Tripp Lite N785-I01-SFP-D Transceiver/Media Converter
Tripp Lite N785-I01-SFP-D Transceiver/Media Converter - 1 x Network (RJ-45) - Multi-mode, Single-mode - Gigabit Ethernet - 10/100/1000Base-T, 100/1000Base-X - 1 x Expansion Slots - SFP (mini-GBIC) - 1 x SFP Slots - DIN Rail Mountable - TAA Compliant
| $169.75 | Retail $248.00 |
- Connect different types of media within a network with this single port
- With Twisted Pair cable, get the desired data transfer rate up to a required distance
- With 10/100/1000Base-T technology get up to 1000Mbps data transfer rate over supported network cable
- The DIN Rail Mountable provides convenient installation
By:
Tripp Lite
Manufacturer:
Tripp Lite by Eaton
Product ID:
144512
Item:
N785-I01-SFP-D
UPC Code:
037332268587
Our Part #
9VB874
Condition
New
$169.75EA
$248.00
$248.00
Availability
Only 101 Left In Stock
Product description
Tripp Lite N785-I01-SFP-D Transceiver/Media Converter - 1 x Network (RJ-45) - Multi-mode, Single-mode - Gigabit Ethernet - 10/100/1000Base-T, 100/1000Base-X - 1 x Expansion Slots - SFP (mini-GBIC) - 1 x SFP Slots - DIN Rail Mountable - TAA Compliant
1 x Network (RJ-45) - Multi-mode, Single-mode - Gigabit Ethernet - 10/100/1000Base-T, 100/1000Base-X - 1 x Expansion Slots - SFP (mini-GBIC) - 1 x SFP Slots - DIN Rail Mountable - TAA Compliant
Specifications
Fiber Mode Supported
Single-mode
Fiber Mode Supported
Multi-mode
Number of Total Expansion Slots
1
UPC Alternates
037332268587
Brand Name
Tripp Lite
Country of origin
Taiwan
Depth
3.8"
Environmental Certification
RoHS
Environmentally Friendly
Yes
Ethernet Technology
Gigabit Ethernet
Expansion Slot Type
SFP (mini-GBIC)
Form factor
DIN Rail Mountable
Height
0.6"
Limited Warranty
2 Year
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
N785-I01-SFP-D
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Features | Customize a Network Extension over Fiber Optic Cable
This network media converter works with a variety of SFP transceivers to convert a copper Gigabit Ethernet signal to fiber optic and extend it to a second network device. The customizable SFP port supports both singlemode and multimode transceivers allowing your network connection to reach hubs switches and other devices located farther away than copper cabling's 100-meter limit. Auto-negotiation and automatic MDI/MDI-X configuration seamlessly connect devices without crossover cabling.
Monitor Your Installation with Link Fault Signaling and Loop Back Functions
Determine the health of your network connection via the Link Fault Signaling (LFS) and Line Loop Back (LLB) functions. The LFS LED indicates when a copper or fiber cable has been severed or another cause of disruption in service has occurred. The LLB diagnostic test ensures copper and fiber cables have been correctly installed. Use the DIP switches to control each function or turn them on or off.
LEDs Indicate Installation Performance and Diagnostic Functions
Easy-to-read LEDs on the side of the unit indicate essential status information including network speed and connection LFS diagnostics and unit power. The included 20-57VDC terminal block provides primary and secondary power inputs.
Protective Metal Housing Built to Withstand a Variety of Hazards
The IP30 industrial-grade aluminum case is protected from entry by tools wires and other solid objects greater than 2.5 millimeters in diameter. It can also operate in extreme temperatures ranging from -40 to 75 degrees Celsius (-40 to 167 degrees Fahrenheit). It is protected from electrostatic discharge (ESD) radio frequency interference (RFI) and power surges. Hardware is included for DIN mounting.
TAA-Compliant for GSA Schedule Purchases
The N785-I01-SFP-D is compliant with the Federal Trade Agreements Act (TAA) which makes it eligible for GSA (General Services Administration) Schedule and other federal procurement contracts.
Media Type Supported
Optical Fiber
Media Type Supported
Twisted Pair
Network Technology
100/1000Base-X
Network Technology
10/100/1000Base-T
Package Contents
- N785-I01-SFP-D Transceiver/Media Converter
- SFP Connector Cap
- RJ45 Connector Cap
- Terminal Block (20-57VDC)
- DIN Rail Kit
- Quick Start Guide
Plug/Connector Type
Terminal Block
Power consumption
6 W
Power source
AC Adapter
Product Name
N785-I01-SFP-D Transceiver/Media Converter
Product Type
Transceiver/Media Converter
Weight (Approximate)
14.88 oz
Width
1.8"
