8K 1x3 DisplayPort 1.4 to DisplayPort MST Hub Splitter
8K 1x3 DisplayPort 1.4 to DisplayPort MST Hub Splitter - Plug-n-play - Total Bandwidth 32.4Gbps (Max)
| $67.43 | Retail $119.99 |
- Enjoy the feast of movies with both video and sound device supported
- Features DisplayPort cable type
- Features Multi-Stream Transport (MST) Support
- Fully compatible with tablets
By:
SIIG
Manufacturer:
SIIG, Inc
Product ID:
144021
Item:
CE-DP0P11-S1
UPC Code:
662774043944
Our Part #
9BF076
Condition
New
$67.43EA
$119.99
$119.99
Availability
Only 526 Left In Stock
Product description
8K 1x3 DisplayPort 1.4 to DisplayPort MST Hub Splitter - Plug-n-play - Total Bandwidth 32.4Gbps (Max)
Plug-n-play - Total Bandwidth 32.4Gbps (Max)
Specifications
Connector on First End Details
1 x 20-pin DisplayPort 1.4 Digital Audio/Video - Male
Connector on Second End Details
3 x 20-pin DisplayPort 1.4 Digital Audio/Video - Female
Connector on Second End Details
1 x 5-pin Micro USB - Female
Connector Type on First End
DisplayPort 1.4 Digital Audio/Video - Male
Connector Type on Second End
Micro USB - Female
Connector Type on Second End
DisplayPort 1.4 Digital Audio/Video - Female
UPC Alternates
662774043944
Brand Name
SIIG
Cable Characteristic
Splitter Cable
Cable type
DisplayPort
Color
Black
Compatibility
Microsoft Surface Book
Microsoft Tablet:
- Surface Pro 2
- Surface Pro 3
- Surface Pro 4
AMD Graphics Card:
- RX560
- RX570
- Radeon 7200 Series
Connector on First End
DisplayPort Male Digital Audio/Video
Connector on First End
1 x 20-pin DisplayPort Male DisplayPort 1.4 Digital Audio/Video
Connector on Second End
3 x 20-pin DisplayPort Female DisplayPort 1.4 Digital Audio/Video
Connector on Second End
DisplayPort Female Digital Audio/Video
Connector on Second End
Micro USB Female Power
Connector on Second End
1 x 5-pin Micro USB Female Power
Country of origin
China
Data transfer rate
32.4 Gbit/s
Device Supported
Notebook
Device Supported
Desktop Computer
Device Supported
Tablet
Device Supported
Monitor
Device Supported
Graphics Card
Device Supported
Audio/Video Device
Environmental Certification
RoHS
Environmentally Friendly
Yes
Features
HDR Support
Features
Eyefinity Technology
Features
Display Stream Compression (DSC)
Features
EMI Protection
Features
Mirror Display Mode
Features
HDCP 2.2
Features
Plug & Play
Features
Extended Display Mode
Features
Multi-Stream Transport (MST) Support
Limited Warranty
2 Year
Manufacturer
SIIG Inc
Manufacturer Part Number
CE-DP0P11-S1
Manufacturer Website Address
http://www.siig.com
Marketing Information
- Connect up to three DisplayPort displays to single DisplayPort 1.4 output with Multi-Stream Transport (MST) technology to boost your productivity
- Provides multiple display modes such as Mirror mode same content on each display Extended mode with individual content on each display and Panoramic Video Wall mode which combines multiple monitors to use as one large display
Note: Mirror mode using a NVIDIA Surround technology graphics adapter is limited to 2 displays. Video Wall mode requires either a AMD Eyefinity Intel or NVIDIA Surround technology graphics adapter - Total Bandwidth 32.4Gbps (max): Supports one UHD 8K (7680 x 4320)@30Hz display two 4K@60Hz displays three or four 4K (3840x2160)@30Hz or less displays. Other resolution combinations which are less than or equal to 4K@30Hz will work also. For example three 2K three 1080p 4K+2K+1080p etc.
Note: The total combined bandwidth among all connected displays must NOT exceed the total maximum bandwidth - Compatible with DisplayPort 1.4 with MST graphics cards with AMD Eyefinity Intel Collage or NVIDIA Surround technology
- Supports 4K HDR and HDCP 2.2
- Reset button allows re-detection of all the displays if any of the displays are not detected
- Plug-n-play trouble-free set up without complicated hardware or driver installation
- High quality aluminum housing decreases surrounding electro magnetic interference and provides optimal video quality
Note: Replaces CE-DP0D12-S1
Compatibility Notes:
- Requires either AMD Eyfinity or Intel Collage or NVIDIA Surround technology graphics adapter for Video Wall mode
- Requires a DisplayPort 1.4 graphics card to support minimum of 3 external displays
- Mirror mode using Windows Display Uility and NVIDIA Utility is limited to 2 displays
Package Contents
- 1x3 Triple 4K DisplayPort 1.4 to DisplayPort MST Hub Splitter
- Micro-USB power cable
- Quick Start Guide
Product color
Black
Product Name
1x3 Triple 4K DisplayPort 1.4 to DisplayPort MST Hub Splitter
Product Type
A/V Cable
Supported Resolution
7680 x 4320
Weight (Approximate)
0.28 lb
