Transition Networks Hardened Mini Fast Ethernet Media Converter
Transition Networks Hardened Mini Fast Ethernet Media Converter - 1 x Network (RJ-45) - 1 x LC Ports - Multi-mode - Fast Ethernet - 100Base-T, 100Base-FX - Wall Mountable, Rail-mountable
| $192.61 | Retail $246.00 |
- Unit and Port LEDs provide quick status
- Auto-Negotiation
- Fixed Full-Duplex on fiber
- Auto-MDI/MDIX
- Link Pass Through
- Active Link Pass Through on SFP version
- Automatic Link Restoration
- Far-End-Fault (FEF)
- DC and AC power inputs via terminal block
- Includes barrel connector pig-tail cable
By:
Transition Networks
Manufacturer:
Transition Networks, Inc
Product ID:
107059
Item:
M/E-ISW-FX-02(MMLC)
UPC Code:
648177043071
Our Part #
6JU665
Condition
New
$192.61EA
$246.00
$246.00
Availability
Currently out of stock
Product description
Transition Networks Hardened Mini Fast Ethernet Media Converter - 1 x Network (RJ-45) - 1 x LC Ports - Multi-mode - Fast Ethernet - 100Base-T, 100Base-FX - Wall Mountable, Rail-mountable
1 x Network (RJ-45) - 1 x LC Ports - Multi-mode - Fast Ethernet - 100Base-T, 100Base-FX - Wall Mountable, Rail-mountable
Specifications
Fiber Mode Supported
Multi-mode
Fiber Optic Wavelength
1300 nm
Maximum Distance Supported
12.43 Mile
UPC Alternates
648177043071
Brand Name
Transition Networks
Country of origin
Taiwan
Depth
3.3"
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Ethernet Technology
Fast Ethernet
Form factor
Rail-mountable
Form factor
Wall Mountable
Height
0.9"
Limited Warranty
Lifetime
Manufacturer
Transition Networks Inc
Manufacturer Part Number
M/E-ISW-FX-02(MMLC)
Manufacturer Website Address
http://www.transition.com
Marketing Information
The M/E-ISW Series is a hardened Fast Ethernet Mini media converter that provides a cost effective plug-and-play media conversion between 10/100Base-TX ports and 100Base-FX ports for hardened or outdoor 10/100 environments. With its supported operating temperature range of -40°C to 75°C the Mini offers a space saving alternative for converting copper to fiber in extreme environments.
Media Type Supported
Twisted Pair
Media Type Supported
Optical Fiber
Network Technology
100Base-T
Network Technology
100Base-FX
Number of Network (RJ-45) Ports
1
Package Contents
- Hardened Mini Fast Ethernet Media Converter
- Barrel Connector Pig-Tail Cable
Power source
Power Supply
Product Name
Hardened Mini Fast Ethernet Media Converter
Product Series
M/E-ISW
Product Type
Transceiver/Media Converter
Total Number of Ports
2
Weight (Approximate)
2 lb
Width
1.8"
