Eaton 480W 24V DC DIN Rail Industrial UPS - Hardwire Input/Output
Eaton 480W 24V DC DIN Rail Industrial UPS - Hardwire Input/Output - Basic - NEMA 5-20P, NEMA L5-20P - 24 x NEMA 5-20R - 120 V AC - 1920 W - Vertical - Rack-mountable
| $361.91 | Retail $491.00 |
- Recommended for industrial locations where temperatures range within 0°C and 50°C
- Protects equipment against blackouts, brownouts, overvoltages, surges and line noise
- Keeps power running during brief outages to allow time for safe system shutdown
- Built-in clamp mounts easily to a "top hat" 35mm DIN rail with no mounting screws or brackets required
- Requires Eaton BPDIN24XL extended battery module for operation (sold separately)
- Add up to 4 external battery modules (BPDIN24XL) to extend backup runtime
- 2-year limited warranty
By:
Eaton
Manufacturer:
Eaton Corporation
Product ID:
159434
Item:
DIN24480DC
Our Part #
12TL67
Condition
New
$361.91EA
$491.00
$491.00
Availability
Only 382 Left In Stock
Product description
Eaton 480W 24V DC DIN Rail Industrial UPS - Hardwire Input/Output - Basic - NEMA 5-20P, NEMA L5-20P - 24 x NEMA 5-20R - 120 V AC - 1920 W - Vertical - Rack-mountable
Basic - NEMA 5-20P, NEMA L5-20P - 24 x NEMA 5-20R - 120 V AC - 1920 W - Vertical - Rack-mountable
Specifications
Load Capacity (VA)
480 VA
Load Capacity (W)
480 W
Maximum Operating Elevation
6561 ft
Output Power Factor
1
Phase
Single Phase
Receptacle Detail
1 x Hardwired
Sound Emission (A-Weighted)
40 dB(A)
Storage Temperature
5°F (-15°C) - 104°F (40°C)
Application/Usage
Manufacturing Facility
Application/Usage
Automation Industry
Application/Usage
Network
Application/Usage
IT System
Application/Usage
Edge Computing
Application/Usage
Machine Control
Application/Usage
Industrial
Application/Usage
Storage Device
Application/Usage
Factory
Backup/Run Time (Full Load)
3 Minute
Backup/Run Time (Half Load)
10 Minute
Battery Characteristics
Valve-regulated
Battery Chemistry
Lead Acid
Brand Name
Eaton
Depth
4.8"
Display
LED
Environmental Certification
RoHS 3
Environmental Certification
REACH
Environmental Certification
WEEE
Environmental Certification
RoHS
Environmentally Friendly
Yes
Form factor
DIN Rail
Height
5"
Input voltage
24 V DC
Limited Warranty
2 Year
Load Capacity
480 VA/480 W
Manufacturer
Eaton Corporation
Manufacturer Part Number
DIN24480DC
Manufacturer Website Address
http://www.eaton.com
Marketing Information
Flexible Power Protection for Smart Industrial Applications
The DIN24480DC standby UPS system with hardwire DC input/output delivers reliable power and battery backup for computing networking control and storage equipment in factories warehouses edge computing locations and automated manufacturing and fabrication facilities. The rugged compact housing withstands demanding conditions and integrates seamlessly and securely into electrical enclosures in any non-traditional IT environment.
Ideal for Factory Floors and Extreme Temperatures
Get full use of the DIN24480DC's power capacity because there is no derating based on its operating temperature range of 0°C (32°F) to 50°C (122°F) which expands the number of locations in which it can be used. Built to fit into small spaces the DIN24480DC is a UL 508 recognized component for use in industrial panels. Its pre-installed clamp enables quick mounting to a 35 mm DIN rail. Its fanless design reduces noise and increases reliability.
Reliable Battery Backup Keeps You Operational Through Power Outages
Power outages not only drain productivity from the factory floor but they also damage expensive equipment. The DIN24480DC protects productivity by providing enough runtime to maintain operation during a brief power outage and protects equipment by allowing it to complete an operation during an extended outage. It also prevents brownouts overvoltages surges and line noise from damaging equipment that could destroy data and contribute to costly downtime.
Stay in Control of Your Operation
LEDs on the front panel confirm normal operation and indicate alarm or fault status. Remote on/off can help you avoid maintenance surprises. The DIN24480DC has dry contacts for battery status and UPS communication.
Easy Preventative Maintenance and Initial Troubleshooting
The DIN24480DC requires connection of the BPDIN24XL external battery module (sold separately). Up to four battery modules can be connected to extend backup runtime. The self-test capability can extend the life of the UPS and minimize disruption to operations.
Maximum Operating Temperature
122°F (50°C)
Package Contents
- DIN24480DC 480VA DIN Rail UPS
- Safety Card
- Owner's Manual
Plug/Connector Type
Hardwired
Product Name
DIN24480DC 480VA DIN Rail UPS
Product Type
Standby UPS
Status Indicators
LED Indicators:
- POWER (GREEN)
- LINE MODE ON (SOLID)
- BATTERY MODE (FLASHING)
- FAULT (RED) - FLASHING
Weight (Approximate)
14.40 oz
Width
1.5"
