Advantech 2-port RS-232/422/485 Serial Device Server
Advantech 2-port RS-232/422/485 Serial Device Server - Twisted Pair - 2 x Network (RJ-45) - 2 x Serial Port - 10/100Base-TX - Fast Ethernet - Wall Mountable, DIN Rail Mountable
| $307.30 |
- Supports line to line 2 KV, line to ground 4 KV surge protection
- Provides 2 x 10/100 Mbps Ethernet ports for LAN redundancy
- Provides COM port redirection (Virtual COM), TCP and UDP operation modes
- Supports up to 921.6 kbps, and any baud rate setting
- Allows a max. of 5 hosts to access one serial port
- Allows a max. of 16 hosts to be accessed as TCP client mode
- Built-in 15 KV ESD protection for all serial signals
- Provides rich configuration methods including Windows utility, Telnet console, and Web Browser
- Supports 32-bit/64-bit Windows 2000/XP/Vista/7/8/8.1/10, Windows Server2003/2008/2012/2016, and Linux
- Automatic RS-485 data flow control
By:
Advantech
Manufacturer:
Advantech Co., Ltd
Product ID:
131404
Item:
EKI-1522-CE
Our Part #
7ZA185
Condition
New
$307.30EA
Availability
Only 228 Left In Stock
Product description
Advantech 2-port RS-232/422/485 Serial Device Server - Twisted Pair - 2 x Network (RJ-45) - 2 x Serial Port - 10/100Base-TX - Fast Ethernet - Wall Mountable, DIN Rail Mountable
Twisted Pair - 2 x Network (RJ-45) - 2 x Serial Port - 10/100Base-TX - Fast Ethernet - Wall Mountable, DIN Rail Mountable
Specifications
Brand Name
Advantech
Certifications & Standards
- EMC: CE FCC
- EMI: EN 55011/ EN 55032 Class A EN 61000-6-4 FCC Part 15 Subpart B Class A
- EMS: EN 61000-4-2 (Level 4) EN 61000-4-3 (Level 3) EN 61000-4-4 (Level 4) EN 61000-4-5 (Level 4) EN 61000-4-6 (Level 3) EN 61000-4-8 (Level 4) EN55024
- Freefall: IEC 60068-2-32
- Safety: UL 60950-1
- Shock: IEC 60068-2-27
- Vibration: IEC 60068-2-6
Country of origin
Taiwan
Depth
3.7"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
Fast Ethernet
Form factor
Wall Mountable
Form factor
DIN Rail Mountable
Height
5.5"
Limited Warranty
5 Year
Manufacturer
Advantech Co. Ltd
Manufacturer Part Number
EKI-1522-CE
Manufacturer Website Address
http://www.advantech.com
Marketing Information
EKI-1521 EKI-1522 and EKI-1524 feature two independent Ethernet ports and MAC addresses to provide a redundant network mechanism to guarantee Ethernet network reliability. EKI-1521 EKI-1522 and EKI-1524 are serial device servers that connect RS-232/422/485 serial devices such as PLC meters sensors and barcode reader to an IP-based Ethernet LAN. They allow nearly any device with serial ports to connect and share an Ethernet network. EKI-1521 EKI-1522 and EKI-1524 provide various operations: COM port redirection (Virtual COMport) TCP Server TCP Client and UDP mode. With COM port redirection mode standard serial operation calls are transparently redirected to the EKI-1521 EKI-1522 and EKI-1524 guaranteeing compatibility with legacy serial devices and enabling backward compatibility with existing software. With TCP server TCP client and UDP modes EKI- 1521 EKI-1522 and EKI-1524 ensure the compatibility of network software that uses a standard network API. Moreover you can make serial devices communicate with other devices peer-to-peer without any intermediate host PCs and software programming.
Media Type Supported
Twisted Pair
Network Standard
10/100Base-TX
Number of Network (RJ-45) Ports
2
Packaged Quantity
1
Power consumption
3.20 W
Product Model
EKI-1522
Product Name
2-port RS-232/422/485 Serial Device Server
Product Type
Device Server
Weight (Approximate)
1.04 lb
Width
1.4"
