand Name
Black Box
Certifications & Standards
CE
Country of origin
United States
Depth
1.3"
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Height
0.6"
Limited Warranty
5 Year
Manufacturer
Black Box Corporation
Manufacturer Part Number
IC833A
Manufacturer Website Address
http://www.blackbox.com
Marketing Information
- Automatic configuration on Windows 98 ME 2000 XP and Vista systems.
- Powered from the USB interface.
- Includes 3-ft. (0.9 m) USB cable.
USB is the connectivity standard for today's PCs replacing familiar serial ports. However many commercial and industrial devices still use RS-232 RS-422 or RS-485 interfaces. To connect these devices to modern PCs you need simple and reliable converters.
The Black Box Mini USB-to-Serial Converter offer USB-to-serial conversion in a space saving package. Simply plug the converter into an available USB port on your computer or USB hub and install the drivers supplied on CD ROM. The serial device will show up as an additional COM port in the Windows Device Manager.
RS-485 (two- and four-wire)
- Support TDA TDB RDA RDB and GND.
- Baud rates up to 921 Kbps.
- Use on RS-485 2-wire or RS-422/485 4-wire networks.
- Support Send Data Control (SDC).
RS-232
- Full handshake support (TD RD RTS CTS DTR DSR DCD RI GND).
- Baud rates up to 460 Kbps.
Package Contents
- DB9 Mini Converter (USB to Serial) USB/RS-485 (4-wire Terminal Block)
- 1m USB Cable
Product Name
DB9 Mini Converter (USB to Serial) USB/RS-485 (4-wire Terminal Block)
Product Type
Data Transfer Adapter
Width
2.3"
