ATEN HDMI HDBaseT Transmitter with Dual Output (4K@100m) (HDBaseT Class A)-TAA Compliant
ATEN HDMI HDBaseT Transmitter with Dual Output (4K@100m) (HDBaseT Class A)-TAA Compliant - 1 Input Device - 492.13 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
| $377.96 | Retail $409.00 |
- Extends HDMI signals to one local and two remote displays up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable
- HDMI (3D, Deep Color, 4K); HDCP 2.2 compatible
- Superior video quality:
- 4K up to 100 m
- 1080p up to 150 m when in HDBaseT Long Reach Mode
- Extends Ethernet communication using the Ethernet pass-through port
- Supports two IR channels for simultaneous IR signal transmissions, ranged from 30 KHz to 56 KHz
- ATEN EDID Technology -- when both transmitter and receiver sides are connected, VE814A adopts the EDID values of the display connected to the VE814AT for high-quality output
- RS-232 channel - allows you to connect to serial terminals or serial devices, such as touch screens and barcode scanners
- Supports wide screen format
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
140489
Item:
VE814AT
UPC Code:
672792007989
Our Part #
5DB959
Condition
New
$377.96EA
$409.00
$409.00
Availability
Only 5 Left In Stock
Product description
ATEN HDMI HDBaseT Transmitter with Dual Output (4K@100m) (HDBaseT Class A)-TAA Compliant - 1 Input Device - 492.13 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
1 Input Device - 492.13 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 1 x HDMI Out - 4K - 4096 x 2160 - Twisted Pair - Category 6a - Rack-mountable
Specifications
Transmitter Depth
5.35"
Transmitter Height
1.14"
Transmitter Weight (Approximate)
15.87 oz
Transmitter Width
3.98"
UPC Alternates
672792007989
Brand Name
ATEN
Connectivity technology
Wired
Country of origin
Taiwan
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
Rack-mountable
Graphics Modes
4K
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
VE814AT
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
ATEN VE814AT is an HDBaseT Video Transmitter that is capable of sending HDMI signals up to 100 m over a single Cat 5e/6/6a or ATEN 2L-2910 Cat 6 cable. Featuring dual synchronous outputs the VE814AT can transmit video signal to two remote displays and one at the local side. This HDCP 2.2-compliant transmitter meets the HDMI Specification including 3D Deep Color the maximum data rate of (10.2 Gbps) and 4K video quality up to 100 m.
The VE814AT supports RS-232 and IR signaling pass-through allowing you to control the HDMI source device from the remote unit (VE814AR) while granting access to the HDMI display device from the local unit (VE8014AT). In addition it supports Long Reach Mode that extends HDMI signals up to 150 m 1080p via a single Cat 5e/6 cable.
The VE814AT is a powerful solution for where digital signage is required such as bars educational spaces and public transportation stations allowing display of identical contents at different spots.
Maximum Operating Distance
492.13 ft
Maximum Video Resolution
4096 x 2160
Media Type Supported
Twisted Pair
Number of Network (RJ-45) Ports
1
Package Contents
- HDMI HDBaseT Transmitter with Dual Output (4K@100m) (HDBaseT Class A)
- 1 x RS-232 Terminal Block
- 1 x Power Adapter
- 1 x User Instructions
Product Line
VanCryst
Product Name
HDMI HDBaseT Transmitter with Dual Output (4K@100m) (HDBaseT Class A)
Product Type
Video Extender Transmitter
Twisted Pair Cable Standard
Category 6a
