AddOn 10/100/1000Base-TX(RJ-45) to 1000Base-SX(SC) MMF 850nm 550m POE Media Converter
AddOn 10/100/1000Base-TX(RJ-45) to 1000Base-SX(SC) MMF 850nm 550m POE Media Converter - 100% compatible and guaranteed to work
| $193.72 | Retail $300.00 |
- Attach multiple devices together or expand the number of devices connected to your existing network by using 2 transceiver/media converter
- With Twisted Pair cable, get the desired data transfer rate up to a required distance
- With 10/100/1000Base-T technology get up to 1000Mbps data transfer rate over twisted pair cable
- Takes minimal energy and effort to get installed internally
Manufacturer:
AddOn
Product ID:
118830
Item:
ADD-GMCP-SX-5SC
UPC Code:
818262857450
Our Part #
6E3846
Condition
New
$193.72EA
$300.00
$300.00
Availability
Only 28 Left In Stock
Product description
AddOn 10/100/1000Base-TX(RJ-45) to 1000Base-SX(SC) MMF 850nm 550m POE Media Converter - 100% compatible and guaranteed to work
100% compatible and guaranteed to work
Specifications
Fiber Mode Supported
Multi-mode
Fiber Optic Cable Standard
62.5/125 µm
Maximum Distance Supported
1804.46 ft
UPC Alternates
818262857450 821455028209
Country of origin
United States
Depth
6"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
Gigabit Ethernet
Form factor
Internal
Height
1.5"
Limited Warranty
3 Year
Manufacturer
AddOn
Manufacturer Part Number
ADD-GMCP-SX-5SC
Manufacturer Website Address
http://www.addoncomputer.com
Marketing Information
ADD-GMCP-SX-5SC is a Media Converter that converts a 1000Base-TX(RJ45) to 1000Base-SX(SC) via a 850nm multi-mode fiber (MMF) SC connector which allows distance reach up to 550m. ADD-GMCP-SX-5SC provides a cost effective conversion from 1000Base Copper to 1000Base-SX fiber while extending the network reach beyond the 100m reach limitation of copper. This AC/DC powered PoE media converter is a Power Sourcing Equipment (PSE) which combines data transferred over a fiber optic link with 48V (or other voltage) power supply providing power to IEEE802.3af powered device (PD) over CAT5 and up UTP cable (cable length up to 100meters / 330feets). It complies with the IEEE802.3af standard. The converter includes a single port PSE controller which offers PD signature sensing and power monitoring features. Other features include over-current protection and LFP function. The LFP (Link Fault Pass-through) allows the media converter to monitor both the fiber and copper RX port for loss of signal. In case of a loss of RX signal on one media port the converter will automatically disable the TX signal to the other media port thus passing through the link fault.
Addoncomputer.com Media Converters and Network Interface Cards are 100% compliant for all of our networking needs. Now you have a cost effective solution to your network upgrade needs. With our ADDON CERTIFICATION TEST Program we can guarantee your product will work right the first time.
Addoncomputer.com Media Converters and Network Interface Cards are 100% compliant for all of our networking needs. Now you have a cost effective solution to your network upgrade needs. With our ADDON CERTIFICATION TEST Program we can guarantee your product will work right the first time.
Media Type Supported
Twisted Pair
Media Type Supported
Optical Fiber
Network Technology
1000Base-SX
Network Technology
10/100/1000Base-T
Number of Network (RJ-45) Ports
1
Product Name
1000Base-TX To 1000Base-SX SC MM 850nm POE Media Converter
Product Type
Transceiver/Media Converter
Total Number of Ports
2
Weight (Approximate)
1.40 lb
Width
5"
