SIIG DP Cyber RS-232 1S PCIe Card - 250Kbps
SIIG DP Cyber RS-232 1S PCIe Card - 250Kbps - ASIX AX99100 Chipset - PCI Express Base Specification 2.0 Compliant
| $27.59 | Retail $39.99 |
- Adds one 9-pin RS-232 serial port to PCIe enabled desktop computers
- One 16C650 UART serial port supports data transfer rate up to 250Kbps
- Compliant with PCI Express 2.0 Gen 1
- Single-lane (x1) PCI Express End-point Controller with PHY integrated
- Full serial modem control with hardware and software flow control
- Supports 5, 6, 7, 8 and 9-bit serial formats
- Supports Even, Odd, None, Space and Mark parity
- Supports on chip 256-byte FIFO buffers in transmit and receive path
- Works as either standard RS-232 port or with 5V or 12V power output for devices that require power (such as handheld scanners, table scanners, POS displays and many more). Configurable via jumpers
- Supports PCI Bus Power Management Interface Specification Revision 1.2
By:
SIIG
Manufacturer:
SIIG, Inc
Product ID:
117672
Item:
JJ-E20611-S1
UPC Code:
662774044088
Our Part #
8UL694
Condition
New
$27.59EA
$39.99
$39.99
Availability
Only 21 Left In Stock
Product description
SIIG DP Cyber RS-232 1S PCIe Card - 250Kbps - ASIX AX99100 Chipset - PCI Express Base Specification 2.0 Compliant
ASIX AX99100 Chipset - PCI Express Base Specification 2.0 Compliant
Specifications
Number of Serial Ports (External)
1
UPC Alternates
662774044088
Brand Name
SIIG
Card Height
Full-height/Low-profile
Country of origin
China
Depth
4.7"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Plug-in Card
Height
0.7"
Host interface
PCI Express 2.0 x1
Limited Warranty
2 Year
Manufacturer
SIIG Inc
Manufacturer Part Number
JJ-E20611-S1
Manufacturer Website Address
http://www.siig.com
Marketing Information
Add one 16650 RS232 port to your PCI Express system
Features- Adds one 9-pin RS-232 serial port to PCIe enabled desktop computers
- One 16C650 UART serial port supports data transfer rate up to 250Kbps
- Compliant with PCI Express 2.0 Gen 1
- Single-lane (x1) PCI Express End-point Controller with PHY integrated
- Full serial modem control with hardware and software flow control
- Supports 5 6 7 8 and 9-bit serial formats
- Supports Even Odd None Space and Mark parity
- Supports on chip 256-byte FIFO buffers in transmit and receive path
- Works as either standard RS-232 port or with 5V or 12V power output for devices that require power (such as handheld scanners table scanners POS displays and many more). Configurable via jumpers
- Supports PCI Bus Power Management Interface Specification Revision 1.2
- Dual profile design installs into both full-size and low-profile system chassis with the included mounting brackets
- Installs into any PCI Express slot of any lane width
- Perfect solution to connect with POS system industrial testing and control device security system logistic management equipment printers scanners etc
Package Contents
- DP Cyber 1S PCIe Card
- Full Height Bracket
- 1 x Low Profile Bracket
- 1 x Y-Split Power Cable
- 2 x Voltage Jumper
- Software CD
- User Manual
Platform Supported
PC
Product Name
DP Cyber 1S PCIe Card
Product Type
Serial Adapter
Weight (Approximate)
1.60 oz
Width
2.9"
