Minuteman 1500 VA On-line Tower UPS with 6 0utlets
Minuteman 1500 VA On-line Tower UPS with 6 0utlets - Tower - 5 Minute Stand-by - 120 V AC Input - 110 V AC, 120 V AC, 127 V AC Output - 6 x NEMA 5-15R
| $1,041.08 | Retail $1,115.00 |
- True on-line, double-conversion technology
- Easy-to-read LCD display
- 0.9 output power factor
- Highly-efficient, Economy Mode option
- Output receptacle control with 2 banks
- Extended runtime capable
- Independent Battery Bypass - allows the UPS to provide voltage regulation and spike/surge protection either with dead batteries or without batteries
- Hot-swappable battery replacement
- Cold Start capable
- Automatic internal bypass
By:
Minuteman
Manufacturer:
Para Systems, Inc
Product ID:
106347
Item:
EC1500LCD
UPC Code:
784755155382
Our Part #
5XD103
Condition
New
$1,041.08EA
$1,115.00
$1,115.00
Availability
Only 77 Left In Stock
Product description
Minuteman 1500 VA On-line Tower UPS with 6 0utlets - Tower - 5 Minute Stand-by - 120 V AC Input - 110 V AC, 120 V AC, 127 V AC Output - 6 x NEMA 5-15R
Tower - 5 Minute Stand-by - 120 V AC Input - 110 V AC, 120 V AC, 127 V AC Output - 6 x NEMA 5-15R
Specifications
Load Capacity (VA)
1500 VA
Load Capacity (W)
1350 W
Maximum Operating Elevation
10000 ft
Maximum Storage Elevation
50000 ft
Operating Humidity
10% - 90%
Output Frequency
60 Hz
Receptacle Detail
6 x NEMA 5-15R
Storage Temperature
14°F (-10°C) - 122°F (50°C)
UPC Alternates
784755155382
Waveform Type
Pure Sine Wave
Application/Usage
Medical
Application/Usage
Security System
Application/Usage
Server
Application/Usage
Electronic Device
Application/Usage
Voice/Data Network
Application/Usage
Education
Application/Usage
Healthcare
Application/Usage
Network
Application/Usage
Lab Equipment
Backup/Run Time (Full Load)
5 Minute
Backup/Run Time (Half Load)
15 Minute
Battery Characteristics
Sealed Non-spillable Maintenance-free
Battery Chemistry
Lead Acid
Brand Name
Minuteman
Dataline Protection
RJ-45
Dataline Protection
RJ-11
Depth
17.4"
Environmental Certification
RoHS 2
Form factor
Tower
Height
11.4"
Hot Swappable
Yes
Input voltage
120 V AC
Input Voltage Range
0 V AC - 160 V AC
Limited Warranty
3 Year
Load Capacity
1500 VA/1350 W
Manufacturer
Para Systems Inc
Manufacturer Part Number
EC1500LCD
Manufacturer Website Address
http://www.minutemanups.com
Marketing Information
On-Line UPS Comprehensive Protection
Minuteman's Encompass Series delivers the comprehensive protection only offered by a true on-line UPS. By totally regenerating the incoming AC signal through double-conversion technology an on-line UPS provides an impenetrable "electrical firewall" providing the most fail-safe power protection available.
Designed to protect the most critical equipment used in data centers voice and data communications security systems and light industrial applications. The Encompass Series is SNMP-capable (card optional) and allows full-device management using Minuteman's SentryHD™ power monitoring and control software.
The Encompass product line is a value-priced on-line UPS solution that provides an outstanding set of features true sinewave output a three-year warranty (including batteries) and is designed to meet the reliability expectations of even the most demanding critical applications. Two form factors are available in the Encompass Series: a tower-only version (EC-LCD) and a rack/tower version (EC-RT).
Minuteman's Encompass Series delivers the comprehensive protection only offered by a true on-line UPS. By totally regenerating the incoming AC signal through double-conversion technology an on-line UPS provides an impenetrable "electrical firewall" providing the most fail-safe power protection available.
Designed to protect the most critical equipment used in data centers voice and data communications security systems and light industrial applications. The Encompass Series is SNMP-capable (card optional) and allows full-device management using Minuteman's SentryHD™ power monitoring and control software.
The Encompass product line is a value-priced on-line UPS solution that provides an outstanding set of features true sinewave output a three-year warranty (including batteries) and is designed to meet the reliability expectations of even the most demanding critical applications. Two form factors are available in the Encompass Series: a tower-only version (EC-LCD) and a rack/tower version (EC-RT).
Maximum Operating Temperature
104°F (40°C)
Network Management
SNMP Manageable
Number of Batteries
1
Output voltage
127 V AC
Output voltage
110 V AC
Package Contents
- 1500 VA On-line Tower UPS with 6 0utlets
- Batteries Disconnected
- Quick Installation Guide
Plug/Connector Type
NEMA 5-15P
Product Line
Encompass
Product Name
1500 VA On-line Tower UPS with 6 0utlets
Product Type
Dual Conversion Online UPS
Receptacle Type
NEMA 5-15R
Software Included
Minuteman SentryHD Power Monitoring and Control Software
Sound Emission
55 dB(A)
Status Indicators
- LCD Status Panel
- Alarm
Surge energy rating
254 J
Transfer Time
0 ns
Weight (Approximate)
48.10 lb
Width
6.8"
