Star Tech.com Dual SATA to LP4 Power Doubler Cable Adapter, SATA to 4 Pin LP4 Internal PC Peripheral Power Supply Connector, 9 Amps/108W
Star Tech.com Dual SATA to LP4 Power Doubler Cable Adapter, SATA to 4 Pin LP4 Internal PC Peripheral Power Supply Connector, 9 Amps/108W - Dual SATA to LP4 power supply (ATX) adapter cable combines 2 SATA connections into one 4-Pin LP4 connector for a total power output of 150W (9A) - Extra power for LP4 mobile rack multi-drive (SSD/HDD) Backplanes (StarTech.com SATSASBP425)
| $15.82 | Retail $17.99 |
- DUAL SATA TO LP4 POWER CABLE: This power supply doubler adapter cable overcomes SATA Power supply (ATX) output limits by combining 2 SATA power connections into one 4-Pin LP4 connector, providing extra power to drive backplanes & storage peripherals
- DUAL SATA PROVIDES 150W TO LP4 DEVICE: Dual SATA Power inputs provide additional 5V and 12V power lines, providing extra 4.5A current per line, giving a total power output of 108W (9A at 12V) and 45W (9A at 5V)
- EXTRA POWER FOR 4-Pin LP4 BACKPLANES: The double SATA power supply to LP4 adapter cable provides extra power to mobile rack multi-drive (SSD/HDD) Backplanes that utilize LP4 Power such as StarTech.com SATSASBP425
- HIGH QUALITY CONSTRUCTION: 100% copper 18AWG UL1007 wires with PVC insulation, allowing max current of 4.5A per wire, Insulation tested upto 300V DC and connectors made from high strength LD-PE that can withstand high voltage and current ratings
- SPECS: 6 inch 2x SATA Power male to
Manufacturer:
StarTech.com
Product ID:
108796
Item:
DSATPMOLP4
UPC Code:
065030888110
Our Part #
8UK452
Condition
New
$15.82EA
$17.99
$17.99
Availability
Only 5507 Left In Stock
You may be also interested
Product description
Star Tech.com Dual SATA to LP4 Power Doubler Cable Adapter, SATA to 4 Pin LP4 Internal PC Peripheral Power Supply Connector, 9 Amps/108W - Dual SATA to LP4 power supply (ATX) adapter cable combines 2 SATA connections into one 4-Pin LP4 connector for a total power output of 150W (9A) - Extra power for LP4 mobile rack multi-drive (SSD/HDD) Backplanes (StarTech.com SATSASBP425)
Dual SATA to LP4 power supply (ATX) adapter cable combines 2 SATA connections into one 4-Pin LP4 connector for a total power output of 150W (9A) - Extra power for LP4 mobile rack multi-drive (SSD/HDD) Backplanes (StarTech.com SATSASBP425)
Specifications
First End Connector Detail
2 x 15-pin SATA Male
First End Connector Type
SATA
Second End Connector Detail
1 x 4-pin LP4 Female
Second End Connector Type
LP4
UPC Alternates
065030888110
Cord Length
5.90"
Country of origin
China
Current rating
9 A
Device Supported
Power Supply
Device Supported
Hard Drive
Device Supported
DVD-ROM
Limited Warranty
Lifetime
Manufacturer
StarTech.com
Manufacturer Part Number
DSATPMOLP4
Manufacturer Website Address
http://www.startech.com
Marketing Information
The SATA power to LP4 power cable adapter features two male SATA power connectors and one female LP4 power connector.
Robust Power ConnectivityThe pc internal power cable eliminates the need to upgrade your power supply for peripherals that require additional power via the LP4 connector. This enables you to extend your power connections and allows you to position your internal PC devices (i.e. hard drive DVD-ROM drive add-in card etc.) inside the system case. In addition the dual SATA power cable offers 6-inches in cable length from each of the SATA connector to the 4 pin LP4 peripheral power connector.
Constructed of only top-quality materials and designed for optimum performance and reliability this power supply SATA cable is the perfect connectivity solution for demanding devices.
The Choice of IT Pros Since 1985StarTech.com conducts thorough compatibility and performance testing on all our products to ensure we are meeting or exceeding industry standards and providing high-quality products to IT Professionals. Our local StarTech.com Technical Advisors have broad product expertise and work directly with our StarTech.com Engineers to provide support for our customers both pre and post-sales.
The DSATPMOLP4 is backed by a StarTech.com lifetime warranty and free lifetime technical support.
Product Type
Splitter Cord
Voltage Rating
5 V DC
Voltage Rating
12 V DC
Weight (Approximate)
0.07 lb
