Microchip PD-9601GCO Outdoor PoE Midspan
Microchip PD-9601GCO Outdoor PoE Midspan - 1-Port, IP67, IEEE® 802.3bt Type 4, 90W Outdoor PoE Midspan
| $263.46 | Retail $300.38 |
- Outdoor rated: IP67
- Extended temperature range ?40?C to +60?C
- Supports IEEE 802.3bt type 4 standard PDs
- IEEE 802.3af/at backward compatible
- One part number for worldwide use (AC connector)
- Output power of 90W over 4-pairs is guaranteed
- Supports 10/100/1000Base-T applications
- Plug-and-play installation
- Safe: low-power devices receive only the power they need
- Automatic detection and protection of non?standard Ethernet terminals
- Complies with the latest EMI and safety standards
By:
Microchip
Manufacturer:
Microchip Technology Inc.
Product ID:
157795
Item:
PD-9601GCO/AC
UPC Code:
844117004113
Our Part #
39121004
Condition
New
$263.46EA
$300.38
$300.38
Availability
Only 3 Left In Stock
You may be also interested
Product description
Microchip PD-9601GCO Outdoor PoE Midspan - 1-Port, IP67, IEEE® 802.3bt Type 4, 90W Outdoor PoE Midspan
1-Port, IP67, IEEE® 802.3bt Type 4, 90W Outdoor PoE Midspan
Specifications
Input Ports
1 x Gigabit Ethernet
UPC Alternates
844117004113
Brand Name
Microchip
Height
2.4"
Input voltage
120 V AC
Input voltage
230 V AC
Length
6.7"
Manufacturer
Microchip Technology Inc.
Manufacturer Part Number
PD-9601GCO/AC
Manufacturer Website Address
http://www.microchip.com
Marketing Information
Microchip's PD-9601GCO Power over Ethernet (PoE) single-port midspan offers a cost effective IEEE 802.3bt type 4 compliant solution for outdoor installations guaranteeing 90 Watts of power and ensuring safe and reliable operation in outdoor environment of any standard PoE data terminal. It allows wireless LAN access points security network cameras and other IP terminals to receive power along with data over stan- dard Ethernet cables leaving network infrastructure completely unaltered.
The PD-9601GCO also offers surge protection for both the AC and the PoE ports ensuring the indoor equip-ment is protected from outdoor surges.
Maximum Input Current
1.35 A
Maximum Output Power
95 W
Product Model
PD-9601GCO
Product Name
PD-9601GCO PoE Injector
Product Type
PoE Injector
Weight (Approximate)
3.80 lb
Width
5.5"
