Panorama Antennas 4G LTE and GPS In-Vehicle Antenna
Panorama Antennas 4G LTE and GPS In-Vehicle Antenna - 698 MHz to 960 MHz, 1562 MHz to 1612 MHz, 1710 MHz to 2700 MHz - 4 dBi - Cellular Network, Vehicle, GPS - Black - Omni-directional - SMA Connector
| $51.36 | Retail $59.85 |
- Dashboard or Windshield Mount
- Cellular/LTE and GPS/GNSS
- Suitable for M3 category Vehicles (UNECE Reg 118)
- Available with SMA or FAKRA connectors
By:
Panorama Antennas
Manufacturer:
Panorama Antennas Ltd
Product ID:
104233
Item:
GPSC-7-27-3SP
Our Part #
6DC629
Condition
New
$51.36EA
$59.85
$59.85
Availability
Only 370 Left In Stock
Product description
Panorama Antennas 4G LTE and GPS In-Vehicle Antenna - 698 MHz to 960 MHz, 1562 MHz to 1612 MHz, 1710 MHz to 2700 MHz - 4 dBi - Cellular Network, Vehicle, GPS - Black - Omni-directional - SMA Connector
698 MHz to 960 MHz, 1562 MHz to 1612 MHz, 1710 MHz to 2700 MHz - 4 dBi - Cellular Network, Vehicle, GPS - Black - Omni-directional - SMA Connector
Specifications
Antenna Gain
4 dBi
Directivity
Omni-directional
Operating Frequency Range
1710 MHz to 2700 MHz
Operating Frequency Range
1562 MHz to 1612 MHz
Operating Frequency Range
698 MHz to 960 MHz
Application/Usage
GPS
Application/Usage
Cellular Network
Application/Usage
Vehicle
Brand Name
Panorama Antennas
Connector Type
SMA
Depth
2.70"
Height
0.60"
Manufacturer
Panorama Antennas Ltd
Manufacturer Part Number
GPSC-7-27-3SP
Manufacturer Website Address
http://www.panorama-antennas.com
Marketing Information
The GPSC-7-27 range of telematics antennas offers a "2-in-2" product for vehicle communications and telematics. The housing incorporates antennas for cellular/LTE and GPS/GLONASS with a 26dB gain LNA.
Meeting the requirements of UNECE regulation R 118 the antenna is suitable for use in the M3 category of vehicles (transportation). The antenna housing is UV resistant while the 3m length integrated coax cables are flame retardant low smoke specification.
The antenna offers easy and quick installation on/under the dashboard or on the windshield using the supplied acrylic adhesive pad (performance may change depending on mounting position/surface and the product should not be mounted on conductive surfaces or metalized glass).
Package Contents
- 4G LTE and GPS In-Vehicle Antenna
- Acrylic Adhesive Pad
Product color
Black
Product Name
4G LTE and GPS In-Vehicle Antenna
Product Type
Antenna
Weight (Approximate)
4.59 oz
Width
2.90"
