Brainboxes Industrial Ethernet 4 Port Switch DIN Rail Mountable
Brainboxes Industrial Ethernet 4 Port Switch DIN Rail Mountable - 4 Ports - 10/100Base-TX - TAA Compliant - 2 Layer Supported - Rail-mountable - Lifetime Limited Warranty
| $76.14 |
- 4 Port Ethernet Switch
- Integrated DIN Rail Mount with grounding
- Redundant dual power inputs: +5V to +30V DC
- Industrial operating temp range -40°C to +80°C / -40°F to +176°F
- Slim Footprint Case, only 22.5mm wide
By:
Brainboxes
Manufacturer:
Brainboxes Limited
Product ID:
127953
Item:
SW-504
UPC Code:
837324009873
Our Part #
TE5921
Condition
New
$76.14EA
Availability
Only 2 Left In Stock
Product description
Brainboxes Industrial Ethernet 4 Port Switch DIN Rail Mountable - 4 Ports - 10/100Base-TX - TAA Compliant - 2 Layer Supported - Rail-mountable - Lifetime Limited Warranty
4 Ports - 10/100Base-TX - TAA Compliant - 2 Layer Supported - Rail-mountable - Lifetime Limited Warranty
Specifications
UPC Alternates
837324009873 860350919519
Brand Name
Brainboxes
Certifications & Standards
- CE
- CCC-Mark
- C-Tick
- Microsoft Certified Gold Partner
- METL
- AEO (C-TPAT)
Country of origin
United Kingdom
Depth
3.9"
Environmental Certification
WEEE
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
Fast Ethernet
Form factor
Rail-mountable
Height
0.9"
Layer Supported
2
Limited Warranty
Lifetime
Manageable
No
Manufacturer
Brainboxes Limited
Manufacturer Part Number
SW-504
Manufacturer Website Address
http://www.brainboxes.com
Marketing Information
Industrial Ethernet 4 Port unmanaged switch. Galvanically Isolated Ethernet Ports capable of 10/100 Mbps. Industrial temperature range of -40°C to +80°C (-40°F to 176°F) and dual input redundant power supply with wide voltage range means it can be powered from USB or on the 24V factory floor. Power terminal is removable with numbered pins for easy wiring. Power consumption is optimised based on the status of the link device. No software required. Ideal for factory floor in vehicle and marine applications.
Media Type Supported
Twisted Pair
Network Technology
10/100Base-TX
Number of Network (RJ-45) Ports
4
Package Contents
- Industrial Ethernet 4 Port Switch DIN Rail Mountable
- Quick Start Guide
Port/Expansion Slot Details
4 x Fast Ethernet Network
Power source
AC Adapter
Power source
USB
Product Name
Industrial Ethernet 4 Port Switch DIN Rail Mountable
Product Type
Ethernet Switch
Weight (Approximate)
4.41 oz
Width
4.6"
