Mellanox DAC Cable Ethernet 100GbE QSFP28 3m

Mellanox DAC Cable Ethernet 100GbE QSFP28 3m - 9.84 ft Twinaxial Network Cable for Network Device - First End: 1 x SFF-8665 QSFP28 Network - Second End: 1 x SFF-8665 QSFP28 Network - 100 Gbit/s - LSZH - 30 AWG - Black
$157.74Retail $219.00
  • For exceptional quality, upright compatibility and reliability use this network cable
  • Twinaxial cable type - for places where up to 10 meters coverage with high-speed data transfer is required
  • For extra fire safety, the cable features a halogen-free jacket
  • Fully compatible with network devices
By:
Mellanox
Manufacturer:
NVIDIA Corporation
Product ID:
169121
Item:
MCP1600-C003E30L
Our Part #
3DR746
Condition
New
$157.74EA
$219.00
Availability Only 29 Left In Stock
Great Deals Everyday

You may be also interested

Product description

Mellanox DAC Cable Ethernet 100GbE QSFP28 3m - 9.84 ft Twinaxial Network Cable for Network Device - First End: 1 x SFF-8665 QSFP28 Network - Second End: 1 x SFF-8665 QSFP28 Network - 100 Gbit/s - LSZH - 30 AWG - Black
9.84 ft Twinaxial Network Cable for Network Device - First End: 1 x SFF-8665 QSFP28 Network - Second End: 1 x SFF-8665 QSFP28 Network - 100 Gbit/s - LSZH - 30 AWG - Black

Specifications

Connector on First End Details
1 x SFF-8665 QSFP28 Network
Connector Type on First End
SFF-8665 QSFP28 Network
Product Material
Copper
American Wire Gauge
30 AWG
Brand Name
Mellanox
Cable length
9.84 ft
Cable type
Twinaxial
Data transfer rate
100 Gbit/s
Device Supported
Network Device
Environmental Certification
RoHS
Environmentally Friendly
Yes
Features
Passive
Features
Bendable
Features
Halogen Free
Features
Lead-free
Jacket Type
LSZH
Limited Warranty
1 Year
Manufacturer
NVIDIA Corporation
Manufacturer Part Number
MCP1600-C003E30L
Manufacturer Website Address
http://www.nvidia.com
Marketing Information

NVIDIA MCP1600-C003E30L Direct Attach Copper Cable Ethernet 100GbE QSFP28 3m Black 30AWG CA-L100GbE QSFP28 Direct Attach Copper Cable

NVIDIA's direct attach copper (DAC) cables are high speed cost-effective alternatives to fiber optics in 100Gb/s Ethernet applications.

NVIDIA QSFP28 passive copper cable contains four high-speed copper pairs each operating at data rates of up to 25GbE. Each QSFP28 connector includes an EEPROM providing product information which can be read by the host system.

NVIDIA's unique quality passive copper cable solutions provide power-efficient connectivity for short distance interconnects. They enable higher port bandwidth density and configurability at a low cost and reduced power requirement in the data centers.

MCP1600-C0xxEyyz cables up to 2m support IEEE 802.3bj CA-25G-N (Cable Assembly No-FEC) with low latency. Cables from 3m to 5m support IEEE 802.3bj CA-25G-L (Cable Assembly Long) with RS-FEC (Reed Solomon Forward Error Correction) enabled(1). For 2.5m and 3m cables there are two versions supporting either CA-25G-N or CA-25G-L.

NVIDIA's unique quality passive copper cable solutions provide power-efficient connectivity for short distance interconnects. They enable higher port bandwidth density and configurability at a low cost and reduced power requirement in the data centers.

Rigorous cable production testing ensures best out-of-the-box installation experience performance and durability.

Highlights

  • Up to 100GbE data rate
  • SFF-8665 compliant QSFP28
  • Operating case temperature 0-70C
  • Single 3.3V supply voltage
  • Bit Error Rate (BER) better than 1E-15
  • Hot pluggable
  • RoHS compliant
  • LSZH (Low Smoke Zero Halogen) jacket
  • LF (Lead Free) HF (Halogen Free) PCB
  • SFF-8636 compliant I2C management interface
Product color
Black
Product Name
DAC Cable Ethernet 100GbE QSFP28 3m
Product Type
Network Cable
