StarTech.com SATA to 2.5in or 3.5in IDE Hard Drive Adapter for HDD Docks

StarTech.com SATA to 2.5in or 3.5in IDE Hard Drive Adapter for HDD Docks - Use your 2.5in or 3.5in IDE hard drives in a SATA HDD Docking Station - sata to ide adapter - sata to pata adapter - sata to ide converter
$32.00Retail $37.99
  • Supports 40-pin (3.5in) and 44-pin (2.5in) IDE hard drives
  • Durable, metal construction
  • Compatible with most 3.5in StarTech.com SATA hard drive docking stations and duplicators
  • Large capacity hard drive support, with 48-bit LBA
  • Compliant with SATA revision 1.0
  • Compatible with PATA (IDE) 66/100/133 MBps hard drives
  • Mounting holes for both 2.5in and 3.5in form factor IDE hard drives
Manufacturer:
StarTech.com
Product ID:
135621
Item:
SAT2IDEADP
UPC Code:
065030843393
Our Part #
GU5371
Condition
New
$32.00EA
$37.99
Availability Only 339 Left In Stock
Great Deals Everyday

You may be also interested

Product description

StarTech.com SATA to 2.5in or 3.5in IDE Hard Drive Adapter for HDD Docks - Use your 2.5in or 3.5in IDE hard drives in a SATA HDD Docking Station - sata to ide adapter - sata to pata adapter - sata to ide converter
Use your 2.5in or 3.5in IDE hard drives in a SATA HDD Docking Station - sata to ide adapter - sata to pata adapter - sata to ide converter

Specifications

Compatible Drive Bay Width
3.5"
Cooling Fan
No
Product Material
Steel
UPC Alternates
065030843393
Additional Information

OS independent: No software or drivers required

Additional Information
  • Connector Type(s): 1 - SP4 (4 pin Small Drive Power)
  • Drive Connectors: 1 - LP4 (4 pin; Large Drive Power); 1 - IDE (40 Pin EIDE/PATA); 1 - IDE (44 Pin EIDE/PATA 2.5" HDD)
  • Host Connectors: 1 - SATA Power (15 pin); 1 - SATA (7 pin Data)
  • Number of Drives: 1
  • Drive Size: 2.5in & 3.5in
  • Compatible Drive Types: IDE (ATA)
  • Drive Installation: Fixed
  • Fan(s): No
  • Chipset ID: JMicron - JM20330
  • LBA support: 48-bit
Certifications & Standards
  • FCC
  • CE
Country of origin
China
Depth
4"
Drive Interface
SATA/600
Environmental Certification
REACH
Environmental Certification
WEEE
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
Internal
Height
1"
Host interface
Serial ATA
Length
4"
Limited Warranty
2 Year
Manufacturer
StarTech.com
Manufacturer Part Number
SAT2IDEADP
Manufacturer Website Address
http://www.startech.com
Marketing Information

The SAT2IDEADP SATA to IDE hard drive adapter enables you to use your 2.5-inch/3.5-inch IDE-based (PATA) hard drives in most StarTech.com SATA-based HDD docking stations and drive duplicators. The SATA-IDE adapter features all-metal construction that ensures maximum durability and is fully compatible with IDE hard drives up to ATA-133 (133MBps).

The unique mounting style of the SATA/IDE adapter enables it to be easily mounted to an IDE/ATA hard drive and inserted into a SATA hard drive dock bay for quick and easy retrieval of data from older HDDs. The adapter can also be used to install IDE hard drives into SATA-only desktop computers or any other scenario that requires an IDE hard drive to be connected through Serial ATA.

The SAT2IDEADP hard drive adapter works with most StarTech.com SATA HDD Docking Stations and Duplicators.

Backed by 2-year warranty and free lifetime technical support.

More from the Manufacturer

Marketing Information

The SAT2IDEADP SATA to IDE hard drive adapter enables you to use your 2.5-inch/3.5-inch IDE-based (PATA) hard drives in most StarTech.com SATA-based HDD docking stations and drive duplicators. The SATA-IDE adapter features all-metal construction that ensures maximum durability and is fully compatible with IDE hard drives up to ATA-133 (133MBps).

The unique mounting style of the SATA/IDE adapter enables it to be easily mounted to an IDE/ATA hard drive and inserted into a SATA hard drive dock bay for quick and easy retrieval of data from older HDDs. The adapter can also be used to install IDE hard drives into SATA-only desktop computers or any other scenario that requires an IDE hard drive to be connected through Serial ATA.

The SAT2IDEADP hard drive adapter works with most StarTech.com SATA HDD Docking Stations and Duplicators.

Backed by 2-year warranty and free lifetime technical support.

More from the Manufacturer

Marketing Information

The SATDOCKU3S USB 3.0 Hard Drive Docking Station delivers full instant access to any 2.5in or 3.5in SATA (SATA SATA II SATA III) hard drive (HDD) or solid state drive (SSD) without having to mount the drive in a computer or install it in an external enclosure. Large capacity drives (tested with up to 4TB 3.5" and 1TB 2.5" drives) can be used to greatly enhance your computer's storage/backup capabilities.

Connected to the host computer through a single USB 3.0 SuperSpeed or USB 2.0 connection the hard drive docking station provides a convenient plug-and-play storage solution that delivers instant access to the hard drive without requiring a reboot.

Relying on the outstanding data throughput support of USB 3.0 the HDD docking station is capable of transfer speeds of up to 5Gbps making it the fastest way to access data from an external drive. Double the value of this hard drive docking station using a SATA to IDE hard drive adapter (SAT2IDEADP) which enables you to use any 2.5 or 3.5in IDE hard drive in a SATA hard drive dock slot.

o ensure compatibility with your computer system the SATDOCKU3S supports all of the leading operating system platforms including: Microsoft Windows Apple OSX Linux and Google Chrome OS

More from the Manufacturer

Marketing Information

The SATDOCKU3S USB 3.0 Hard Drive Docking Station delivers full instant access to any 2.5in or 3.5in SATA (SATA SATA II SATA III) hard drive (HDD) or solid state drive (SSD) without having to mount the drive in a computer or install it in an external enclosure. Large capacity drives (tested with up to 4TB 3.5" and 1TB 2.5" drives) can be used to greatly enhance your computer's storage/backup capabilities.

Connected to the host computer through a single USB 3.0 SuperSpeed or USB 2.0 connection the hard drive docking station provides a convenient plug-and-play storage solution that delivers instant access to the hard drive without requiring a reboot.

Relying on the outstanding data throughput support of USB 3.0 the HDD docking station is capable of transfer speeds of up to 5Gbps making it the fastest way to access data from an external drive. Double the value of this hard drive docking station using a SATA to IDE hard drive adapter (SAT2IDEADP) which enables you to use any 2.5 or 3.5in IDE hard drive in a SATA hard drive dock slot.

o ensure compatibility with your computer system the SATDOCKU3S supports all of the leading operating system platforms including: Microsoft Windows Apple OSX Linux and Google Chrome OS

More from the Manufacturer

Number of Total Expansion Bays
1
Package Contents
  • SATA to 2.5in or 3.5in IDE Hard Drive Adapter for HDD Docks
  • 1 x 40-pin IDE Cable
  • 1 x 40-pin to 44-pin IDE Cable with Power
  • 1 x SP4 to LP4 Power Cable
  • 1 x Package of Mounting Screws
  • 1 x Installation Guide
Packaged Quantity
1
Product color
Black
Product Name
SATA to 2.5in or 3.5in IDE Hard Drive Adapter for HDD Docks
Product Type
IDE to SATA Adapter
Product Type
Drive Bay Adapter
Weight (Approximate)
3.67 oz
Width
3.1"
