Tripp Lite 16U Wallmount Low Profile Vertical Rack Enclosure Server Cabinet
Tripp Lite 16U Wallmount Low Profile Vertical Rack Enclosure Server Cabinet - 19" 16U Wide x 35" Deep Wall Mountable for Server, LAN Switch, Patch Panel, UPS, Battery Pack - Black Powder Coat - Steel - 400 lb x Maximum Weight Capacity - 399.04 lb x Static/Stationary Weight Capacity
| $821.33 | Retail $1,182.60 |
- Maximum load capacity of 400 lb.
- Locking steel cabinet vented to keep equipment cool
- Secures 12U of 19 in. rack equipment up to 35 in. deep
- Includes additional 4U of space for patch panels
- Modular design for easy disassembly and assembly
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
130225
Item:
SRWF16U38
UPC Code:
037332195869
Our Part #
8D9113
Condition
New
$821.33EA
$1,182.60
$1,182.60
Availability
Only 56 Left In Stock
Product description
Tripp Lite 16U Wallmount Low Profile Vertical Rack Enclosure Server Cabinet - 19" 16U Wide x 35" Deep Wall Mountable for Server, LAN Switch, Patch Panel, UPS, Battery Pack - Black Powder Coat - Steel - 400 lb x Maximum Weight Capacity - 399.04 lb x Static/Stationary Weight Capacity
19" 16U Wide x 35" Deep Wall Mountable for Server, LAN Switch, Patch Panel, UPS, Battery Pack - Black Powder Coat - Steel - 400 lb x Maximum Weight Capacity - 399.04 lb x Static/Stationary Weight Capacity
Specifications
Product Material
Steel
Rack Depth
35"
Rack Width
19"
Static/Stationary Weight Capacity
399.04 lb
UPC Alternates
037332195869 098379020736
Application/Usage
Patch Panel
Application/Usage
Server
Application/Usage
UPS
Application/Usage
Battery Pack
Application/Usage
LAN Switch
Brand Name
Tripp Lite
Country of origin
China
Depth
23.2"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Wall Mountable
Height
38"
Limited Warranty
5 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
SRWF16U38
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
The SRWF16U38 SmartRack® 16U Low-Profile Vertical-Mount Server-Depth Wall-Mount Rack Enclosure Cabinet is designed to house EIA-standard 19-inch rack equipment in network wiring closets retail locations classrooms back offices two-post racks and other areas with limited floor space where you need equipment to be secure organized and out of the way. Constructed from heavy-duty steel with a durable black powder-coated finish the cabinet has a maximum load capacity of 400 pounds.
Because the low-profile cabinet mounts vertically it extends only 24 inches from the wall while housing equipment up to 35 inches deep including 1U servers UPS systems battery packs and switches. In addition to 12U of rack space in the primary mounting area it also includes a 4U mounting space at the top of the enclosure for patch panels.
The top cover and front panel are removable to allow expedient access to equipment. The cover also locks securely with the included keys to help prevent damage tampering or theft. The vented cabinet allows air to flow freely and keep equipment cool. Convenient top bottom and side ports allow easy cable routing.
The SRWF16U38's modular design allows you to disassemble the cabinet in minutes for wall-mounting with user-supplied hardware. Mounting holes are spaced 16 inches apart to accommodate standard wall studs. Equipment installation is easy with threaded mounting holes that support 12-24 mounting in two-post racks.
Features
Saves Valuable Workspace
Because the low-profile cabinet mounts vertically it extends only 24 inches from the wall while housing equipment up to 35 inches deep including 1U servers UPS systems battery packs and switches. In addition to 12U of rack space in the primary mounting area it also includes a 4U mounting space at the top of the enclosure for patch panels.
The top cover and front panel are removable to allow expedient access to equipment. The cover also locks securely with the included keys to help prevent damage tampering or theft. The vented cabinet allows air to flow freely and keep equipment cool. Convenient top bottom and side ports allow easy cable routing.
The SRWF16U38's modular design allows you to disassemble the cabinet in minutes for wall-mounting with user-supplied hardware. Mounting holes are spaced 16 inches apart to accommodate standard wall studs. Equipment installation is easy with threaded mounting holes that support 12-24 mounting in two-post racks.
Features
Saves Valuable Workspace
- Recommended for areas with limited floor space where you need equipment to be secure organized and out of the way
- Houses EIA-standard 19 in. rack equipment in 12U of space
- Also includes 4U of mounting space at the top of the enclosure for patch panels
- Extends only 24 in. from the wall while housing equipment up to 35 in. deep
- Maximum load capacity of 400 lb.
- Top cover locks securely to help prevent damage tampering or theft
- Vented cabinet keeps equipment cool
- Convenient ports with removable covers allow cable routing through top bottom and sides
- Modular design for easy disassembly and assembly
- Wall-mounting holes spaced 16 in. apart for standard wall stud placement
- Threaded mounting holes support 12-24 mounting in 2-post racks
- Rack spaces marked for easy reference
- Provides physical equipment and media security required for PCI DSS (Payment Card Industry Data Security Standard) compliance
Maximum weight capacity
400 lb
Package Contents
- SmartRack SRWF16U38 Rack Cabinet
- 2 x Keys
- Owner's Manual
Product color
Black Powder Coat
Product Line
SmartRack
Product Name
SmartRack SRWF16U38 Rack Cabinet
Product Type
Rack Cabinet
Rack Height
16U
Weight (Approximate)
81.50 lb
Width
19.7"
