Allied Telesis GS950/18PS V2 Ethernet Switch
Allied Telesis GS950/18PS V2 Ethernet Switch - 16 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T, 100/1000Base-X - 2 Layer Supported - Modular - 2 SFP Slots - Power Supply - 75 W Power Consumption - 185 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Wall Mountable, Rack-mountable, Desktop
| $805.10 | Retail $872.00 |
- VLAN: IEEE 802.1Q tagged - Port-based - Up to 256 groups
- Quality of Service Classification: IEEE 802.1p tagging - Port-based priority - Four priority queues per port
- IP Multicast Support (IPv4) - IGMP snooping (v1/v2) - Static multicast group (up to 256) - Spanning-Tree, IEEE 802.1d/w/s
- IEEE 802.3ad Link Aggregation: Manual - LACP
- IEEE 802.1x Port-based, MAC-based and Network Access Control: Local authentication server (MD5 only) - Remote authentication through RADIUS - Dynamic VLAN assignment - RADIUS Client
- Other: IEEE 802.3x flow control or HOL blocking prevention ( when flow control is off) - Port mirroring - Destination MAC filtering - Ingress/egress rate limiting - Broadcast storming control - 100 FX SFP support - Jumbo Frames - up to 10K
- Management Features: SSH - Telnet - Web-based configuration - CLI configuration - SNMP trap view - LLDP - Firmware upgrade by FTP and HTTP - Configuration backup/restore by FTP and
By:
Allied Telesis
Manufacturer:
Allied Telesis, Inc
Product ID:
144499
Item:
AT-GS950/18PS V2-10
UPC Code:
767035219165
Our Part #
9VT266
Condition
New
$805.10EA
$872.00
$872.00
Availability
Only 2 Left In Stock
You may be also interested
Product description
Allied Telesis GS950/18PS V2 Ethernet Switch - 16 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T, 100/1000Base-X - 2 Layer Supported - Modular - 2 SFP Slots - Power Supply - 75 W Power Consumption - 185 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Wall Mountable, Rack-mountable, Desktop
16 Ports - Manageable - Gigabit Ethernet - 10/100/1000Base-T, 100/1000Base-X - 2 Layer Supported - Modular - 2 SFP Slots - Power Supply - 75 W Power Consumption - 185 W PoE Budget - Twisted Pair, Optical Fiber - PoE Ports - Wall Mountable, Rack-mountable, Desktop
Specifications
PoE Budget
185 W
Total Number of Network Ports
16
UPC Alternates
767035219165
Brand Name
Allied Telesis
Depth
9.8"
Environmental Certification
EU RoHS
Environmental Certification
RoHS
Environmental Certification
China RoHS
Ethernet Technology
Gigabit Ethernet
Expansion Slot Type
SFP (mini-GBIC)
Form factor
Rack-mountable
Form factor
Desktop
Form factor
Wall Mountable
Height
1.7"
Layer Supported
2
Manageable
Yes
Manufacturer
Allied Telesis Inc
Manufacturer Part Number
AT-GS950/18PS V2-10
Manufacturer Website Address
http://www.alliedtelesis.com
Marketing Information
The Allied Telesis GS950/18PS V2 Gigabit PoE+ WebSmart switch features 16 x 10/100/1000T ports and two SFP ports delivering up to 30 Watts per port (PoE+) to support video surveillance cameras wireless access points IP phones and other PoE powered devices. PoE+ eliminates the need for separate power cabling and minimizes the clutter of power supplies and adapters for simplified deployment. Thanks to its compact size the AT-GS950/18PS V2 is ideal for the edge of SMB businesses classrooms cafes and Point of Sale (POS) applications.
Media Type Supported
Optical Fiber
Media Type Supported
Twisted Pair
Network Technology
10/100/1000Base-T
Network Technology
100/1000Base-X
Networking standards
IEEE 802.3i
Networking standards
IEEE 802.1p
Networking standards
IEEE 802.1w
Networking standards
IEEE 802.3at
Networking standards
IEEE 802.3ab
Networking standards
IEEE 802.3x
Networking standards
IEEE 802.1D
Networking standards
IEEE 802.3
Networking standards
IEEE 802.1s
Networking standards
IEEE 802.3af
Networking standards
IEEE 802.1x
Networking standards
IEEE 802.3ad
Networking standards
IEEE 802.3u
Networking standards
IEEE 802.3az
Networking standards
IEEE 802.1Q
Networking standards
IEEE 802.3z
Package Contents
- GS950/18PS V2 Ethernet Switch
- Rack-mount Brackets and Screws
- US Power Cord
- Rubber Feet
Port/Expansion Slot Details
2 x Gigabit Ethernet Expansion Slot
Port/Expansion Slot Details
16 x Gigabit Ethernet PoE+
Power consumption
75 W
Power source
Power Supply
Product Model
GS950/18PS V2
Product Name
GS950/18PS V2 Ethernet Switch
Product Series
GS950 V2
Product Type
Ethernet Switch
Weight (Approximate)
8.16 lb
Width
17.3"
