Asus ROG Strix Z690-G GAMING WIFI Desktop Motherboard - Intel Z690 Chipset - Socket LGA-1700 - Intel Optane Memory Ready - Micro ATX
Asus ROG Strix Z690-G GAMING WIFI Desktop Motherboard - Intel Z690 Chipset - Socket LGA-1700 - Intel Optane Memory Ready - Micro ATX - Pentium Gold, Celeron, Core i5, Core i7, Core i9 Processor Supported - 128 GB DDR5 SDRAM Maximum RAM - DIMM, UDIMM - 4 x Memory Slots - IEEE 802.11 a/b/g/n/ac/ax/az - HDMI - DisplayPort - 6 x SATA Interfaces
| $3,720.31 |
- Experience responsive performance, power and adaptability with the compatible Intel Celeron processor
- DDR5 SDRAM slot for convenient installation of memory
- RAID supported levels provide data reliability and fault tolerance
- Wireless support reduces the number of cables required to connect peripherals
- HDMI interface connects variety of HD devices including Gaming Controllers, Blu-ray players, laptops, PCs, digital cameras and many others for you to experience the ultimate HD display
- DisplayPort transmits both audio and video signals through a common channel to deliver versatile performance
- Micro ATX form factor brings a significant number of PCI slots, expansion slots, and peripheral ports with an enhanced heat dissipation capability
- With 2 USB 2.0 ports, connect devices for a quick data movement
By:
Asus ROG
Manufacturer:
ASUS Computer International
Product ID:
146131
Item:
ROG STRIX Z690-G GAMING WIFI
Our Part #
43201513
Condition
New
$3,720.31EA
Availability
Only 28 Left In Stock
Product description
Asus ROG Strix Z690-G GAMING WIFI Desktop Motherboard - Intel Z690 Chipset - Socket LGA-1700 - Intel Optane Memory Ready - Micro ATX - Pentium Gold, Celeron, Core i5, Core i7, Core i9 Processor Supported - 128 GB DDR5 SDRAM Maximum RAM - DIMM, UDIMM - 4 x Memory Slots - IEEE 802.11 a/b/g/n/ac/ax/az - HDMI - DisplayPort - 6 x SATA Interfaces
Pentium Gold, Celeron, Core i5, Core i7, Core i9 Processor Supported - 128 GB DDR5 SDRAM Maximum RAM - DIMM, UDIMM - 4 x Memory Slots - IEEE 802.11 a/b/g/n/ac/ax/az - HDMI - DisplayPort - 6 x SATA Interfaces
Specifications
Chipset Model
Z690
Maximum Memory Supported
128 GB
Memory Speed Supported
4800 MHz
Memory Speed Supported
5200 MHz
Memory Speed Supported
5400 MHz
Memory Speed Supported
5000 MHz
Memory Speed Supported
5800 MHz
Memory Speed Supported
5600 MHz
Memory Speed Supported
6000 MHz
Number of Memory Slots
4
Number of PCI Express x16 Slots
2
Number of SATA Interfaces
6
Number of Total Expansion Slots
3
Onboard Video
CPU Dependent Video
Processor Generation Supported
12th Gen
Processor Socket
Socket LGA-1700
Processor Supported
Core i7
Processor Supported
Celeron
Processor Supported
Core i5
Processor Supported
Pentium Gold
Processor Supported
Core i9
Total Number of Onboard USB Ports
7
Wireless LAN Standard
IEEE 802.11 a/b/g/n/ac/ax/az
Audio Channels
7.1
Bluetooth
Yes
Brand Name
Asus ROG
Chipset Manufacturer
Intel
Controller Type
Serial ATA/600
Form factor
Micro ATX
Manufacturer
ASUS Computer International
Manufacturer Part Number
ROG STRIX Z690-G GAMING WIFI
Manufacturer Website Address
http://usa.asus.com
Marketing Information
Intel® Z690 LGA 1700 ATX motherboard with PCIe® 5.0 14+1 DrMos DDR5 memory support Two-Way AI Noise Cancelation AI Overclocking AI Cooling AI Networking WiFi 6E (802.11ax) Intel® 2.5 Gb Ethernet three M.2 slots with heatsinks PCIe® 4.0 NVMe® SSD support M.2 backplates USB 3.2 Gen 2x2 Type-C® SATA and AURA Sync RGB lighting
- Intel® LGA 1700 socket: Ready for 12th Gen Intel Core™ Pentium® Gold and Celeron® Processors
- Optimal Power Solution: 14+1 DrMos with ProCool II power connector high-quality alloy chokes and durable capacitors to support multi-core processors
- Optimized Thermal Design: Integrated I/O cover and VRM heatsinks with high conductivity thermal pad three onboard M.2 heatsinks and M.2 backplates for two M.2 slots
- High-performance Networking: On-board Intel® WiFi 6E (802.11ax) and Intel® 2.5 Gb Ethernet with ASUS LANGuard
- Best Gaming Connectivity: Supports HDMI® 2.1 and DisplayPort™ 1.4 output three M.2 slots as well as USB 3.2 Gen 2x2 Type-C®
- Intelligent Control: ASUS-exclusive AI Overclocking and Two-Way AI Noise Cancelation to simplify setup and improve performance
- DIY Friendly Design: M.2 Q-Latch pre-mounted I/O shield BIOS FlashBack™ button and Clr CMOS button
- Unmatched Personalization: ASUS-exclusive Aura Sync RGB lighting including a RGB header and three addressable Gen 2 headers
- Industry-leading Gaming Audio: High fidelity audio with ALC4080 with Savitech SV3H712 amplifier along with DTS® Sound Unbound and Sonic Studio III
- Renowned Software: Bundled AIDA64 Extreme 60 days free trial version and intuitive UEFI BIOS dashboard with integrated MemTest86
ROG STRIX Z690-G GAMING WIFI
ROG Strix Z690-G Gaming WiFi is the premiere choice for enthusiasts who enjoy building compact mATX setups. Premium-grade power delivery cooling and the latest networking standards have been packed in to ride alongside DDR5 and PCIe 5.0 unleashing the full force of 12th Gen Intel® Core™ processors. And layered on top there's a stack of ASUS-exclusive intelligent controls to optimize every aspect of system performance.
Memory form factor
DIMM
Memory form factor
UDIMM
Memory Technology
DDR5 SDRAM
Product Line
Strix
Product Model
Z690-G GAMING WIFI
Product Name
Strix Z690-G GAMING WIFI Desktop Motherboard
Product Type
Desktop Motherboard
RAID Levels
10
RAID Levels
0
RAID Levels
1
RAID Levels
5
Width
9.6"
