Aruba CX 8360v2 8360-48Y6C Ethernet Switch
Aruba CX 8360v2 8360-48Y6C Ethernet Switch - Manageable - 25 Gigabit Ethernet, 100 Gigabit Ethernet - 25GBase-X, 100GBase-X - TAA Compliant - 3 Layer Supported - Modular - 725 W Power Consumption - Optical Fiber - 1U High - Cabinet Mount, Surface Mount, Rack-mountable
| $22,656.95 | Retail $53,385.00 |
- Effectively increases available bandwidth on your network
- Lets you conveniently connect different networks to enable improved flexibility to your infrastructure
- Built-in power supply to ensure all components are being supplied with accurate voltage
- Supports layer 3 switching for enhanced performance and usability
- Easily mountable on a flat surface
- Management capability allows maximum efficiency and with unrestricted control
- Lets you conveniently connect to the 25 gigabit ethernet Ethernet technology to offer maximum productivity
- Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
By:
Aruba
Manufacturer:
Hewlett Packard Enterprise
Product ID:
153328
Item:
JL719C
UPC Code:
190017568140
Our Part #
06QM24
Condition
New
$22,656.95EA
$53,385.00
$53,385.00
Availability
Only 9999 Left In Stock
Product description
Aruba CX 8360v2 8360-48Y6C Ethernet Switch - Manageable - 25 Gigabit Ethernet, 100 Gigabit Ethernet - 25GBase-X, 100GBase-X - TAA Compliant - 3 Layer Supported - Modular - 725 W Power Consumption - Optical Fiber - 1U High - Cabinet Mount, Surface Mount, Rack-mountable
Manageable - 25 Gigabit Ethernet, 100 Gigabit Ethernet - 25GBase-X, 100GBase-X - TAA Compliant - 3 Layer Supported - Modular - 725 W Power Consumption - Optical Fiber - 1U High - Cabinet Mount, Surface Mount, Rack-mountable
Specifications
Compatible Rack Unit
1U
Number of Power Supplies Supported
2
Number of Total Expansion Slots
54
UPC Alternates
190017568140
Application/Usage
Business
Application/Usage
Data Center
Brand Name
Aruba
Depth
22"
Ethernet Technology
100 Gigabit Ethernet
Ethernet Technology
25 Gigabit Ethernet
Expansion Slot Type
QSFP28
Expansion Slot Type
SFP28
Form factor
Rack-mountable
Form factor
Cabinet Mount
Form factor
Surface Mount
Frequency
47 Hz
Frequency
63 Hz
Height
1.7"
Input voltage
120 V AC
Input voltage
230 V AC
Layer Supported
3
Manageable
Yes
Manufacturer
Hewlett Packard Enterprise
Manufacturer Part Number
JL719C
Manufacturer Website Address
http://www.hpe.com
Marketing Information
The Aruba CX 8360 v2 Switch Series offers a flexible and innovative approach to addressing the application security and scalability demands of the mobile cloud and IoT era. These switches serve the needs of the next-generation core and aggregation layer of campuses as well as virtual and highly dynamic data center environments. They provide up to 3.6Tbps of capacity with line-rate Gigabit Ethernet interfaces including support for Smart Rate (1/2.5 5 Gbps) 10Gbps 25Gbps 40Gbps 50 Gbps and 100Gbps.
The 8360 series includes industry-leading line rate ports with 1/10/25/50GbE (SFP/SFP+/SFP28) and 40/100GbE (QSFP+/ QSFP28) connectivity in a compact 1U form factor. 4x10Gbps and 4x25Gbps break out from 40/100G ports offer advanced flexibility in connectivity and aggregation. These switches deliver a fantastic investment for customers wanting to migrate from older 1GbE/10GbE to faster 25GbE or from 10GbE/40GbE uplinks to 50/100GbE ports.
In addition the 48 and 32 x 25G port 8360 models support low- density MACsec ports and enable secured connectivity at 10GbE and 25GbE over unsecured domains. And MACsec with 2 x40/100G port with the 48x25 8360 model.
PRODUCT DIFFERENTIATORS
The Aruba CX 8360 switch series is based on ArubaOS-CX a modern database-driven operating system that automates and simplifies many critical and complex tasks. The enhanced capabilities of ArubaOS-CX provide a unique set of differentiators for campus and data center switching.
Modular Architecture with native cloud-native ArubaOS-CX
ArubaOS-CX is built on a modular Linux architecture with OVSDB providing the following unique capabilities:
ArubaOS-CX includes Aruba's Network Analytics Engine (NAE) for advanced telemetry and automation. The NAE framework is an industry-first monitoring and troubleshooting system providing greatly improved network operations. NAE uniquely provides the ability to monitor and easily troubleshoot network health and congestion issues. The Time Series Database (TSDB) may be used to store configuration and operational state.
The 8360 series includes industry-leading line rate ports with 1/10/25/50GbE (SFP/SFP+/SFP28) and 40/100GbE (QSFP+/ QSFP28) connectivity in a compact 1U form factor. 4x10Gbps and 4x25Gbps break out from 40/100G ports offer advanced flexibility in connectivity and aggregation. These switches deliver a fantastic investment for customers wanting to migrate from older 1GbE/10GbE to faster 25GbE or from 10GbE/40GbE uplinks to 50/100GbE ports.
In addition the 48 and 32 x 25G port 8360 models support low- density MACsec ports and enable secured connectivity at 10GbE and 25GbE over unsecured domains. And MACsec with 2 x40/100G port with the 48x25 8360 model.
PRODUCT DIFFERENTIATORS
The Aruba CX 8360 switch series is based on ArubaOS-CX a modern database-driven operating system that automates and simplifies many critical and complex tasks. The enhanced capabilities of ArubaOS-CX provide a unique set of differentiators for campus and data center switching.
Modular Architecture with native cloud-native ArubaOS-CX
ArubaOS-CX is built on a modular Linux architecture with OVSDB providing the following unique capabilities:
- Safe and powerful access to all state at all times allows unique visibility and analytics capabilities
- REST APIs and Python scripting provide fine-grained microservices architecture enabling full integration with other workflow systems and services
- Supports Aruba Fabric Composer - a software-defined orchestration solution that simplifies and accelerates leaf-spine network provisioning and day-to-day operations across rack-scale compute and storage infrastructure.
- Continual state synchronization provides superior fault tolerance and high availability
- All software processes communicate with the database rather than with each other ensuring high stability with minimal inter-process communication
ArubaOS-CX includes Aruba's Network Analytics Engine (NAE) for advanced telemetry and automation. The NAE framework is an industry-first monitoring and troubleshooting system providing greatly improved network operations. NAE uniquely provides the ability to monitor and easily troubleshoot network health and congestion issues. The Time Series Database (TSDB) may be used to store configuration and operational state.
Media Type Supported
Optical Fiber
Network Technology
25GBase-X
Network Technology
100GBase-X
Networking standards
IEEE 802.1ak
Networking standards
IEEE 802.1D
Networking standards
IEEE 802.3ad
Networking standards
IEEE 802.3ae
Networking standards
IEEE 802.3by
Networking standards
IEEE 802.3cc
Networking standards
IEEE 802.3x
Networking standards
IEEE 802.1AX
Networking standards
IEEE 802.3ba
Networking standards
IEEE 802.3z
Networking standards
IEEE 802.3cd
Networking standards
IEEE 802.1Q
Networking standards
IEEE 802.1AEbw
Networking standards
IEEE 802.1Qbb
Networking standards
IEEE 802.1v
Networking standards
IEEE 802.1p
Networking standards
IEEE 802.3bj
Networking standards
IEEE 802.1AEbn
Networking standards
IEEE 802.3an
Networking standards
IEEE 802.1x
Networking standards
IEEE 802.1w
Networking standards
IEEE 802.1ae
Networking standards
IEEE 802.1ab
Networking standards
IEEE 802.1s
Networking standards
IEEE 802.1t
Port/Expansion Slot Details
48 x 25 Gigabit Ethernet Expansion Slot
Port/Expansion Slot Details
6 x 100 Gigabit Ethernet Expansion Slot
Power consumption
725 W
Power source
Power Supply
Product Model
8360-48Y6C
Product Name
CX 8360v2 8360-48Y6C Ethernet Switch
Product Series
CX 8360v2
Product Type
Ethernet Switch
Weight (Approximate)
23.65 lb
Width
17.4"
