StarTech.com 2 Port PCI RS422/485 Serial Adapter Card with 161050 UART
StarTech.com 2 Port PCI RS422/485 Serial Adapter Card with 161050 UART - Add two RS422/485 serial ports through a standard or low profile PCI expansion slot - pci serial card - rs422 serial card - rs485 serial card - dual port serial card - 2 port rs422 pci card
| $121.19 | Retail $133.99 |
- Supports maximum data transmission rate of 128Kbps
- 16C1050 UART with 256-byte Deep FIFO
- Supports 2-wire and 4-wire RS485 modes
- Jumper pins for RS422/485 toggling
- Supports Hardware and Software flow control
- Supports PCI Power Management 1.1
- Compliant with PCI Local Bus Specification 2.3
Manufacturer:
StarTech.com
Product ID:
127136
Item:
PCI2S4851050
UPC Code:
065030842587
Our Part #
KF0783
Condition
New
$121.19EA
$133.99
$133.99
Availability
Only 171 Left In Stock
Product description
StarTech.com 2 Port PCI RS422/485 Serial Adapter Card with 161050 UART - Add two RS422/485 serial ports through a standard or low profile PCI expansion slot - pci serial card - rs422 serial card - rs485 serial card - dual port serial card - 2 port rs422 pci card
Add two RS422/485 serial ports through a standard or low profile PCI expansion slot - pci serial card - rs422 serial card - rs485 serial card - dual port serial card - 2 port rs422 pci card
Specifications
Number of Serial Ports (External)
2
UART Type
161050
UPC Alternates
065030842587
Card Height
Dual-profile
Country of origin
Taiwan
Data transfer rate
128kB/s
Environmental Certification
REACH
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
Plug-in Card
Height
1.8"
Host interface
Universal PCI
Length
4.7"
Limited Warranty
Lifetime
Manufacturer
StarTech.com
Manufacturer Part Number
PCI2S4851050
Manufacturer Website Address
http://www.startech.com
Marketing Information
The PCI2S4851050 2-Port PCI Serial Adapter Card (RS422/RS485) with 161050 UART adds two DB9 RS422/RS485 serial ports using a single PCI expansion slot.
The PCI serial card offers a high performance 16C1050 UART and supports both 2-wire and 4-wire RS485 modes. The card delivers an efficient single-chip design and a large 256-byte transit/receive FIFO buffer that work together to provide high-speed serial communication while reducing the overall load on the system CPU.
With the included standard and low profile/half-height brackets this PCI serial expansion card suits a broad range of system form factors and is a perfect addition for connecting RS422/485 serial devices to a host computer. For added versatility the RS422/RS485 adapter is able to accommodate 3.3 or 5V PCI/PCI-X slots.
Backed by a StarTech.com lifetime warranty and free lifetime technical support.
Marketing Information
The PCI2S4851050 2-Port PCI Serial Adapter Card (RS422/RS485) with 161050 UART adds two DB9 RS422/RS485 serial ports using a single PCI expansion slot.
The PCI serial card offers a high performance 16C1050 UART and supports both 2-wire and 4-wire RS485 modes. The card delivers an efficient single-chip design and a large 256-byte transit/receive FIFO buffer that work together to provide high-speed serial communication while reducing the overall load on the system CPU.
With the included standard and low profile/half-height brackets this PCI serial expansion card suits a broad range of system form factors and is a perfect addition for connecting RS422/485 serial devices to a host computer. For added versatility the RS422/RS485 adapter is able to accommodate 3.3 or 5V PCI/PCI-X slots.
Backed by a StarTech.com lifetime warranty and free lifetime technical support.
Package Contents
- 2 Port PCI RS422/485 Serial Adapter Card with 161050 UART
- Standard and Low Profile/half-height Brackets
- Driver CD
Packaged Quantity
1
Platform Supported
PC
Product Name
2 Port PCI RS422/485 Serial Adapter Card with 161050 UART
Product Type
Serial Adapter
Weight (Approximate)
2 oz
Width
0.6"
