Tripp Lite PDU Monitored Horizontal 3.3/3.8KW 208/240V ATS L6-20R L6-20P 1U
Tripp Lite PDU Monitored Horizontal 3.3/3.8KW 208/240V ATS L6-20R L6-20P 1U - 3.80 kVA - 1U
| $944.71 | Retail $1,377.80 |
- Two single-phase L6-20P inputs with 10 ft. cords
- L6-20R outlet for connecting single device or 0U vertical PDU
- Automatic transfer switching within 1-5 ms
- Built-in LX Platform Interface for remote access
- Digital display for real-time status monitoring
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
121378
Item:
PDUMNH20HVAT
UPC Code:
037332187932
Our Part #
3F8064
Condition
New
$944.71EA
$1,377.80
$1,377.80
Availability
Only 48 Left In Stock
You may be also interested
Product description
Tripp Lite PDU Monitored Horizontal 3.3/3.8KW 208/240V ATS L6-20R L6-20P 1U - 3.80 kVA - 1U
3.80 kVA - 1U
Specifications
Mounting Orientation
Horizontal
Plug/Connector Detail
2 x NEMA L6-20P
Power Rating (Watt)
3800 W
Receptacle Detail
1 x NEMA L6-20R
UPC Alternates
037332187932
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
14"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
1.7"
Input current
20 A
Input voltage
230 V AC
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUMNH20HVAT
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
The PDUMNH20HVAT 3.3/3.8kW Single-Phase 208/240V ATS/Monitored PDU provides remote power monitoring and enables redundant power for network devices with non-redundant power supply configurations. Ideal for data centers and server rooms it mounts in 1U of space in EIA-standard 19-inch racks and features one L6-20R outlet-perfect for connecting a single device or a 0U 208/240V PDU with an L6-20P plug.
Dual 10-foot input cords with L6-20P plugs connect to separate primary and secondary single-phase power sources. The PDU constantly evaluates the power quality of both input sources. Dynamic solid-state (TRIAC) automatic transfer switching allows the PDU to switch to the secondary source within 1-5 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption.
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities including temperature and humidity conditions. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP. DHCP/Manual configuration lets you assign network settings to the card automatically reducing the need for manual configuration. Automated alerts help prevent accidental overloads power loss and downtime.
Dual 10-foot input cords with L6-20P plugs connect to separate primary and secondary single-phase power sources. The PDU constantly evaluates the power quality of both input sources. Dynamic solid-state (TRIAC) automatic transfer switching allows the PDU to switch to the secondary source within 1-5 milliseconds should the primary source fail or become unstable to ensure your connected equipment operates without interruption.
The built-in Java-free HTML5-based LX Platform network interface enables full remote access for PDU status monitoring and email notifications via secure web browser SNMP telnet or SSH. It supports 10/100 Mbps auto-sensing for optimum communication with an Ethernet network. Optional EnviroSense2 modules (sold separately) provide a variety of environmental monitoring capabilities including temperature and humidity conditions. Protocols supported include IPv4 IPv6 HTTP HTTPS SMTP SNMPv1 SNMPv2 SNMPv3 telnet SSH FTP DHCP and NTP. DHCP/Manual configuration lets you assign network settings to the card automatically reducing the need for manual configuration. Automated alerts help prevent accidental overloads power loss and downtime.
Mount Type
Rack-mountable
Package Contents
- PDUMNH20HVAT 1-Outlet PDU
- Mounting brackets
- Owner's manual
Plug/Connector Type
NEMA L6-20P
Product Name
PDUMNH20HVAT 1-Outlet PDU
Product Type
PDU
Rack Height
1U
Receptacle Type
NEMA L6-20R
Weight (Approximate)
15.37 lb
Width
16.9"
