Axiom Transceiver/Media Converter
Axiom Transceiver/Media Converter - 1 x Network (RJ-45) - 1 x ST Ports - DuplexST Port - Single-mode - Gigabit Ethernet - 1000Base-ZX, 10/100/1000Base-TX
| $192.01 |
- Expand your network capacity and fulfill requirement with this 2 transceiver/media converter
- Supports optical fiber cable for durable performance, minimal signal loss, and fast data transfers to greater distances
- With 1000Base-ZX technology get up to 1000Mbps data transfer rate over optical fiber cable
By:
Axiom
Manufacturer:
Axiom Memory Solutions
Product ID:
143837
Item:
MC03-S5T80-AX
UPC Code:
840177840050
Our Part #
8UK801
Condition
New
$192.01EA
Availability
Only 1 Left In Stock
Product description
Axiom Transceiver/Media Converter - 1 x Network (RJ-45) - 1 x ST Ports - DuplexST Port - Single-mode - Gigabit Ethernet - 1000Base-ZX, 10/100/1000Base-TX
1 x Network (RJ-45) - 1 x ST Ports - DuplexST Port - Single-mode - Gigabit Ethernet - 1000Base-ZX, 10/100/1000Base-TX
Specifications
Fiber Mode Supported
Single-mode
Fiber Optic Wavelength
1550 nm
Maximum Distance Supported
49.71 Mile
Network (RJ-45)
Yes
ST Port Type
Duplex
UPC Alternates
840177840050
Brand Name
Axiom
Ethernet Technology
Gigabit Ethernet
Limited Warranty
1 Year
Manufacturer
Axiom Memory Solutions
Manufacturer Part Number
MC03-S5T80-AX
Manufacturer Website Address
http://www.axiommemory.com
Marketing Information
Features
The Axiom Mini 10/100/1000Base-TX to 100/1000Base-FX Media Converter Series is a Gigabit Ethernet stand-alone Mini unmanaged media converter that provides cost effective entry-level media conversion between Copper RJ45 10/100/1000Base-TX ports and 100/1000Base-FX fiber optic ports. Available with an open SFP port or its fixed connector configuration deployments can be just plug-and-play or are fully customizable with the transceiver of your choice. With its small size it is ideal for locations where space is limited. Choose from Multimode or Single-mode fiber connections to meet the distance requirements of your network.
- Unit and Port LEDs allow for quick status information
- Auto-Negotiation
- Full-Duplex or Half-Duplex Operation Modes
- Auto-MDI/MDIX
- Automatic Link Restoration
- Connect to legacy network equipment
- Eliminate Collision Domains
- 10/100/1000Base-TX UTP to 1000Base-FX Fiber media convertion
- Supports IEEE802.3U IEEE802.3z 1000Base-TX/FX protocols IEEE802.3ab standards
- Available with Open SFP Port or optional built in LC/SC/ST Connections
- DIP switch to set different configurations
- Compact package size
- Supports IEEE802.3x flow control; 100Base-FX interface; auto MDI-MDIX function; LFP function
Media Type Supported
Optical Fiber
Media Type Supported
Twisted Pair
Network Technology
10/100/1000Base-TX
Network Technology
1000Base-ZX
Number of Network (RJ-45) Ports
1
Power source
DC
Product Type
Transceiver/Media Converter
Total Number of Ports
2
