CyberPower PDU20SWHVT10ATNET 200 - 240 VAC 20A Switched ATS PDU
CyberPower PDU20SWHVT10ATNET 200 - 240 VAC 20A Switched ATS PDU - 10 Outlets, 10 ft, 2 x NEMA L6-20P, Horizontal, 1U, LCD, 3YR Warranty
| $782.27 |
- 200V - 240V 20A Switched ATS PDU with 8 IEC-320 C13 outlets, 2 IEC-320 C19 outlets and dual NEMA L6-20P 20A high-voltage input connections
- Switched Automatic Transfer Switching (ATS) PDU to provide a redundant input power option
- Digital Display (Load, Voltage, and KW) for on-site monitoring of total PDU load
- SNMP/HTTP Network Interface for real-time outlet control, monitoring and event logging of the Switched ATS PDU
By:
CyberPower
Manufacturer:
CyberPower Systems, Inc
Product ID:
137227
Item:
PDU20SWHVT10ATNET
UPC Code:
649532610822
Our Part #
39121017
Condition
New
$782.27EA
Availability
Only 5 Left In Stock
Product description
CyberPower PDU20SWHVT10ATNET 200 - 240 VAC 20A Switched ATS PDU - 10 Outlets, 10 ft, 2 x NEMA L6-20P, Horizontal, 1U, LCD, 3YR Warranty
10 Outlets, 10 ft, 2 x NEMA L6-20P, Horizontal, 1U, LCD, 3YR Warranty
Specifications
PDU Type
Switched
Plug/Connector Detail
2 x NEMA L6-20P
Receptacle Detail
8 x IEC 60320 C13
Receptacle Detail
2 x IEC 60320 C19
UPC Alternates
649532610822 818214596031
Additional Information
- Phase: Single Phase
- Frequency: 50/60 Hz
- LCD Displays: Amperage Voltage KW Network Information and Hardware/LCD Firmware
- LED Indicators: Input Output Load Tx/Rx LINK Outlets
- Upgradeable Firmware: Yes - SNMP HW and LCD
Brand Name
CyberPower
Certifications & Standards
- UL60950-1 Certified by ETL (USA)
- CSA C22.2(Canada)
- FCC Class A
Cord Length
10 ft
Country of origin
China
Energy Star
No
Environmental Certification
RoHS
Environmentally Friendly
Yes
Height
1.8"
Input current
20 A
Input voltage
230 V AC
Length
9.3"
Limited Warranty
3 Year
Management
- Automatic Transfer Switch (ATS)
- SNMP/HTTP
Manufacturer
CyberPower Systems Inc
Manufacturer Part Number
PDU20SWHVT10ATNET
Manufacturer Website Address
http://www.cyberpowersystems.com
Marketing Information
The CyberPower PDU20SWHVT10ATNET 10-outlet 1U rack mount switched auto transfer switch (ATS) PDU provides 200-240V / 20A output. The PDU distributes power to 10 IEC-320 8-C13 / 2-C14 receptacles from redundant L5-20P plugs. Dual power cords can be plugged into separate power sources to provide redundancy to single-corded equipment. If there is a power failure or an under/over voltage the PDU will switch to the secondary power source to insure continuous operation.
The PDU includes a RMCARD203 SNMP card. With the SNMP card and an IP address on the network interface users have real-time monitoring and outlet control of the ATS PDU including event notifications.
The LCD provides local monitoring of voltage and amperage of the PDU and on/off control of the outlets.
The unit has a rugged industrial-grade metal housing and 10-foot AC power cords. It can be mounted horizontally includes a cord retention tray and is UL60950_1 & FCC Class A certified. A three-year warranty is standard.
The PDU includes a RMCARD203 SNMP card. With the SNMP card and an IP address on the network interface users have real-time monitoring and outlet control of the ATS PDU including event notifications.
The LCD provides local monitoring of voltage and amperage of the PDU and on/off control of the outlets.
The unit has a rugged industrial-grade metal housing and 10-foot AC power cords. It can be mounted horizontally includes a cord retention tray and is UL60950_1 & FCC Class A certified. A three-year warranty is standard.
- 200V - 240V 20A Switched ATS PDU with 8 IEC-320 C13 outlets 2 IEC-320 C19 outlets and dual NEMA L6-20P 20A high-voltage input connections
- Switched Automatic Transfer Switching (ATS) PDU to provide a redundant input power option
- Digital Display (Load Voltage and KW) for on-site monitoring of total PDU load
- SNMP/HTTP Network Interface for real-time outlet control monitoring and event logging of the Switched ATS PDU
Mount Type
Rack-mountable
Package Contents
- PDU20SWHVT10ATNET Switched ATS PDU 200-240V 20A 1U 10-Outlets (2) L6-20P
- RMCARD203 SNMP Card
- 1 x Mounting Brackets Set
- Cord Retention Tray
- Cord Organizers
- User Manual
Plug/Connector Type
NEMA L6-20P
Product Name
PDU20SWHVT10ATNET Switched ATS PDU 200-240V 20A 1U 10-Outlets (2) L6-20P
Product Series
Switched ATS PDU
Product Type
PDU
Rack Height
1U
Receptacle Type
IEC 60320 C13
Receptacle Type
IEC 60320 C19
Weight (Approximate)
12.35 lb
Width
17.1"
