Kramer MegaTOOLS EXT3-XR-TR Video Extender Transmitter
Kramer MegaTOOLS EXT3-XR-TR Video Extender Transmitter - 1 Input Device - 1 Output Device - 328.08 ft Range - 2 x Network (RJ-45) - 4 x USB - 1 x HDMI In - 1 x HDMI Out - 4K UHD - Twisted Pair - Ceiling Mount, Rack-mountable, Desktop
| $554.47 | Retail $950.00 |
By:
Kramer
Manufacturer:
Kramer Electronics LTD
Product ID:
172854
Item:
EXT3-XR-TR
Our Part #
7139544
Condition
New
$554.47EA
$950.00
$950.00
Availability
Only 27 Left In Stock
You may be also interested
Product description
Kramer MegaTOOLS EXT3-XR-TR Video Extender Transmitter - 1 Input Device - 1 Output Device - 328.08 ft Range - 2 x Network (RJ-45) - 4 x USB - 1 x HDMI In - 1 x HDMI Out - 4K UHD - Twisted Pair - Ceiling Mount, Rack-mountable, Desktop
1 Input Device - 1 Output Device - 328.08 ft Range - 2 x Network (RJ-45) - 4 x USB - 1 x HDMI In - 1 x HDMI Out - 4K UHD - Twisted Pair - Ceiling Mount, Rack-mountable, Desktop
Specifications
Transmitter Depth
4.57"
Transmitter Height
1.06"
Transmitter Weight (Approximate)
1.32 lb
Transmitter Width
7.48"
Brand Name
Kramer
Connectivity technology
Wired
Environmental Certification
RoHS
Environmental Certification
WEEE
Environmentally Friendly
Yes
Form factor
Desktop
Form factor
Rack-mountable
Form factor
Ceiling Mount
Graphics Modes
4K UHD
Limited Warranty
7 Year
Manufacturer
Kramer Electronics LTD
Manufacturer Part Number
EXT3-XR-TR
Manufacturer Website Address
http://www.kramerelectronics.com
Marketing Information
EXT3-XR-TR is a high-performance extended-reach HDBaseT 3.0 extender for 4K60Hz (4:4:4) HDMI USB Ethernet RS-232 and IR signals over twisted pair flexibly set as transmitter-side or receiver-side device. EXT3-XR-TR transmitter-side converts all input signals into the transmitted HDBaseT 3.0 signal. EXT3-XR-TR receiver-side receives the HDBaseT 3.0 signal and converts it back into the original input signals. It extends video signals to up 100m (330ft) over CAT copper cables at up to 4K@60Hz (4:4:4) video resolution
FEATURES
High Performance Standard Extender - Professional HDBaseT extender for providing extended-reach signals over twisted-pair copper infrastructures. TP-600TRxr is a standard extender that can be connected to any market-available HDBaseT-compliant extension product. For optimum extension reach and performance use recommended Kramer cables
HDMI Signal Extension - HDCP 2.3 EDID and CEC signals are passed through from the source to the display. Supports HDR10 deep color x.v.Color™ lip sync HDMI uncompressed audio channels Dolby TrueHD DTS-HD 2K 4K and 3D as specified in HDMI 2.0
HDMI Mirroring - Transmitter-side extender mirrors input HDMI signal to loop output port for connecting a local monitor or an additional unit in a daisy chain
Flexible USB 2.0 Extension - An active USB host is connected to the extender at either the transmitter or receiver sides. USB 2.0 signals are extended between the extender transmitter and receiver sides enabling connection of the active USB host to both local and remote USB devices such as camera and audio devices or HID (Human Interface Devices) mouse or keyboard devices
Multi-channel Audio Transmission - Up to 32 channels of digital stereo uncompressed signals for supporting studio-grade surround sound
Ethernet Extension - Ethernet interface data flows in both directions allowing extension of up to 1 Gbps Ethernet connectivity for LAN communication and device control
Bidirectional RS-232 Extension - Serial interface data flows in both directions allowing data transmission and device control
Bidirectional Infrared Extension - IR interface data flows in both directions allowing remote control of peripheral devices located at either end of the extended line
Cost-effective Maintenance - Status LED indicators for HDMI Loop HDBT and USB active host ports facilitate easy local maintenance and troubleshooting
Easy and Elegant Installation - MegaTOOLS™ fan-less enclosure for dropped-ceiling mounting or side-by-side mounting of 2 units in a 1U rack space with the recommended rack adapter
FEATURES
High Performance Standard Extender - Professional HDBaseT extender for providing extended-reach signals over twisted-pair copper infrastructures. TP-600TRxr is a standard extender that can be connected to any market-available HDBaseT-compliant extension product. For optimum extension reach and performance use recommended Kramer cables
HDMI Signal Extension - HDCP 2.3 EDID and CEC signals are passed through from the source to the display. Supports HDR10 deep color x.v.Color™ lip sync HDMI uncompressed audio channels Dolby TrueHD DTS-HD 2K 4K and 3D as specified in HDMI 2.0
HDMI Mirroring - Transmitter-side extender mirrors input HDMI signal to loop output port for connecting a local monitor or an additional unit in a daisy chain
Flexible USB 2.0 Extension - An active USB host is connected to the extender at either the transmitter or receiver sides. USB 2.0 signals are extended between the extender transmitter and receiver sides enabling connection of the active USB host to both local and remote USB devices such as camera and audio devices or HID (Human Interface Devices) mouse or keyboard devices
Multi-channel Audio Transmission - Up to 32 channels of digital stereo uncompressed signals for supporting studio-grade surround sound
Ethernet Extension - Ethernet interface data flows in both directions allowing extension of up to 1 Gbps Ethernet connectivity for LAN communication and device control
Bidirectional RS-232 Extension - Serial interface data flows in both directions allowing data transmission and device control
Bidirectional Infrared Extension - IR interface data flows in both directions allowing remote control of peripheral devices located at either end of the extended line
Cost-effective Maintenance - Status LED indicators for HDMI Loop HDBT and USB active host ports facilitate easy local maintenance and troubleshooting
Easy and Elegant Installation - MegaTOOLS™ fan-less enclosure for dropped-ceiling mounting or side-by-side mounting of 2 units in a 1U rack space with the recommended rack adapter
Maximum Operating Distance
328.08 ft
Media Type Supported
Twisted Pair
Number of HDMI Inputs
1
Number of Network (RJ-45) Ports
2
Number of USB Ports
4
Package Contents
- MegaTOOLS EXT3-XR-TR Video Extender Transmitter
- Power Adapter
- Bracket
- Rubber Feet
Product Line
MegaTOOLS
Product Name
MegaTOOLS EXT3-XR-TR Video Extender Transmitter
Product Type
Video Extender Transmitter
