Panorama Antennas SHKG Antenna
Panorama Antennas SHKG Antenna - 1562 MHz to 1612 MHz, 2.4 GHz to 5.8 GHz, 2300 MHz to 2500 MHz, 4900 MHz to 6000 MHz, 698 MHz to 960 MHz, 1710 MHz to 2170 MHz, 2500 MHz to 3800 MHz - 26 dB - GPS, Cellular Network, Wireless Data Network - Black - Panel - Omni-directional - FME, SMA Connector
| $184.18 | Retail $225.74 |
- Eases up the installation procedure thanks to its 360-degree horizontal pattern
- Provides gain of up to 26 dB
- This antenna is an excellent choice for gps
- Panel-mountable design for mounting convenience
By:
Panorama Antennas
Manufacturer:
Panorama Antennas Ltd
Product ID:
115241
Item:
SHKG-7-27-T24-58
Our Part #
6DC677
Condition
New
$184.18EA
$225.74
$225.74
Availability
Only 117 Left In Stock
You may be also interested
Product description
Panorama Antennas SHKG Antenna - 1562 MHz to 1612 MHz, 2.4 GHz to 5.8 GHz, 2300 MHz to 2500 MHz, 4900 MHz to 6000 MHz, 698 MHz to 960 MHz, 1710 MHz to 2170 MHz, 2500 MHz to 3800 MHz - 26 dB - GPS, Cellular Network, Wireless Data Network - Black - Panel - Omni-directional - FME, SMA Connector
1562 MHz to 1612 MHz, 2.4 GHz to 5.8 GHz, 2300 MHz to 2500 MHz, 4900 MHz to 6000 MHz, 698 MHz to 960 MHz, 1710 MHz to 2170 MHz, 2500 MHz to 3800 MHz - 26 dB - GPS, Cellular Network, Wireless Data Network - Black - Panel - Omni-directional - FME, SMA Connector
Specifications
Antenna Gain
26 dB
Directivity
Omni-directional
Operating Frequency Range
2300 MHz to 2500 MHz
Operating Frequency Range
1710 MHz to 2170 MHz
Operating Frequency Range
1562 MHz to 1612 MHz
Operating Frequency Range
4900 MHz to 6000 MHz
Operating Frequency Range
2500 MHz to 3800 MHz
Operating Frequency Range
2.4 GHz to 5.8 GHz
Operating Frequency Range
698 MHz to 960 MHz
Application/Usage
Cellular Network
Application/Usage
Wireless Data Network
Application/Usage
GPS
Brand Name
Panorama Antennas
Connector Type
FME
Connector Type
SMA
Form factor
Panel
Height
1.97"
Manufacturer
Panorama Antennas Ltd
Manufacturer Part Number
SHKG-7-27-T24-58
Manufacturer Website Address
http://www.panorama-antennas.com
Marketing Information
The SHKG has a compact OEM style sharkfin housing that contains 2x2 MiMo antenna function for 4G/3G/2G and an active antenna for GPS/GLONASS/Galileo/Beidou with 26dB gain LNA. In order to maximise functionality versions of the SHK[G] are available that add either 2x2 MiMo or 3x3 MiMo antenna functionality for 2.4/5.8GHz WiFi.
- OEM sharkfin styling
- MiMo 4G/3G/2GHz and GNSS in one housing
- Optional 2x2 or 3x3 WiFi 2.4/5GHz
The antenna does not require a metallic ground plane and maintains a high level of performance even when mounted on a non-metallic surface. This high-performance antenna offers multiple antenna functions while remaining discreet and is suitable for (overt/covert) applications where a cost-effective effective efficient and robust antenna is essential.
Product color
Black
Product Model
SHKG
Product Name
SHKG Antenna
Product Type
Antenna
Weight (Approximate)
9.17 oz
Width
2.40"
