Tripp Lite PDU Basic ISOBAR Surge Protection 14 Outlets L5-20P 15ft Cord 1U
Tripp Lite PDU Basic ISOBAR Surge Protection 14 Outlets L5-20P 15ft Cord 1U - Basic - NEMA L5-20P, NEMA 5-20P - 12 x NEMA 5-20R, 2 x NEMA 5-15R - 120 V AC - 1U - Horizontal/Vertical - Wall-mountable, Rack-mountable
| $217.91 | Retail $323.86 |
- Ideal no-frills PDU for telecom, security, A/V and other small network applications
- 3840 joules protect your valuable electronics against dangerous surges and spikes
- 12 NEMA 5-20R and 2 5-15R outlets distribute AC power to connected equipment
- 15 ft. cord with L5-20P input (and 5-20P adapter) connects to AC power source
- Flexible installation options include 1U and 0U rack, under counter and on wall
- 2-year limited warranty
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
108703
Item:
PDUH20-ISO
UPC Code:
037332255877
Our Part #
8JR836
Condition
New
$217.91EA
$323.86
$323.86
Availability
Only 269 Left In Stock
Product description
Tripp Lite PDU Basic ISOBAR Surge Protection 14 Outlets L5-20P 15ft Cord 1U - Basic - NEMA L5-20P, NEMA 5-20P - 12 x NEMA 5-20R, 2 x NEMA 5-15R - 120 V AC - 1U - Horizontal/Vertical - Wall-mountable, Rack-mountable
Basic - NEMA L5-20P, NEMA 5-20P - 12 x NEMA 5-20R, 2 x NEMA 5-15R - 120 V AC - 1U - Horizontal/Vertical - Wall-mountable, Rack-mountable
Specifications
Mounting Orientation
Horizontal/Vertical
PDU Type
Basic
Phase
Single Phase
Power Rating (Watt)
2030 W
Receptacle Detail
2 x NEMA 5-15R
Receptacle Detail
12 x NEMA 5-20R
UPC Alternates
037332255877
Brand Name
Tripp Lite
Country of origin
China
Depth
4.5"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
1.8"
Input current
20 A
Input voltage
120 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUH20-ISO
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Single-Phase 120V PDU Distributes Network-Grade Power to Multiple Loads
This basic PDU is an ideal no-frills unit for telecom security audio/video and a wide variety of general portable and stationary rack-mount applications. Recommended for network-grade IT environments the PDUH20-ISO features 12 NEMA 5-20R outlets in the rear and two 5-15R outlets in front. A 15-foot cord with L5-20P input plug (and included 5-20P adapter) connects to your facility's AC power source generator or protected UPS system to distribute power to connected loads.
3840 Joules Fight Back Against Unexpected Power Surges
Protecting your valuable electronics is ISOBAR® network-grade AC surge and noise suppression. A 3840-joule surge protection rating defends your sensitive electronic components against even the strongest power surges spikes and line noise. The PDUH20-ISO covers full normal (H-N) and common (N-G/H-G) protection modes. A green LED confirms your connected equipment is protected.
Up-to-Date Safety Features Protect Your Vital Equipment
The switchless design helps prevent an accidental shutdown which could lead to costly downtime. A 20A circuit breaker protects connected components from dangerous overloads. A red LED signals a suppressor or wiring fault.
Versatile Installation Options Give You Plenty of Choices
The reversible all-metal housing comes with mounting brackets for installation in 1U of space or 0U vertical mounting in an EIA-standard 19-inch rack. You can also reorient the brackets for permanent mounting under a counter or on a wall with user-supplied hardware.
Mount Type
Rack-mountable
Mount Type
Wall-mountable
Output voltage
100 V AC
Output voltage
127 V AC
Package Contents
- PDUH20-ISO 14-Outlets PDU
- NEMA 5-20P Input Adapter
- Rack-Mounting Hardware
- Owner's Manual
Plug/Connector Type
NEMA 5-20P
Plug/Connector Type
NEMA L5-20P
Product Name
PDUH20-ISO 14-Outlets PDU
Product Type
PDU
Protection Type
Spike Protection
Protection Type
Accidental Power Shutdown
Protection Type
Circuit Protection
Protection Type
Noise
Protection Type
Overload Protection
Protection Type
Surge Protection
Rack Height
1U
Receptacle Type
NEMA 5-20R
Receptacle Type
NEMA 5-15R
Weight (Approximate)
4.60 lb
Width
17.5"
