IOGEAR MiniView GCS1742 2-Port Dual View KVM Switch
IOGEAR MiniView GCS1742 2-Port Dual View KVM Switch - 2 x 1 - 2 x SPHD-15 Video/USB, 2 x SPHD-15 Audio/Video
| $186.58 | Retail $199.95 |
- One dual monitor console controls 2 dual monitor computers
- Increase security for your intranet by separating a PC connected to the Internet and a PC connected to an Intranet
- Additional VGA display channel provided for dual display of each computer
- Additional USB peripheral ports for the connected computers to share USB devices, such as printers, scanners, and portable hard drives, etc.
- Advanced control: Switch computers without interrupting USB or Audio operations
- Audio jacks provided for speaker and microphone sharing
- Independent switching of KVM, USB, and audio
- Easy to install - no software required - connecting cables is all it takes
- Easy to operate - computer selection via push button switches or hotkeys
- Auto Scan function to monitor computer operation
By:
IOGEAR
Manufacturer:
IOGEAR, Inc
Product ID:
135031
Item:
GCS1742
UPC Code:
647697163924
Our Part #
43211601
Condition
New
$186.58EA
$199.95
$199.95
Availability
Only 71 Left In Stock
Product description
IOGEAR MiniView GCS1742 2-Port Dual View KVM Switch - 2 x 1 - 2 x SPHD-15 Video/USB, 2 x SPHD-15 Audio/Video
2 x 1 - 2 x SPHD-15 Video/USB, 2 x SPHD-15 Audio/Video
Specifications
Number of Local Users Supported
1
UPC Alternates
647697163924 801096832939 818275763632 881317003638
Additional Information
- Independent switching of KVM USB and audio
- Easy to install - no software required - connecting cables is all it takes
- Easy to operate - computer selection via push button switches or hotkeys
- Auto Scan function to monitor computer operation
- Hotkey selection for OS and keyboard language
- LED display for easy status monitoring
- Caps Lock Num Lock and Scroll Lock states are saved and restored when switching
- Hot pluggable - add or remove computers for easy maintenance
- Keyboard and mouse emulation for error free booting
- Efficient ergonomic design - logical connector layout
Brand Name
IOGEAR
Compatibility
- Supports multimedia USB keyboards
- Supports Mac & Sun keyboards
Country of origin
Taiwan
Depth
2.9"
Graphic Mode
SVGA
Graphic Mode
VGA
Height
1.7"
Input voltage
5 V DC
Limited Warranty
3 Year
Manufacturer
IOGEAR Inc
Manufacturer Part Number
GCS1742
Manufacturer Website Address
http://www.iogear.com
Marketing Information
The Dual View GCS1742 USB KVMP Switch brings dual head video functionality to IOGEAR's USB KVM switch technology. Now two dual-display computers can be accessed and controlled from a single console that consists of a USB keyboard USB mouse and two VGA SVGA or Multisync monitors. In addition the GCS1742 allows the computers to share USB peripherals connected to the USB peripheral ports such as printers scanners portable hard drivers etc.
Recognizing the importance of sound this switch is also audio-enabled. A single microphone can provide audio input to each of the computers and you can enjoy the audio output of each computer on a single set of speakers.
Maximum Operating Distance
72"
Maximum Video Resolution
2048 x 1536
Minimum Scan Interval
1 Second
Number of VGA Ports
2
Package Contents
- 1 x MiniView GCS1742 2-Port Dual View KVM Switch
- 2 x Custom audio/video cables (6 ft long)
- 2 x Custom USB/video cables (6 ft long)
- 1 x Firmware upgrade cable
- 1 x User Manual
- 1 x Quick Start Guide
Platform Supported
PC
Platform Supported
Mac
Platform Supported
Sun
Power consumption
1.25 W
Product Line
MiniView
Product Name
MiniView GCS1742 2-Port Dual View KVM Switch
Product Type
KVM Switchbox
VGA
Yes
Weight (Approximate)
1.81 lb
Width
7.9"
