Black Box Audio/Video Extender
Black Box Audio/Video Extender - 2 x Network (RJ-45) - 2 x HDMI - 328 ft Extended Range - Black
| $629.28 | Retail $700.00 |
- Non-Returnable
- HDCP 2.2 compliant
- HD signal transmission via a single CAT5e/CAT6 cable up to 100 m (1080p) and 70 m (4K at 60 Hz YUV 4:4:4)|HD signal transmission via a single CAT6A/7 cable up to 100 m (1080p) and 100 m (4K at 60 Hz YUV 4:4:4)
- IR pass-through allows you to control the source from the display location or control the display from the source location
- Use two RS-232 control systems for serial communication by connecting to the devices via serial cables to control the source device or display
By:
Black Box
Manufacturer:
Black Box Corporation
Product ID:
152564
Item:
AVX-HDMI2-HDB-R2
UPC Code:
822088279396
Our Part #
43222608
Condition
New
$629.28EA
$700.00
$700.00
Availability
Only 4 Left In Stock
Product description
Black Box Audio/Video Extender - 2 x Network (RJ-45) - 2 x HDMI - 328 ft Extended Range - Black
2 x Network (RJ-45) - 2 x HDMI - 328 ft Extended Range - Black
Specifications
Maximum Extended Range
328 ft
Number of HDMI Ports
2
UPC Alternates
822088279396
Brand Name
Black Box
Country of origin
China
Depth
3.7"
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Height
0.8"
Limited Warranty
2 Year
Manufacturer
Black Box Corporation
Manufacturer Part Number
AVX-HDMI2-HDB-R2
Manufacturer Website Address
http://www.blackbox.com
Marketing Information
Send high-quality video and audio signals farther without replacing the copper cable with this HDMI 2.0 Extender. In compliance with HDR and HDCP 2.2 standards it supports 4K at 60 Hz 4:4:4 resolution Dolby and DTS HD audio and bi-directional IR control in a low-profile box.
The extender consists of a transmitter and a receiver. Configure the ARC channel feed for a TV (with ARC support) or an auxiliary S/PDIF input port via an audio output DIP switch on the receiver. The extender uses proprietary one-way PoC technology to power the receiver from the transmitter. LEDs show power and signal status for established connections between devices.
With increased bandwidth up to 18 Gbps you can extend signals over CATx cable up to 328 ft. while maintaining:
- Higher resolutions
- Higher frame rates
- Multiple full HD streams in the same pipe
- 21:9 aspect ratio
Secure and Compliant
A locking HDMI connector prevents accidental cable disconnects and the extender has CE FCC IC RCM and VCCI approvals.
Package Contents
- 1 x Transmitter
- 1 x Receiver
- 1 x Power Adapter (12 VDC 2 A)
- 2 x Phoenix Male Connectors (3.5-MM 3-PIN)
- 1 x IR Emitter Cable
- 1 x IR Broadband Receiver Cable (30 KHZ - 50 KHZ)
- 4 x Mounting Brackets
Product color
Black
Product Type
Audio/Video Extender
Width
6.8"
