StarTech.com 2-Port USB-C MST Hub, Dual-DisplayPort up to 4K 60Hz w/ DP 1.4 Alt Mode & DSC, Multi-Monitor Adapter/Splitter, Windows Only
StarTech.com 2-Port USB-C MST Hub, Dual-DisplayPort up to 4K 60Hz w/ DP 1.4 Alt Mode & DSC, Multi-Monitor Adapter/Splitter, Windows Only - USB-C to Dual-DisplayPort MST Hub for 2x 4K 60Hz displays; Discrete GPUs/12th gen and up Intel Processors w/ DP 1.4 required for 2x 4K 60Hz monitors; Works with DP 1.2 hosts at lower resolutions; Driverless; 1ft cable; USB Bus Powered; Windows Only
| $74.72 | Retail $104.99 |
- MULTI-MONITOR CONFIGURATION: USB-C to Dual-DisplayPort MST Hub drives up to two 4K 60Hz displays from a USB-C DP 1.4 host with DSC; Supports HDR and 2ch Audio; HDCP 2.2; Backwards compatible with DP 1.4 and DP 1.2 hosts at lower resolutions
- IT PRO PERFORMANCE: Increase productivity by adding up to two extended/mirrored displays to a Windows laptop; Utilize the host's built-in GPU capabilities, enabling high performance graphics, with minimal CPU usage and no driver installation required
- HARDWARE COMPATIBILITY: Windows computers with discrete GPUs or 12th gen and up Intel Processors featuring DP 1.4 with DSC, to support dual-4K 60Hz monitors; See resolution chart below for a list of other supported display configurations
- EXTRA-LONG CABLE: 1ft (30 cm) built-in cable for extended reach reduces port/connector strain on 2-in-1 devices such as Surface Pro 7/8, iPad Pro, HP Elite x2, and laptops on riser stands; Ideal for on-the-go travel use in office/home/s
Manufacturer:
StarTech.com
Product ID:
148293
Item:
MST14CD122DP
UPC Code:
065030884372
Our Part #
09PL28
Condition
New
$74.72EA
$104.99
$104.99
Availability
Only 8894 Left In Stock
Product description
StarTech.com 2-Port USB-C MST Hub, Dual-DisplayPort up to 4K 60Hz w/ DP 1.4 Alt Mode & DSC, Multi-Monitor Adapter/Splitter, Windows Only - USB-C to Dual-DisplayPort MST Hub for 2x 4K 60Hz displays; Discrete GPUs/12th gen and up Intel Processors w/ DP 1.4 required for 2x 4K 60Hz monitors; Works with DP 1.2 hosts at lower resolutions; Driverless; 1ft cable; USB Bus Powered; Windows Only
USB-C to Dual-DisplayPort MST Hub for 2x 4K 60Hz displays; Discrete GPUs/12th gen and up Intel Processors w/ DP 1.4 required for 2x 4K 60Hz monitors; Works with DP 1.2 hosts at lower resolutions; Driverless; 1ft cable; USB Bus Powered; Windows Only
Specifications
Connector Gender on First End
Male
Connector Gender on Second End
Female
Connector on First End Details
1 x 24 Pin USB Type C - Male
Connector on Second End Details
2 x DisplayPort 1.4 Digital Audio/Video - Female
Connector Type on First End
USB Type C - Male
Connector Type on Second End
DisplayPort 1.4 Digital Audio/Video - Female
Product Material
Plastic
UPC Alternates
065030884372
Adapter Type
DisplayPort/USB-C
Cable length
11.80"
Country of origin
China
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Features
Multi-Stream Transport (MST) Support
Features
HDR Support
Features
Strain Relief
Features
Display Stream Compression (DSC)
Features
HDCP 2.2
Features
Plug and Play
Features
Active
Limited Warranty
3 Year
Manufacturer
StarTech.com
Manufacturer Part Number
MST14CD122DP
Manufacturer Website Address
http://www.startech.com
Marketing Information
This USB-C to DisplayPort MST Hub enables a connection to two DisplayPort monitors using a DisplayPort Alternate Mode (DP Alt Mode) capable USB-C host device.
4K at 60Hz with HDR
Multi-Stream Transport (MST) technology combines multiple video signals into a single output signal/stream. This MST Hub separates the single input stream into two independent signals one for each DisplayPort-enabled display. Support for High Dynamic Range (HDR) offers increased contrast brightness colors and luminosity.
Host Connection Maximum Resolution Output 1 Maximum Resolution Output 2 Example Host Processor/Graphics DisplayPort 1.4 with DSC 5K 60Hz 5K 60Hz *Intel 11th Gen with DSC Intel 12th Gen Processors & Later Discrete AMD & Nvidia GPU's that support DSC DisplayPort 1.4 4K 60Hz 4K 60Hz Intel 10th Gen (Ice Lake Only) Intel 11th Gen Processors & Later Discrete AMD and Nvidia GPU's that support DP 1.4 DisplayPort 1.2 4K 30Hz 4K 30Hz Intel 8th - 10th Gen Processors & LaterMultitasking Made Easy
Configure the dual-DP displays in extended or mirrored mode. Create a high-performance workstation by adding two independent 4K 60Hz displays. This empowers increased multi-tasking across your organization resulting in increased productivity.
Hassle-Free Setup
Windows devices supporting DP Alt Mode over USB-C feature native support for MST. This USB-C to DP hub is compatible Thunderbolt 3/4 and USB4-enabled Windows devices with 11th generation (and later) processors. Plug-and-play installation with no drivers or software required. The 12in (30cm) built-on cable provides options for flexible installation configurations reducing the amount of strain on ports and connectors. Additionally this dual-monitor splitter is bus-powered requiring no external power source.
This product is backed for 3 years including free lifetime 24/5 multilingual technical assistance.
Maximum Resolution Supported
3840 x 2160
Packaged Quantity
1
Product color
Space Gray
Product Type
Video Adapter
