ATEN Proxime CE700A KVM Console/Extender
ATEN Proxime CE700A KVM Console/Extender - 1 Computer(s) - 1 Local User(s) - 1 Remote User(s) - 492.13 ft Range - WUXGA - 1920 x 1200 Maximum Video Resolution - 2 x Network (RJ-45) - 4 x USB - 2 x VGA - Proprietary Interface - 5.3 V DC Input Voltage - Rack-mountable
| $250.42 | Retail $294.00 |
- Cat 5e cable connects the Local and Remote Units - up to 150m apart
- Dual console operation - control your system from both the local and remote USB keyboard, monitor, and mouse consoles
- Built-in ASIC for greater reliability and compatibility
- Auto Signal Compensation (ASC)
- USB Keyboard and USB Mouse Ports
- USB overcurrent detection and prevention
- Pushbutton operating mode selection (Local Unit only) - select between Local and Auto operating modes.
- Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection
- Automatic gain control - adjusts signal strength to compensate for distance
- High resolution video - up to 1920 x 1200@60Hz (30m ); 1600 x 1200@60Hz (100m); 1280 x 1024@60Hz (150m)
By:
ATEN
Manufacturer:
ATEN Technology, Inc
Product ID:
170658
Item:
CE700A
UPC Code:
672792002120
Our Part #
CN6875
Condition
New
$250.42EA
$294.00
$294.00
Availability
Only 26 Left In Stock
Product description
ATEN Proxime CE700A KVM Console/Extender - 1 Computer(s) - 1 Local User(s) - 1 Remote User(s) - 492.13 ft Range - WUXGA - 1920 x 1200 Maximum Video Resolution - 2 x Network (RJ-45) - 4 x USB - 2 x VGA - Proprietary Interface - 5.3 V DC Input Voltage - Rack-mountable
1 Computer(s) - 1 Local User(s) - 1 Remote User(s) - 492.13 ft Range - WUXGA - 1920 x 1200 Maximum Video Resolution - 2 x Network (RJ-45) - 4 x USB - 2 x VGA - Proprietary Interface - 5.3 V DC Input Voltage - Rack-mountable
Specifications
KVM Technology
Analog
Receiver Weight (Approximate)
10.93 oz
Transmitter Weight (Approximate)
11.29 oz
UPC Alternates
672792002120 743928306464 818204549108 818216199759
Brand Name
ATEN
Connectivity technology
Wired
Country of origin
China
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
Rack-mountable
Graphic Mode
WUXGA
Input voltage
5.3 V DC
Limited Warranty
2 Year
Manufacturer
ATEN Technology Inc
Manufacturer Part Number
CE700A
Manufacturer Website Address
http://www.aten.com/us/en/
Marketing Information
The Proxime CE700A KVM Console/Extender is a USB KVM Extender with superior video quality and built-in ESD and surge protection that allows access to a computer system up to 150 meters away from a remote USB console (USB keyboard monitor and USB mouse. The Proxime CE700A KVM Console/Extender improves on previous designs by incorporating 8KV/15KV ESD protection and 2KV surge protection and providing superior video quality up to 1920 x 1200 resolution.
Maximum Operating Distance
492.13 ft
Maximum Video Resolution
1920 x 1200
Number of Network (RJ-45) Ports
2
Number of USB Ports
4
Package Contents
- Proxime CE700A KVM Console/Extender
- 2 x Power Adapters
- 1 x USB KVM Cable
- 2 x Grounding Wires
- 1 x Rack Mount Kit
- 1 x User Manual
- 1 x Quick Start Guide
Packaged Quantity
1
Product Line
ProXime
Product Name
Proxime CE700A KVM Console/Extender
Product Type
KVM Console/Extender
