Tripp Lite UPS Smart 5000VA 3750W Rackmount AVR 208V Pure Sign Wave 5kVA USB DB9 3URM
Tripp Lite UPS Smart 5000VA 3750W Rackmount AVR 208V Pure Sign Wave 5kVA USB DB9 3URM - 5000VA/3750W - 10 Minute Full Load - 1 x NEMA L6-30R, 2 x NEMA L6-20R, 2 x NEMA 5-15R
| $3,630.62 | Retail $5,494.32 |
- 5kVA / 5000VA line interactive 3U rack/tower UPS; Sine wave output
- 208V nominal output during inputs of 174-282V; Supports 600VA 120V output
- USB, Serial, EPO & optional SNMP/Web card monitoring options
- 97% line-mode efficiency; Hot-swappable internal batteries
- NEMA L6-30P input; 2 NEMA 5-15R, 2 L6-20R & 1 L6-30R outlets
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
134996
Item:
SMART5000TEL3U
UPC Code:
037332116116
Our Part #
454401
Condition
New
$3,630.62EA
$5,494.32
$5,494.32
Availability
Only 93 Left In Stock
Product description
Tripp Lite UPS Smart 5000VA 3750W Rackmount AVR 208V Pure Sign Wave 5kVA USB DB9 3URM - 5000VA/3750W - 10 Minute Full Load - 1 x NEMA L6-30R, 2 x NEMA L6-20R, 2 x NEMA 5-15R
5000VA/3750W - 10 Minute Full Load - 1 x NEMA L6-30R, 2 x NEMA L6-20R, 2 x NEMA 5-15R
Specifications
Load Capacity (VA)
5000 VA
Load Capacity (W)
3750 W
Receptacle Detail
2 x NEMA 5-15R
Receptacle Detail
2 x NEMA L6-20R
Receptacle Detail
1 x NEMA L6-30R
UPC Alternates
037332116116
Additional Information
- Ideal in rackmount or tower installations for centralized UPS protection of critical 208V equipment in server rooms internetworking closets and telecommunications systems. Common applications include any mix of servers workstations hubs routers concentrators IP telephony and traditional PBX switching systems
- Switches: Includes 2 front panel mounted push button switches for system enable self-test and alarm cancel functions
Backup/Run Time (Full Load)
10 Minute
Backup/Run Time (Half Load)
24 Minute
Brand Name
Tripp Lite
Certifications & Standards
UL1778 (USA) CSA (Canada) FCC Class A (Emissions)
Country of origin
Taiwan
Depth
25"
Form factor
Rack/Tower
Height
5.3"
Hot Swappable
Yes
Input current
24 A
Input voltage
208 V AC
Limited Warranty
3 Year
Limited Warranty
2 Year
Load Capacity
5000 VA/3750 W
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
SMART5000TEL3U
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite's SMART5000TEL3U intelligent line interactive UPS protects server networking and telecommunications equipment from blackouts voltage fluctuations and surges in a compact rackmount housing. Completely self-contained UPS system occupies only 3 rack spaces (3U) in a standard 19 inch rack making this model one of the smallest 5kVA UPS systems available. Included accessories support mounting 4 post rack enclosures. Large capacity 5000 VA/3750 watt UPS system accepts raw AC input adjusting output to regulated 208V levels. One pair of 120V outlets support up to 600VA monitors and other low voltage accessories. Includes slot for internal Network Management Card option. Includes USB and 2 DB9 monitoring ports for unattended shutdown remote control and monitoring of UPS system and power data. Five outlets (two L6-20R one L6-30R and two 5-15R) allow the connection of high current 20 and 30 amp 208V connectors and up to two 120V devices (max 600VA at 120V).
Network Management
SNMP Manageable
Package Contents
- Smart Pro 5000TEL3U UPS
- SMART5000TEL3U UPS System
- PowerAlert Software and cabling
- Mounting hardware
- Warranty information
- Instruction manual
Plug/Connector Type
NEMA L6-30P
Product Line
SmartPro
Product Name
SmartPro SMART5000TEL3U 5000VA Tower/Rack-mountable UPS
Product Type
Line-interactive UPS
Rack Height
3U
Receptacle Type
NEMA L6-20R
Receptacle Type
NEMA 5-15R
Receptacle Type
NEMA L6-30R
Software Included
PowerAlert Software
Transfer Time
8 ms
Typical Battery Recharge Time
4 Hour
Weight (Approximate)
143.30 lb
Width
17.5"
