Kramer 4K UHD HDMI, Bidirectional RS-232 & IR over HDBaseT Twisted Pair Transmitter
Kramer 4K UHD HDMI, Bidirectional RS-232 & IR over HDBaseT Twisted Pair Transmitter - 1 Input Device - 229.66 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 4K - 4096 x 2160 - Twisted Pair - Category 6 - Rack-mountable
| $186.94 | Retail $335.00 |
By:
Kramer
Manufacturer:
Kramer Electronics LTD
Product ID:
172935
Item:
50-80021090
Our Part #
43201614
Condition
New
$186.94EA
$335.00
$335.00
Availability
Only 3 Left In Stock
Product description
Kramer 4K UHD HDMI, Bidirectional RS-232 & IR over HDBaseT Twisted Pair Transmitter - 1 Input Device - 229.66 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 4K - 4096 x 2160 - Twisted Pair - Category 6 - Rack-mountable
1 Input Device - 229.66 ft Range - 1 x Network (RJ-45) - 1 x HDMI In - 4K - 4096 x 2160 - Twisted Pair - Category 6 - Rack-mountable
Specifications
Network (RJ-45)
Yes
Transmitter Depth
2.81"
Transmitter Height
0.96"
Transmitter Weight (Approximate)
7.05 oz
Transmitter Width
4.72"
Brand Name
Kramer
Connectivity technology
Wired
Form factor
Rack-mountable
Graphics Modes
4K
Manufacturer
Kramer Electronics LTD
Manufacturer Part Number
50-80021090
Manufacturer Website Address
http://www.kramerelectronics.com
Marketing Information
The TP-580T is a high-performance HDBaseT twisted pair transmitter for 4K@60 UHD (4:2:0) 2Kx4K HDMI bidirectional RS-232 and IR signals. The TP-580T inputs HDMI RS-232 and IR signals and converts them into an HDBaseT twisted pair signal that it transmits to a TP-580R receiver.
- Max. Data Rate - 10.2Gbps (3.4Gbps per graphic channel).
- HDTV Compatible.
- HDCP Compliance.
- Resolution Support - 4K@60 UHD (4:2:0) 2Kx4K.
- HDBaseT™ Technology.
- HDMI Support - Deep Color x.v.Color™ Lip Sync HDMI Uncompressed Audio Channels Dolby TrueHD DTS-HD CEC.
- 3D Pass-Through.
- EDID PassThru - Passes EDID signals between the source and display.
- Bidirectional RS-232 & IR Interface. - Commands and data can flow in both directions via the RS-232 interface allowing status requests and remote control of the destination unit.
- System Range - 70m (230ft) at 2K 40m (130ft) at 4K UHD resolutions.
- Cable - For optimum range and performance using HDBaseT™ use Kramer's BC-HDKat6a cable. Note that the transmission range depends on the signal resolution source and display used. The distance using non-Kramer CAT 6 cable may not reach these ranges.
- Indicators - Status LEDs for input output link and power.
- Compact DigiTOOLS® - 3 units can be rack mounted side-by-side in a 1U rack space with the optional RK-3T universal rack adapter.
Maximum Operating Distance
229.66 ft
Maximum Video Resolution
4096 x 2160
Media Type Supported
Twisted Pair
Number of Network (RJ-45) Ports
1
Product Model
TP-580T
Product Name
4K UHD HDMI Bidirectional RS?232 & IR over HDBaseT Twisted Pair Transmitter
Product Type
Video Extender Transmitter
Twisted Pair Cable Standard
Category 6
