StarTech.com 5 Port Unmanaged Industrial Gigabit Ethernet Switch - DIN Rail / Wall-Mountable
StarTech.com 5 Port Unmanaged Industrial Gigabit Ethernet Switch - DIN Rail / Wall-Mountable - Network up to 5 Ethernet devices through a rugged, industrial Gigabit Ethernet switch - 5 Port Unmanaged Industrial Gigabit Ethernet Switch - DIN Rail / Wall-Mountable Network Switch - Rugged IP30-Rated Gigabit Switch - Industrial Ethernet Switch
| $230.70 | Retail $249.99 |
- 5 10/100/1000 Mbps unmanaged RJ45 Ethernet ports
- IP30-rated DIN rail and wall-mountable metal enclosure
- Wide-range redundant power via two 12-58V DC terminal block inputs, with alarm relay
- Overcurrent and reverse polarity protection
- Extended operating temperature range (-40?C to 75?C)
- Speed / duplex auto-negotiation and auto-MDIX detection on each port
- Up to 9K jumbo frame support
- IEEE 802.3az Energy-Efficient Ethernet
- Supports IEEE 802.3x flow control and back-pressure
Manufacturer:
StarTech.com
Product ID:
128567
Item:
IES51000
UPC Code:
065030859318
Our Part #
YB4236
Condition
New
$230.70EA
$249.99
$249.99
Availability
Only 558 Left In Stock
Product description
StarTech.com 5 Port Unmanaged Industrial Gigabit Ethernet Switch - DIN Rail / Wall-Mountable - Network up to 5 Ethernet devices through a rugged, industrial Gigabit Ethernet switch - 5 Port Unmanaged Industrial Gigabit Ethernet Switch - DIN Rail / Wall-Mountable Network Switch - Rugged IP30-Rated Gigabit Switch - Industrial Ethernet Switch
Network up to 5 Ethernet devices through a rugged, industrial Gigabit Ethernet switch - 5 Port Unmanaged Industrial Gigabit Ethernet Switch - DIN Rail / Wall-Mountable Network Switch - Rugged IP30-Rated Gigabit Switch - Industrial Ethernet Switch
Specifications
Product Material
Steel
UPC Alternates
065030859318
Certifications & Standards
- CE
- FCC
- 802.3
- 802.3u
- 802.3ab
- 802.1p
- 802.3az
- 802.3ad
Country of origin
Taiwan
Depth
4.4"
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmental Certification
REACH
Environmentally Friendly
Yes
Ethernet Technology
Gigabit Ethernet
Form factor
Wall Mountable
Form factor
Rail-mountable
Height
1.1"
Input voltage
120 V AC
Input voltage
230 V AC
Layer Supported
2
Limited Warranty
2 Year
Manageable
No
Manufacturer
StarTech.com
Manufacturer Part Number
IES51000
Manufacturer Website Address
http://www.startech.com
Marketing Information
The IES51000 5-Port Industrial Ethernet Switch offers 5 Gigabit Ethernet ports in a compact IP30-rated metal enclosure making it the ideal network solution for harsh industrial environments such as factory floors warehouses or large junction boxes.
Quickly connect your network devices with little to no configuration. This unmanaged industrial network switch supports 10/100/1000 Mbps transfer speeds full/half-duplex auto-negotiation jumbo frames and auto MDI/MDIX which helps to eliminate the hassle of troubleshooting mis-matched speed and duplex settings.
Providing seamless operation in the event of power dips or failures the switch features redundant 12-58V DC terminal block power inputs to help prevent unnecessary downtime. When used with two power sources the switch also supports alarm relay contacts that you can wire to your existing alarm circuit to notify you instantly when a power disruption occurs.
For easy installation and dependable performance in harsh environments the switch can be DIN Rail or wall mounted and features a compact IP30-rated enclosure with an extended operating temperature range (-40°C to 75°C).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Marketing Information
The IES51000 5-Port Industrial Ethernet Switch offers 5 Gigabit Ethernet ports in a compact IP30-rated metal enclosure making it the ideal network solution for harsh industrial environments such as factory floors warehouses or large junction boxes.
Quickly connect your network devices with little to no configuration. This unmanaged industrial network switch supports 10/100/1000 Mbps transfer speeds full/half-duplex auto-negotiation jumbo frames and auto MDI/MDIX which helps to eliminate the hassle of troubleshooting mis-matched speed and duplex settings.
Providing seamless operation in the event of power dips or failures the switch features redundant 12-58V DC terminal block power inputs to help prevent unnecessary downtime. When used with two power sources the switch also supports alarm relay contacts that you can wire to your existing alarm circuit to notify you instantly when a power disruption occurs.
For easy installation and dependable performance in harsh environments the switch can be DIN Rail or wall mounted and features a compact IP30-rated enclosure with an extended operating temperature range (-40°C to 75°C).
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Media Type Supported
Twisted Pair
Network Technology
10/100/1000Base-T
Networking standards
IEEE 802.3ab
Networking standards
IEEE 802.3
Networking standards
IEEE 802.3u
Networking standards
IEEE 802.3x
Networking standards
IEEE 802.3af
Number of Network (RJ-45) Ports
5
Package Contents
- 5 Port Unmanaged Industrial Gigabit Ethernet Switch - DIN Rail / Wall-Mountable
- 2 x Wall-Mount Brackets
- 1 x DIN-Rail Clip
- 4 x Screws
- 1 x Terminal Block
- 1 x Instruction Manual
Packaged Quantity
1
Port/Expansion Slot Details
5 x Gigabit Ethernet Network
Power consumption
62 W
Power source
AC Adapter
Product Name
5 Port Unmanaged Industrial Gigabit Ethernet Switch - DIN Rail / Wall-Mountable
Product Type
Ethernet Switch
Weight (Approximate)
11.60 oz
Width
3.5"
